Command List
Command List (4/5)
Command Set Command Command Packet Comments
CAM_Title Title Set1 8x 01 04 73 1L 00 nn pp L: Line Number, nn: H-position
qq rr 00 00 00 00 00 FF pp: Color, qq: Blink rr: Opening Title
Title Set2 8x 01 04 73 2L mm nn pp L: Line Number,
qq rr ss tt uu vv ww FF mnpqrstuvw: Setting of characters (1 to 10)
Title Set3 8x 01 04 73 3L mm nn pp L: Line Number,
qq rr ss tt uu vv ww FF mnpqrstuvw: Setting of characters (11 to 20)
Title Clear 8x 01 04 74 1p FF Title Setting clear (p: 0 to a, f= all lines)
On 8x 01 04 74 2p FF Title display On/Off (0 to a, f= all lines)
Off 8x 01 04 74 3p FF
CAM_Mute On 8x 01 04 75 02 FF Mute ON/OFF
Off 8x 01 04 75 03 FF
On/Off 8x 01 04 75 10 FF
CAM_PrivacyZone SetMask 8x 01 04 76 mm nn mm: Mask Settings
0r 0r 0s 0s FF nn 00: Modify, 01: New
rr: W, ss:H
Display 8x 01 04 77 pp pp pp pp FF Mask Display ON/OFF
pp pp pp pp: Mask Settings (0:OFF, 1:ON)
SetMaskColor 8x 01 04 78 pp pp pp pp pp pp pp pp: Mask Color Settings
qq rr FF qq: Color Setting when 0 is selected
rr: Color Setting when 1 is selected
SetPanTiltAngle 8x 01 04 79 0p 0p 0p Pan/Tilt Angle Settings
0q 0q 0q FF ppp: Pan
qqq: Tilt
SetPTZMask 8x 01 04 7B mm 0p 0p 0p Pan/Tilt/Zoom Settings for Mask
0q 0q 0q 0r 0r 0r 0r FF ppp: Pan, qqq: Tilt, rrrr: Zoom
Non_InterlockMask 8x 01 04 6F mm mm: Non_Interlock Mask Settings
0p 0p 0q 0q 0r 0r 0s 0s FF pp: X, q: Y, rr: W, ss: H
GridOn 8x 01 04 7C 02 FF Grid Display ON/OFF
GridOff 8x 01 04 7C 03 FF Grid/Center Line Display Off
CenterLineOn 8x 01 04 7C 04 FF Center Line Display On
CAM_KeyLock Off 8x 01 04 17 00 FF Camera Control Enable/Disable
On 8x 01 04 17 02 FF
CAM_IDWrite 8x 01 04 22 0p 0q 0r 0s FF pqrs: Camera ID (=0000 to FFFF)
CAM_ExternalLock INT 8x 01 04 55 00 FF Internal mode
Line Lock 8x 01 04 55 01 FF Line Lock mode
CAM_VPhase Stop 8x 01 04 05 00 FF
Up 8x 01 04 05 02 FF
Down 8x 01 04 05 03 FF
Up (Step) 8x 01 04 05 2p FF p=step (1-7)
Down (Step) 8x 01 04 05 3p FF
Reset 8x 01 04 05 40 FF Restore Factory Settings
Direct 8x 01 04 45 0p 0q 0r 0s FF pqrs: V-Phase (0000~)
(NTSC: 0000 to 20Chex, PAL: 0000 to 270hex)
