Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
< RELAY >
RY301 1-515-920-11 RELAY (24V) (US, CND)
RY301 1-755-170-11 RELAY (12V) (EXCEPT US, CND)
RY302 1-515-920-11 RELAY (24V) (US, CND)
RY302 1-755-170-11 RELAY (12V) (EXCEPT US, CND)
RY303 1-515-920-11 RELAY (24V) (US, CND)
RY303 1-755-170-11 RELAY (12V) (EXCEPT US, CND)
< VIBRATOR >
X300 1-795-286-21 VIBRATOR, CRYSTAL (49.152MHz)
************************************************************
1-683-013-11 COMPONENT BOARD
*****************
< CAPACITOR >
C742 1-126-933-11 ELECT 100uF 20.00% 16V
C743 1-128-551-11 ELECT 22uF 20.00% 25V
C744 1-126-933-11 ELECT 100uF 20.00% 16V
C745 1-128-551-11 ELECT 22uF 20.00% 25V
C746 1-126-933-11 ELECT 100uF 20.00% 16V
C747 1-128-551-11 ELECT 22uF 20.00% 25V
C758 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C759 1-126-933-11 ELECT 100uF 20.00% 16V
< CONNECTOR >
* CN702 1-568-944-11 PIN, CONNECTOR 6P
< IC >
IC703 8-759-522-11 IC BA7660FS-E2
< JACK >
J666 1-815-814-11 JACK, PIN 3P (COMPONENT VIDEO OUT)
< RESISTOR >
R729 1-218-285-11 RES-CHIP 75 5% 1/16W
R730 1-218-285-11 RES-CHIP 75 5% 1/16W
R731 1-218-285-11 RES-CHIP 75 5% 1/16W
************************************************************
1-675-722-21 CONNECTOR BOARD
*****************
< CONNECTOR >
CN701 1-770-169-11 CONNECTOR, FFC/FPC 17P
< TRANSISTOR >
Q701 8-729-029-66 TRANSISTOR RT1N141S-TP
< RESISTOR >
R707 1-249-424-11 CARBON 3.9K 5% 1/4W F
R708 1-249-417-11 CARBON 1K 5% 1/4W F
R709 1-249-429-11 CARBON 10K 5% 1/4W
************************************************************
1-675-729-21 CLAMP MOTOR BOARD
*******************
< CAPACITOR >
C701 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C702 1-126-964-11 ELECT 10uF 20.00% 50V
C706 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C711 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
< CONNECTOR >
* CN712 1-568-954-11 PIN, CONNECTOR 5P
< DIODE >
D701 8-719-109-69 DIODE MTZJ-T-77-3.6B
< IC >
IC701 8-759-633-65 IC M54641L
< RESISTOR >
R701 1-249-411-11 CARBON 330 5% 1/4W
R702 1-249-401-11 CARBON 47 5% 1/4W F
************************************************************
1-681-998-11 DDCON-1089 BOARD
*****************
< CAPACITOR >
C820 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C821 1-126-964-11 ELECT 10uF 20.00% 50V
C822 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C823 1-126-964-11 ELECT 10uF 20.00% 50V
C826 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
< CONNECTOR >
* CN806 1-568-943-11 PIN, CONNECTOR 5P
< DIODE >
D806 8-719-404-50 DIODE MA111-TX
D807 8-719-404-50 DIODE MA111-TX
D808 8-719-404-50 DIODE MA111-TX
D809 8-719-404-50 DIODE MA111-TX
D810 8-719-069-56 DIODE UDZSTE-176.2B
< COIL >
L801 1-412-959-11 INDUCTOR 47uH
< TRANSISTOR >
Q803 8-729-808-42 TRANSISTOR 2SD1624-T-TD
Q804 8-729-808-42 TRANSISTOR 2SD1624-T-TD
< RESISTOR >
R850 1-216-828-11 METAL CHIP 3.9K 5% 1/16W
R855 1-216-809-11 METAL CHIP 100 5% 1/16W
R874 1-216-839-11 METAL CHIP 33K 5% 1/16W
< TRANSFORMER >
0T801 1-437-416-11 TRANSFORMER, DC-DC CONVERTER
************************************************************
AMP COMPONENT CONNECTOR CLAMP MOTOR DDCON-1089
