REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
R201 1-215-395-00 METAL 82 1% 1/4W
R204 1-216-059-00 METAL CHIP 2.7K 5% 1/10W
R206 1-249-436-11 CARBON 39K 5% 1/4W
R207 1-216-687-11 METAL CHIP 33K 0.50% 1/10W
R208 1-216-667-11 METAL CHIP 4.7K 0.50% 1/10W
R209 1-218-776-11 METAL CHIP 1M 0.50% 1/10W
R210 1-216-045-00 METAL CHIP 680 5% 1/10W
R211 1-249-403-11 CARBON 68 5% 1/4W
R215 1-216-683-11 METAL CHIP 22K 0.50% 1/10W
R217 1-216-013-00 METAL CHIP 33 5% 1/10W
R218 1-216-017-00 METAL CHIP 47 5% 1/10W
R219 1-218-768-11 METAL CHIP 470K 0.50% 1/10W
R220 1-218-768-11 METAL CHIP 470K 0.50% 1/10W
R221 1-218-768-11 METAL CHIP 470K 0.50% 1/10W
R222 1-218-776-11 METAL CHIP 1M 0.50% 1/10W
R223 1-249-416-11 CARBON 820 5% 1/4W
R230 1-249-399-11 CARBON 33 5% 1/4W
R233 1-469-965-21 INDUCTOR 0µH
R240 1-249-399-11 CARBON 33 5% 1/4W
R251 1-219-742-11 METAL 47 5% 1/2W
R261 1-215-395-00 METAL 82 1% 1/4W
R263 1-216-025-00 METAL CHIP 100 5% 1/10W
R264 1-218-754-11 METAL CHIP 120K 0.50% 1/10W
R301 1-215-395-00 METAL 82 1% 1/4W
R304 1-216-059-00 METAL CHIP 2.7K 5% 1/10W
R306 1-249-436-11 CARBON 39K 5% 1/4W
R307 1-216-687-11 METAL CHIP 33K 0.50% 1/10W
R308 1-216-667-11 METAL CHIP 4.7K 0.50% 1/10W
R309 1-218-776-11 METAL CHIP 1M 0.50% 1/10W
R310 1-216-039-00 METAL CHIP 330 5% 1/10W
R311 1-249-402-11 CARBON 56 5% 1/4W
R315 1-216-683-11 METAL CHIP 22K 0.50% 1/10W
R317 1-216-013-00 METAL CHIP 33 5% 1/10W
R318 1-216-019-91 RES-CHIP 56 5% 1/10W
R319 1-218-768-11 METAL CHIP 470K 0.50% 1/10W
R320 1-218-768-11 METAL CHIP 470K 0.50% 1/10W
R321 1-218-768-11 METAL CHIP 470K 0.50% 1/10W
R322 1-218-776-11 METAL CHIP 1M 0.50% 1/10W
R323 1-249-416-11 CARBON 820 5% 1/4W
R330 1-249-399-11 CARBON 33 5% 1/4W
R333 1-469-965-21 INDUCTOR 0µH
R340 1-249-399-11 CARBON 33 5% 1/4W
R351 1-219-742-11 METAL 47 5% 1/2W
R361 1-215-395-00 METAL 82 1% 1/4W
R363 1-216-025-00 METAL CHIP 100 5% 1/10W
R364 1-218-754-11 METAL CHIP 120K 0.50% 1/10W
SPARK GAP
SG001 1-519-422-11 GAP, SPARK
SG002 1-519-421-11 GAP, DISCHARGE
SG101 1-519-421-11 GAP, DISCHARGE
SG201 1-519-421-11 GAP, DISCHARGE
SG301 1-519-421-11 GAP, DISCHARGE
CRYSTAL
X001 1-760-682-21 VIBRATOR, CRYSTAL
A1
— 52 —
GDM-C520/C520K
