Sony FD Trinitron KV-28LS35E - Power Supply and Front-End Parts

REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK
51
F3
AF2
*A-1624-099-A F2 Board, Complete
4-205-711-01 HOLDER, LED
< CAPACITOR >
C2150 1-126-969-11 ELECT 220UF 20.00% 50V
C2601 1-113-924-11 CERAMIC 0.0047UF 20.00% 250V
< CONNECTOR >
CN2150 *1-564-510-11 PLUG, CONNECTOR 7P
CN2601 *1-580-844-11 PIN, CONNECTOR (POWER)
CN2602 1-695-915-11 TAB (CONTACT)
CN2603 *1-691-291-11 PIN, CONNECTOR (PC BOARD) 5P
< DIODE >
D2150 8-719-081-56 DIODE L-59SRSGC-CC
D2152 8-719-109-89 DIODE RD5.6ESB2
< IC >
IC2150 8-749-014-59 IC TSOP1740KS1
< TRANSISTOR >
Q2150 8-729-027-38 TRANSISTOR DTA144EKA-T146
Q2151 8-729-027-43 TRANSISTOR DTC114EKA-T146
< RESISTOR >
R2150 1-216-813-91 RES CHIP 220 5% 1/16W
R2151 1-216-813-91 RES CHIP 220 5% 1/16W
R2152 1-216-841-91 RES CHIP 47K 5% 1/16W
R2153 1-216-829-91 RES CHIP 4.7K 5% 1/16W
R2154 1-216-825-91 RES CHIP 2.2K 5% 1/16W
R2155 1-216-809-91 RES CHIP 100 5% 1/16W
R2156 1-216-815-91 RES CHIP 330 5% 1/16W
< SWITCH >
S2601 £ 1-571-433-21 SWITCH, PUSH (AC POWER)
*A-1624-100-A F3 Board, Complete
*4-374-846-01 COVER, CAPACITOR, CAP TYPE
< CAPACITOR >
C3601 1-113-924-11 CERAMIC 0.0047UF 20.00% 250V
C3602 1-136-212-12 FILM 0.1UF 20.00% 300V
< CONNECTOR >
CN3601 1-580-843-11 PIN, CONNECTOR (POWER)
CN3602 1-695-915-11 TAB (CONTACT)
CN3603 1-580-843-11 PIN, CONNECTOR (POWER)
< FUSE >
F3601 £ 1-576-232-21 FUSE (H.B.C.) 5A/250V
*1-533-725-11 HOLDER, FUSE (F3601)
< RESISTOR >
R3601 1-202-719-00 SOLID 1M 10% 1/2W
< TRANSFORMER >
T3602 1-433-488-11 TRANSFORMER, LINE FILTER
< VARISTOR >
VD3601 1-803-830-31 VARISTOR (ERZV14D621)
*A-1632-945-A A Board, Complete (KV-28LS35B)
*A-1632-946-A A Board, Complete (KV-28LS35E)
*A-1632-934-A A Board, Complete (KV-28LS35U)
*A-1632-939-A A Board, Complete (KV-32LS35B)
*A-1632-940-A A Board, Complete (KV-32LS35E)
*A-1632-931-A A Board, Complete (KV-32LS35U)
A Board, Common Parts
1-900-903-72 LEAD ASSY, FOCUS
4-382-854-01 SCREW (M3X8), P, SW (+)
4-382-854-01 SCREW (M3X8), P, SW (+)
< CAPACITOR >
C002 1-163-233-91 CERAMIC CHIP 18PF 5.00% 50V
C004 1-163-037-11 CERAMIC CHIP 0.022UF 10.00% 50V
C005 1-126-926-91 ELECT 1000UF 20.00% 10V
C006 1-163-233-91 CERAMIC CHIP 18PF 5.00% 50V
C009 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C010 1-164-005-11 CERAMIC CHIP 0.47UF 16V
C011 1-163-005-91 CERAMIC CHIP 470PF 10.00% 50V
C012 1-126-963-11 ELECT 4.7UF 20.00% 50V
C013 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C014 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C015 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C016 1-216-295-91 SHORT 0
C018 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C019 1-162-919-91 CERAMIC CHIP 22PF 5.00% 50V
C020 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C021 1-163-037-11 CERAMIC CHIP 0.022UF 10.00% 50V
C022 1-126-935-11 ELECT 470UF 20.00% 10V
C025 1-126-935-11 ELECT 470UF 20.00% 16V
C026 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C027 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C028 1-163-009-91 CERAMIC CHIP 0.001UF 10.00% 50V
C030 1-163-009-91 CERAMIC CHIP 0.001UF 10.00% 50V
C033 1-163-009-91 CERAMIC CHIP 0.001UF 10.00% 50V
