Sony GDM-C520 - Vertical and Horizontal Position and Size Specification; Focus Adjustment

— 18 —
GDM-C520/C520K
3-5. VERTICAL AND HORIZONTAL POSITION
AND SIZE SPECIFICATION
B
a
a 1.8 mm
b 1.8 mm
a
b
b
A
MODE
A
B
4 : 3
388
291
3-6. FOCUS ADJUSTMENT
1. Adjust Focus (V) and Focus (H) for optimum focus.
Focus (V)
Focus (H)
