Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HBD-E370/E470/E570/E870/T57
112
C415 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C426 1-104-666-11 ELECT 220uF 20% 25V
C428 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C431 1-126-949-11 ELECT 220uF 20% 35V
< CONNECTOR >
* CN400 1-691-774-11 PLUG (MICRO CONNECTOR) 12P
CN403 1-784-926-11 PIN, CONNECTOR 11P
< DIODE >
D402 8-719-083-63 DIODE UDZSUSTE-1713B
D403 8-719-083-66 DIODE UDZSUSTE-1718B
D405 8-719-083-87 DIODE UDZSUSTE-1733B
D406 6-500-288-11 DIODE EK19LF-F7
D407 6-500-288-11 DIODE EK19LF-F7
< IC >
IC400 6-702-302-01 IC TK11133CSCL-G
IC402 6-715-070-01 IC TK72270CSCL-GH
< COIL >
L401 1-457-725-11 INDUCTOR 4.7uH
<
TRANSISTOR >
Q401 8-729-028-96 FET DTC114EUA-T106
Q402 6-551-460-01 TRANSISTOR RSR025P03TL
< RESISTOR >
R402 1-216-295-91 SHORT CHIP 0
R404 1-216-295-91 SHORT CHIP 0
R406 1-216-821-11 METAL CHIP 1K 5% 1/10W
R411 1-216-821-11 METAL CHIP 1K 5% 1/10W
R415 1-216-841-11 METAL CHIP 47K 5% 1/10W
R417 1-216-839-11 METAL CHIP 33K 5% 1/10W
R420 1-216-843-11 METAL CHIP 68K 5% 1/10W
R421 1-216-821-11 METAL CHIP 1K 5% 1/10W
R422 1-216-841-11 METAL CHIP 47K 5% 1/10W
R423 1-216-841-11 METAL CHIP 47K 5% 1/10W
*************************************************************
R-USB BOARD
***********
< CONNECTOR >
CN150 1-842-128-11 USB CONNECTOR (
)
CN151 1-784-922-11 PIN, CONNECTOR 5P
*************************************************************
MISCELLANEOUS
**************
53 1-966-988-11 HARNESS (USB)
56 1-966-989-12 HARNESS (USB)
0 57 1-777-071-83 CORD, POWER (AEP)
0 57 1-835-078-31 CORD, POWER (UK)
0 57 1-837-308-11 CORD, POWER-SUPPLY (US, CND)
102 1-828-954-51 WIRE (FLAT TYPE) (9 CORE) (US, CND)
102 1-828-964-51 WIRE (FLAT TYPE) (11 CORE) (AEP, UK)
154 1-828-343-51 WIRE (FLAT TYPE) (15 CORE)
155 1-828-400-51 WIRE (FLAT TYPE) (27 CORE)
157 1-828-336-51 WIRE (FLAT TYPE) (15 CORE) (US, CND)
157 1-828-346-51 WIRE (FLAT TYPE) (17 CORE) (AEP, UK)
158 1-828-740-51 WIRE (FLAT TYPE) (18 CORE)
159 1-828-730-51 WIRE (FLAT TYPE) (16 CORE)
160 1-828-341-51 WIRE (FLAT TYPE) (15 CORE)
202 A-1750-926-A LOADING FOR SERVICE
0 206 8-820-430-02 DEVICE, OPTICAL (KEM-460AAA/C2RP)
207 1-837-660-51 WIRE (FLAT TYPE) (9 CORE)
208 1-837-658-51 WIRE (FLAT TYPE) (45 CORE)
209 1-837-659-51 WIRE (FLAT TYPE) (5 CORE)
0 F901 1-533-311-12 FUSE, GLASS (DIA.5) (8A/125V) (US, CND)
0 F901 1-576-232-51 FUSE (H.B.C.) (T5AH/250V) (AEP, UK)
M3001 1-787-931-11 DC FAN
TU1 1-693-781-11 TUNER (FM) (US, CND)
TU1 1-693-787-11 TUNER (FM) (AEP, UK)
