HCD-C700/C900
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
R703 1-218-285-11 RES-CHIP 75 5% 1/16W
(US)
R704 1-218-285-11 RES-CHIP 75 5% 1/16W
(US)
R704 1-216-022-00 METAL CHIP 75 5% 1/10W
(EXCEPT US)
R705 1-218-285-11 RES-CHIP 75 5% 1/16W
(US)
R705 1-216-022-00 METAL CHIP 75 5% 1/10W
(EXCEPT US)
R706 1-218-285-11 RES-CHIP 75 5% 1/16W
(US)
R706 1-216-022-00 METAL CHIP 75 5% 1/10W
(EXCEPT US)
R707 1-218-285-11 RES-CHIP 75 5% 1/16W
(US)
R707 1-216-022-00 METAL CHIP 75 5% 1/10W
(EXCEPT US)
R708 1-216-809-11 METAL CHIP 100 5% 1/16W
(US)
R708 1-216-025-11 RES-CHIP 100 5% 1/10W
(EXCEPT US)
R709 1-218-285-11 RES-CHIP 75 5% 1/16W
(US)
R709 1-216-022-00 METAL CHIP 75 5% 1/10W
(EXCEPT US)
R711 1-216-837-11 METAL CHIP 22K 5% 1/16W
(US)
R711 1-216-081-00 METAL CHIP 22K 5% 1/10W
(EXCEPT US)
R712 1-216-821-11 METAL CHIP 1K 5% 1/16W
(US)
R713 1-216-837-11 METAL CHIP 22K 5% 1/16W
(US)
R713 1-216-081-00 METAL CHIP 22K 5% 1/10W
(EXCEPT US)
R714 1-216-833-11 METAL CHIP 10K 5% 1/16W
(US)
R714 1-216-073-00 RES-CHIP 10K 5% 1/10W
(EXCEPT US)
R716 1-216-815-11 METAL CHIP 330 5% 1/16W
(US)
R716 1-216-037-00 METAL CHIP 330 5% 1/10W
(EXCEPT US)
R717 1-216-833-11 METAL CHIP 10K 5% 1/16W
(US)
R717 1-216-073-91 RES-CHIP 10K 5% 1/10W
(EXCEPT US)
R718 1-216-833-11 METAL CHIP 10K 5% 1/16W
(US)
R718 1-216-073-00 RES-CHIP 10K 5% 1/10W
(EXCEPT US)
R719 1-216-817-11 METAL CHIP 470 5% 1/16W
(US)
R719 1-216-041-00 METAL CHIP 470 5% 1/10W
(EXCEPT US)
R720 1-216-817-11 METAL CHIP 470 5% 1/16W
(US)
R720 1-216-041-00 METAL CHIP 470 5% 1/10W
(EXCEPT US)
R721 1-216-833-11 METAL CHIP 10K 5% 1/16W
(US)
R721 1-216-073-00 RES-CHIP 10K 5% 1/10W
(EXCEPT US)
R722 1-216-833-11 METAL CHIP 10K 5% 1/16W
(US)
R722 1-216-073-00 RES-CHIP 10K 5% 1/10W
(EXCEPT US)
R723 1-216-833-11 METAL CHIP 10K 5% 1/16W
(US)
R723 1-216-073-00 RES-CHIP 10K 5% 1/10W
(EXCEPT US)
R727 1-218-289-11 RES-CHIP 510 5% 1/16W
R728 1-218-289-11 RES-CHIP 510 5% 1/16W
< VIBRATOR >
X601 1-579-242-41 VIBRATOR, CRYSTAL (4.332MHz) (AEP, UK)
************************************************************
1-675-728-21 LOAD MOTOR BOARD
******************
< CAPACITOR >
C703 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C704 1-126-964-11 ELECT 10uF 20.00% 50V
C705 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C712 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
< CONNECTOR >
* CN713 1-568-954-11 PIN, CONNECTOR 5P
< DIODE >
D702 8-719-109-85 DIODE MTZJ-T-77-5.1B
< IC >
IC702 8-759-633-65 IC M54641L
< RESISTOR >
R703 1-249-411-11 CARBON 330 5% 1/4W
R704 1-249-401-11 CARBON 47 5% 1/4W F
************************************************************
1-675-725-21 OUT SW BOARD
*************
< CONNECTOR >
* CN709 1-568-943-11 PIN, CONNECTOR 5P
CN715 1-506-481-11 PIN, CONNECTOR 2P
< SWITCH >
S701 1-771-218-11 SWITCH, MICRO (MID OUT)
S702 1-771-218-11 SWITCH, MICRO (LID)
S708 1-771-218-11 SWITCH, MICRO (OUT)
************************************************************
I/O LOAD MOTOR OUT SW
To Next Page
