HBD-E370/E470/E570/E870/T57
12
2-3. MB-134 BOARD
1 connector (CN303)
2 two connectors
(CN601, CN602)
3 wire (flat type) (27 core)
(CN1505)
4 wire (flat type) (18 core)
(CN902)
5 wire (flat type) (16 core)
(CN901)
6 wire (flat type) (45 core)
(CN1401)
7 wire (flat type) (9 core)
(CN2460)
8 wire (flat type) (5 core)
(CN2470)
qa screw (B3 u 5)
qs two screws (BV3)
9 screw (BV3)
9 four screws (BV3)
q; clamp
qd MB
-
134 board
