87
HCD-C700/C900
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
D342 6-500-075-01 DIODE LI136V
D342 8-719-073-82 DIODE SFPB-76V
D343 6-500-075-01 DIODE LI136V
D343 8-719-073-82 DIODE SFPB-76V
D344 6-500-075-01 DIODE LI136V
D344 8-719-073-82 DIODE SFPB-76V
D345 6-500-075-01 DIODE LI136V
D345 8-719-073-82 DIODE SFPB-76V
D351 8-719-404-50 DIODE MA111-TX (US, CND, MX)
D370 6-500-060-01 DIODE P6SMB36AT3
D371 6-500-060-01 DIODE P6SMB36AT3
D372 6-500-060-01 DIODE P6SMB36AT3
D373 6-500-060-01 DIODE P6SMB36AT3
D374 6-500-060-01 DIODE P6SMB36AT3
D375 6-500-060-01 DIODE P6SMB36AT3
D380 6-500-060-01 DIODE P6SMB36AT3
D381 6-500-060-01 DIODE P6SMB36AT3
D382 6-500-060-01 DIODE P6SMB36AT3
D383 6-500-060-01 DIODE P6SMB36AT3
D384 6-500-060-01 DIODE P6SMB36AT3
D385 6-500-060-01 DIODE P6SMB36AT3
< EARTH >
EB301 1-537-770-11 TERMINAL BOARD, GROUND
EB302 1-537-770-11 TERMINAL BOARD, GROUND
< FERRITE BEAD >
FB300 1-469-760-21 INDUCTOR 0uH (US, CND, MX)
FB301 1-469-760-21 INDUCTOR 0uH (US, CND, MX)
FB303 1-400-160-51 INDUCTOR 0uH (US, CND, MX)
FB304 1-469-760-21 INDUCTOR 0uH (US, CND, MX)
FB307 1-469-760-21 INDUCTOR 0uH (US, CND, MX)
FB308 1-469-760-21 INDUCTOR 0uH (US, CND, MX)
FB309 1-400-160-51 INDUCTOR 0uH (US, CND, MX)
FB312 1-400-160-51 INDUCTOR 0uH (US, CND, MX)
FB313 1-400-160-51 INDUCTOR 0uH (US, CND, MX)
FB314 1-469-760-21 INDUCTOR 0uH (US, CND, MX)
FB315 1-469-760-21 INDUCTOR 0uH (US, CND, MX)
FB318 1-400-160-51 INDUCTOR 0uH (US, CND, MX)
FB320 1-400-160-51 INDUCTOR 0uH (US, CND, MX)
FB365 1-400-160-51 INDUCTOR 0uH
< IC >
IC300 8-759-834-29 IC MC74VHC1G04DFT1
IC301 6-700-277-01 IC CXD9646Z
IC302 8-759-533-85 IC BA05FP-E2
IC303 8-759-583-47 IC uPC2933T-E2
IC304 6-700-277-01 IC CXD9646Z
IC305 6-700-279-01 IC CXD9634AQ
IC306 6-700-277-01 IC CXD9646Z
IC307 6-700-277-01 IC CXD9646Z
IC308 6-700-279-01 IC CXD9634AQ
IC309 6-700-277-01 IC CXD9646Z
IC310 6-700-279-01 IC CXD9634AQ
IC311 6-700-277-01 IC CXD9646Z
IC312 8-759-834-30 IC MC74VHC1G08DFT1
< JACK >
J401 1-694-656-11 TERMINAL BOARD (6CH SPEAKER)
< COIL >
L300 1-469-525-91 INDUCTOR 10uH
L302 1-412-939-11 INDUCTOR 1uH (US, CND, MX)
L302 1-412-940-21 INDUCTOR 1.2uH (EXCEPT US, CND, MX)
L401 1-424-777-11 INDUCTOR 10uH
L402 1-424-777-11 INDUCTOR 10uH
L403 1-424-777-11 INDUCTOR 10uH
L404 1-424-777-11 INDUCTOR 10uH
L405 1-424-777-11 INDUCTOR 10uH
L406 1-424-777-11 INDUCTOR 10uH
< TRANSISTOR >
Q301 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
(US, CND, MX)
< RESISTOR >
R300 1-216-833-11 METAL CHIP 10K 5% 1/16W
R301 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R302 1-216-857-11 METAL CHIP 1M 5% 1/16W
R303 1-216-833-11 METAL CHIP 10K 5% 1/16W
R304 1-216-801-11 METAL CHIP 22 5% 1/16W
R305 1-216-801-11 METAL CHIP 22 5% 1/16W
R307 1-216-801-11 METAL CHIP 22 5% 1/16W
R308 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R309 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R310 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R311 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R312 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R313 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R315 1-216-809-11 METAL CHIP 100 5% 1/16W
R316 1-216-809-11 METAL CHIP 100 5% 1/16W
R317 1-216-809-11 METAL CHIP 100 5% 1/16W
R318 1-216-809-11 METAL CHIP 100 5% 1/16W
R319 1-216-809-11 METAL CHIP 100 5% 1/16W
R320 1-216-801-11 METAL CHIP 22 5% 1/16W
R321 1-216-801-11 METAL CHIP 22 5% 1/16W
R322 1-216-803-11 METAL CHIP 33 5% 1/16W
R325 1-216-801-11 METAL CHIP 22 5% 1/16W
R330 1-216-801-11 METAL CHIP 22 5% 1/16W
R333 1-216-801-11 METAL CHIP 22 5% 1/16W
R334 1-216-820-11 METAL CHIP 820 5% 1/16W
R335 1-216-801-11 METAL CHIP 22 5% 1/16W
R336 1-216-820-11 METAL CHIP 820 5% 1/16W
R337 1-216-833-11 METAL CHIP 10K 5% 1/16W
R338 1-216-820-11 METAL CHIP 820 5% 1/16W
R339 1-216-814-11 METAL CHIP 270 5% 1/16W
R340 1-216-814-11 METAL CHIP 270 5% 1/16W
R341 1-216-814-11 METAL CHIP 270 5% 1/16W
R342 1-216-814-11 METAL CHIP 270 5% 1/16W
R343 1-216-801-11 METAL CHIP 22 5% 1/16W
R344 1-216-814-11 METAL CHIP 270 5% 1/16W
R346 1-216-295-00 SHORT 0
R347 1-216-295-00 SHORT 0
R348 1-216-801-11 METAL CHIP 22 5% 1/16W
R349 1-216-801-11 METAL CHIP 22 5% 1/16W
R350 1-216-801-11 METAL CHIP 22 5% 1/16W
R401 1-216-049-11 RES-CHIP 1K 5% 1/10W
R402 1-216-049-11 RES-CHIP 1K 5% 1/10W
R415 1-216-295-00 SHORT 0
AMP
To Next Page
