REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
NOTE: The components identied by shading
and
!
mark are critical for safety. Replace only
with part number specied.
NOTE: Les composants identies per un trame et une
marque
!
sont critiques pour la securite. Ne les
remplacer que par une piece portant le numero specie.
D
* A-1348-031-E D BOARD, COMPLETE
The high-voltage leads associated with the FBT on the D board are not included and
must be ordered separately. Order the following leads when requesting this D board.
!
1-900-805-55 WIRE ASSY, FOCUS LEAD
!
1-251-715-63 CAP ASSY, HIGH-VOLTAGE
CAPACITOR
C401 1-128-528-11 ELECT 470µF 20% 25V
C402 1-130-785-11 MYLAR 0.47µF 5% 100V
C403 1-107-911-11 ELECT 220µF 20% 50V
C404 1-128-528-11 ELECT 470µF 20% 25V
C405 1-163-009-91 CERAMIC CHIP 0.001µF 10% 50V
C406 1-130-475-00 MYLAR 0.0022µF 5% 50V
C407 1-164-161-11 CERAMIC CHIP 0.0022µF 10% 50V
C408 1-163-222-11 CERAMIC CHIP 5pF 0.25pF 50V
C500 1-163-259-91 CERAMIC CHIP 220pF 5% 50V
C502 1-137-150-11 FILM 0.01µF 5% 100V
C503 1-130-495-00 MYLAR 0.1µF 5% 50V
C504 1-136-287-11 FILM 0.0047µF 5% 100V
C505 1-126-949-11 ELECT 220µF 20% 35V
C506 1-127-810-51 ELECT 22µF 20% 250V
C507 1-136-207-11 MYLAR 0.047µF 5% 630V
C508 1-137-715-11 FILM 3300pF 3% 1.8KV
C509 1-107-444-11 CERAMIC 100pF 5% 2KV
C510 1-136-684-51 FILM 0.0022µF 2.00% 100V
C511 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C512 1-163-005-91 CERAMIC CHIP 470pF 10% 50V
C513 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C514 1-136-287-11 FILM 0.0047µF 5% 100V
C515 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C516 1-126-934-11 ELECT 220µF 20% 16V
C517 1-163-133-00 CERAMIC CHIP 470pF 5% 50V
C519 1-163-017-00 CERAMIC CHIP 0.0047µF 10% 50V
C520 1-163-023-00 CERAMIC CHIP 0.015µF 10% 50V
C521 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C522 1-126-965-91 ELECT 22µF 20% 50V
C524 1-126-941-11 ELECT 470µF 20% 25V
C525 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C533 1-163-017-00 CERAMIC CHIP 0.0047µF 10% 50V
C534 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C535 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C536 1-107-665-11 ELECT 0.47µF 20% 400V
C537 1-137-868-11 FILM 0.13µF 5% 400V
C538 1-107-651-11 ELECT 4.7µF 20% 250V
C539 1-115-356-11 FILM 1.2µF 5% 250V
C540 1-107-888-11 ELECT 47µF 20% 25V
C541 1-115-521-11 FILM 0.82µF 5% 250V
C542 1-164-346-11 CERAMIC CHIP 1µF 16V
C543 1-117-666-11 FILM 0.39µF 5% 250V
C544 1-164-005-11 CERAMIC CHIP 0.47µF 25V
C545 1-117-662-11 FILM 0.18µF 5% 250V
C546 1-164-222-91 CERAMIC CHIP 0.22µF 25V
C547 1-119-860-21 FILM 0.082µF 5% 250V
C548 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C549 1-136-060-00 FILM 0.047µF 5% 400V
C550 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C554 1-163-009-91 CERAMIC CHIP 0.001µF 10% 50V
C559 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C560 1-137-856-11 FILM 0.018µF 5% 400V
C561 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C562 1-163-009-91 CERAMIC CHIP 0.001µF 10% 50V
C563 1-104-572-11 CERAMIC 0.0022µF 10% 2KV
C564 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C565 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C566 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C601 1-107-533-11 MYLAR 1µF 20% 250V
C602 1-104-708-11 MYLAR 0.47µF 20% 250V
!
C603 1-113-900-11 CERAMIC 470pF 10% 250V
!
C604 1-113-900-11 CERAMIC 470pF 10% 250V
C605 1-113-926-11 CERAMIC 0.0047µF 250V
C606 1-113-926-11 CERAMIC 0.0047µF 250V
!
C607 1-113-920-11 CERAMIC 0.0022µF 20% 250V
C610 1-137-673-11 ELECT 330µF 20% 450V
C611 1-117-227-11 MYLAR 1µF 10% 450V
C612 1-136-169-00 FILM 0.22µF 5% 50V
C613 1-126-967-11 ELECT 47µF 20% 50V
C614 1-163-251-11 CERAMIC CHIP 100pF 5% 50V
C615 1-104-564-91 CERAMIC 100pF 10% 2KV
C629 1-163-017-00 CERAMIC CHIP 0.0047µF 10% 50V
C630 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C631 1-104-665-11 ELECT 100µF 20% 25V
C632 1-126-961-11 ELECT 2.2µF 20% 50V
C635 1-163-005-91 CERAMIC CHIP 470pF 10% 50V
C636 1-164-161-11 CERAMIC CHIP 0.0022µF 10% 50V
C640 1-126-795-11 ELECT 10µF 20% 50V
D
