89
HCD-C700/C900
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
A-4726-385-A DS-1089 BOARD, COMPLETE (C700:US, C900)
A-4726-822-A DS-1089 BOARD, COMPLETE
(C700:CND, AEP, UK, E, MY, SP, HK, MX, AUS)
***********************
4-234-932-01 BUTTON (DVD)
4-931-757-31 SCREW(DIA.2.6X8)(IT3B),TAPPING
< CONNECTOR >
* CN811 1-568-950-11 PIN, CONNECTOR 12P
< DIODE >
D801 8-719-057-29 DIODE SML78423C-TP15 (DISC 1)
D802 8-719-057-29 DIODE SML78423C-TP15 (DISC 2)
D803 8-719-057-29 DIODE SML78423C-TP15 (DISC 3)
D804 8-719-057-29 DIODE SML78423C-TP15 (DISC 4)
D805 8-719-057-29 DIODE SML78423C-TP15 (DISC 5)
< RESISTOR >
R816 1-216-811-11 METAL CHIP 150 5% 1/16W
R817 1-216-811-11 METAL CHIP 150 5% 1/16W
R818 1-216-811-11 METAL CHIP 150 5% 1/16W
R819 1-216-811-11 METAL CHIP 150 5% 1/16W
R820 1-216-811-11 METAL CHIP 150 5% 1/16W
R821 1-216-811-11 METAL CHIP 150 5% 1/16W
R822 1-216-811-11 METAL CHIP 150 5% 1/16W
R823 1-216-811-11 METAL CHIP 150 5% 1/16W
R824 1-216-811-11 METAL CHIP 150 5% 1/16W
R825 1-216-811-11 METAL CHIP 150 5% 1/16W
R826 1-216-841-11 METAL CHIP 47K 5% 1/16W
R827 1-216-835-11 METAL CHIP 15K 5% 1/16W
R828 1-216-832-11 METAL CHIP 8.2K 5% 1/16W
R829 1-216-826-11 METAL CHIP 2.7K 5% 1/16W
(US, CND)
R829 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
(EXCEPT US, CND)
R830 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R831 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R832 1-216-824-11 METAL CHIP 1.8K 5% 1/16W
R833 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R834 1-216-821-11 METAL CHIP 1K 5% 1/16W
R835 1-216-809-11 METAL CHIP 100 5% 1/16W
< SWITCH >
S811 1-571-760-11 SWITCH, KEY BOARD (DISC 1)
S812 1-571-760-11 SWITCH, KEY BOARD (A)
S813 1-571-760-11 SWITCH, KEY BOARD (DISC 2)
S814 1-571-760-11 SWITCH, KEY BOARD (A)
S815 1-571-760-11 SWITCH, KEY BOARD (DISC 3)
S816 1-571-760-11 SWITCH, KEY BOARD (A)
S817 1-571-760-11 SWITCH, KEY BOARD (DISC 4)
S818 1-571-760-11 SWITCH, KEY BOARD (A)
S819 1-571-760-11 SWITCH, KEY BOARD (DISC 5)
S820 1-571-760-11 SWITCH, KEY BOARD (A)
************************************************************
A-4726-913-A DVD BOARD, COMPLETE (C900)
A-4726-938-A DVD BOARD, COMPLETE (C700:US)
A-4726-940-A DVD BOARD, COMPLETE (C700:CND)
A-4727-011-A DVD BOARD, COMPLETE (AEP, UK)
A-4727-016-A DVD BOARD, COMPLETE (HK, SP)
A-4727-018-A DVD BOARD, COMPLETE (E, AUS)
A-4727-059-A DVD BOARD, COMPLETE (MX)
********************
< CAPACITOR >
C001 1-165-798-21 CAP, CHIP ELECT 100uF
C003 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C004 1-126-204-11 ELECT CHIP 47uF 20% 16V
C005 1-126-246-11 ELECT CHIP 220uF 20% 4V
C006 1-126-204-11 ELECT CHIP 47uF 20% 16V
C007 1-164-850-11 CERAMIC CHIP 10PF 0.50PF 16V
C008 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C009 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C010 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C011 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C012 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C013 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C014 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C015 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C016 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C017 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C018 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C019 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C103 1-164-947-11 CERAMIC CHIP 0.01uF 16V
C104 1-126-209-11 ELECT CHIP 100uF 20.00% 4V
C105 1-164-947-11 CERAMIC CHIP 0.01uF 16V
C106 1-164-947-11 CERAMIC CHIP 0.01uF 16V
C107 1-164-858-11 CERAMIC CHIP 22PF 5.00% 16V
(US, CND)
C107 1-164-852-11 CERAMIC CHIP 12PF 5.00% 16V
(EXCEPT US, CND)
C108 1-164-858-11 CERAMIC CHIP 22PF 5.00% 16V
(US, CND)
C108 1-164-852-11 CERAMIC CHIP 12PF 5.00% 16V
(EXCEPT US, CND)
C109 1-164-947-11 CERAMIC CHIP 0.01uF 16V
C110 1-126-209-11 ELECT CHIP 100uF 20.00% 4V
C111 1-164-947-11 CERAMIC CHIP 0.01uF 16V
C112 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C113 1-164-947-11 CERAMIC CHIP 0.01uF 16V
C114 1-164-947-11 CERAMIC CHIP 0.01uF 16V
C116 1-164-947-11 CERAMIC CHIP 0.01uF 16V
C119 1-164-947-11 CERAMIC CHIP 0.01uF 16V
C124 1-164-947-11 CERAMIC CHIP 0.01uF 16V
C201 1-164-947-11 CERAMIC CHIP 0.01uF 16V
C202 1-164-947-11 CERAMIC CHIP 0.01uF 16V
C203 1-164-947-11 CERAMIC CHIP 0.01uF 16V
C204 1-164-947-11 CERAMIC CHIP 0.01uF 16V
C205 1-164-947-11 CERAMIC CHIP 0.01uF 16V
DS-1089 DVD
