Sony FCB-EX1010 - FCB Camera Command Reference (Part 5)

38
Command List
Command List (5/5)
Command Set Command Command Packet Comments
CAM_MD On 8x 01 04 1B 02 FF Motion Detection On/Off
Off 8x 01 04 1B 03 FF
Function Set 8x 01 04 1C 0m 0n 0p 0q 0r 0s FF m: Display mode
n: Detection Frame Set (0 to F)
pq: Threshold Level (00 to FF)
rs: Interval Time set (00 to FF)
Window Set 8x 01 04 1D 0m 0p 0q 0r 0s FF m: Select Detection Frame (0, 1, 2, 3)
p: Start Horizontal Position (00 to 0B)
q: Start Vertical Position (00 to 07)
r: Stop Horizontal Position (01 to 0C)
s: Stop Vertical Position (01 to 08)
Alarm (Reply) y0 07 04 1B 0p FF p: Detection Frame Number
CAM_Continuous On 8x 01 04 69 02 FF ZoomPosition data Continuous Output On/Off
ZoomPosReply Off 8x 01 04 69 03 FF
(Reply) y0 07 04 69 0p 0p 0q 0q 0q 0q FF pp: D-Zoom Position
* 00: When Zoom Mode is Combine
qqqq: Zoom Position
CAM_ 8x 01 04 6A 00 00 0p 0p FF pp: Interval Time [Vertical timing]
ReplyIntervalTimeSet
CAM_RegisterValue 8x 01 04 24 mm 0p 0p FF mm: Register No. (=00-7F)
pp: Register Value (=00-7F)
