Sony FWD-S42E1 - Input Signal Reference Chart

34
GB
Input Signal Reference
Chart
TV/Video signals
a) VGA is a registered trademark of International Business
Machines Corporation, U.S.A.
b) Macintosh is a trademark of Apple Inc., registered in the
U.S. and other countries.
c) VESA is a registered trademark of the Video Electronics
Standards Association.
d) VESA Coordinated Video Timing
• For HDTV signals, input the tri-level sync signal to the
2nd pin of HD15 (RGB/COMPONENT) IN connector.
• If colors appear too light after input of a DVD signal to the
display, adjust “Chroma” in the “Picture/Sound” settings.
• When the phase is readjusted, the resolution will be
reduced.
• The signals from the Macintosh computer will not be
guaranteed for recognizing the digital RGB input.
• You cannot input the signal indicated with * to DVI IN.
PC signals
Resolution
horizontal
frequency
(kHz)
vertical
frequency
(Hz)
1VGA
a)
-1 (VGA 350) 31.5 70
2 640 × 480@60 Hz 31.5 60
3Mac
b)
13" 35.0 67
4 VGA (VGA TEXT) 31.5 70
5
800 × 600@60 Hz (VESA
c)
STD) 37.9 60
6 Mac 16" 49.7 75
7
1024 × 768@60 Hz (VESA STD) 48.4 60
8
1024 × 768@75 Hz (VESA STD) 60.0 75
9
1024 × 768@85 Hz (VESA STD) 68.7 85
10
1152 × 864@75 Hz (VESA STD) 67.5 75
11 Mac 21" 68.7
75
12 1280 × 960@60 Hz (VESA STD) 60.0 60
13
1280 × 1024@60 Hz (VESA STD) 64.0 60
14
1600 × 1200@60 Hz (VESA STD)* 75.0 60
15 848 × 480@60 Hz (CVT
d)
)29.8 60
16 848 × 480@75 Hz (CVT) 37.7 75
17 848 × 480@85 Hz (CVT) 43.0 85
18 1280 × 720@60 Hz (CVT) 44.8 60
19 1280 × 768@60 Hz (CVT) 47.8 60
20 1280 × 768@75 Hz (CVT) 60.3 75
21 1280 × 960@60 Hz (CVT) 59.7 60
22 1360 × 768@60 Hz (CVT) 47.7 60
23 800 × 600@60 Hz (CVT) 37.4 60
24 1024 × 768@60 Hz (CVT) 47.8 60
25 1280 × 1024@60 Hz (CVT) 63.7 60
26
1400 × 1050@60 Hz (CVT)* 65.3 60
27
1600 × 1200@60 Hz (CVT)* 74.5 60
28 1920 × 1080@60 Hz 66.6 60
29 1920 × 1200@60 Hz 74.0 60
Resolution
Available Inputs
Component DVI HDMI SDI
1 480/60i a
a
2 480/60p aaa
3 575/50i a a
4 576/50p aaa
5 720/50p aaaa
6 720/60p aaaa
7 1080/50i aaaa
8 1080/60i aaaa
9 1080/50p
a
10 1080/60p a
11 1080/24PsF a
Notes
