35
(3) BOTTOM CABINET SECTION
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
101 4-230-507-01 FOOT (B)
102 A-4475-115-A BACK UP BOARD, COMPLETE (US, CND)
103 4-230-504-01 CABINET, BOTTOM
104 A-4473-612-A PHOTO SOCKET BOARD, COMPLETE
105 A-4475-113-A FRONT BOARD, COMPLETE
106 4-230-508-01 SCREW (3X30)
107 4-230-505-01 COVER, REAR
108 A-4475-114-A CENTER/REAR BOARD, COMPLETE (US, CND)
109 4-230-494-01 HOLDER, MAIN CHASSIS
110 4-229-497-01 WASHER, AC CORD
0111 1-783-531-51 CORD, POWER (US, CND)
M505 1-763-410-11 FAN, DC
0T001 1-435-714-11 TRANSFORMER, POWER (US, CND)
#16
#23
#23
#17
#16
T001
#4
#4
#22
#22
not supplied
#16
#16
#18
#18
#17
#18
#3
#5
#21
#4
#3
#17
M505
not supplied
not supplied
not supplied
#4
105
104
106
106
103
101
101
US, CND
110
109
107
108
111
102
not
supplied
not supplied
