104
HCD-C700/C900
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
A-4726-381-A POWER BOARD, COMPLETE (C700:US)
A-4726-832-A POWER BOARD, COMPLETE (C700:CND)
A-4726-912-A POWER BOARD, COMPLETE (C900:US)
A-4726-919-A POWER BOARD, COMPLETE (C900:CND)
A-4727-010-A POWER BOARD, COMPLETE
(AEP, UK, E, MY, SP, HK, AUS)
A-4727-058-A POWER BOARD, COMPLETE (MX)
***********************
< CAPACITOR >
0C901 1-117-703-11 CERAMIC 0.0047uF 99% 250V
0C902 1-115-165-11 FILM 0.1uF 20.00% 275V
0C903 1-162-290-31 CERAMIC 470PF 10% 50V
0C904 1-104-705-11 MYLAR 0.1uF 20.00% 250V
(US)
0C904 1-113-915-11 CERAMIC 0.001uF 20.00% 250V
(AEP, UK, E, MY, SP, HK, MX, AUS)
0C904 1-115-165-11 FILM 0.1uF 20.00% 275V
(CND)
0C905 1-113-920-11 CERAMIC 0.0022uF 20.00% 250V
(US)
0C905 1-113-915-11 CERAMIC 0.001uF 20.00% 250V
(EXCEPT US)
0C906 1-113-920-11 CERAMIC 0.0022uF 20.00% 250V
(US)
0C906 1-113-915-11 CERAMIC 0.001uF 20.00% 250V
(EXCEPT US)
0C907 1-164-159-21 CERAMIC 0.1uF 50V
(US, CND, MX)
0C907 1-164-159-11 CERAMIC 0.1uF 50V
(EXCEPT US, CND, MX)
0C908 1-113-920-11 CERAMIC 0.0022uF 20.00% 250V
(US)
0C908 1-104-705-11 MYLAR 0.1uF 20.00% 250V
(AEP, UK, E, MY, SP, HK, MX, AUS)
0C908 1-113-915-11 CERAMIC 0.001uF 20.00% 250V
(CND)
0C909 1-113-915-11 CERAMIC 0.001uF 20.00% 250V
(EXCEPT US, CND)
0C910 1-113-915-11 CERAMIC 0.001uF 20.00% 250V
(EXCEPT US, CND)
0C911 1-113-915-11 CERAMIC 0.001uF 20.00% 250V
(EXCEPT US, CND)
0C912 1-137-994-11 ELECT 820uF 20% 200V
(US)
0C913 1-136-203-11 FILM 10000PF 5.00% 630V
0C914 1-126-967-11 ELECT 47uF 20.00% 50V
0C915 1-162-286-21 CERAMIC 220PF 10.00% 50V
(US, CND, MX)
0C915 1-162-286-31 CERAMIC 220PF 10% 50V
(US, CND, MX)
0C916 1-117-454-11 FILM 4700PF 5.00% 630V
(US, CND, MX)
0C916 1-137-751-21 FILM 2200PF 3% 800V
(EXCEPT US, CND, MX)
C917 1-113-907-51 CERAMIC 0.0022uF 99% 250V
C918 1-115-339-11 CERAMIC CHIP 0.1uF 10.00% 50V
C919 1-115-789-11 ELECT 1000uF 20.00% 25V
C920 1-136-203-11 FILM 10000PF 5.00% 630V
C921 1-115-819-11 ELECT 2200uF 20.00% 35V (US)
C921 1-110-617-11 ELECT 2200uF 20.00% 50V
(AEP, UK, E, MY, SP, HK, MX, AUS)
C921 1-110-602-51 ELECT 1800uF 20.00% 25V
(CND)
C922 1-128-560-11 ELECT 22uF 20.00% 100V
(US)
C922 1-126-965-11 ELECT 22uF 20.00% 50V
(EXCEPT US)
C923 1-115-819-11 ELECT 2200uF 20.00% 35V (US)
C923 1-110-617-11 ELECT 2200uF 20.00% 50V
(AEP, UK, E, MY, SP, HK, MX, AUS)
C923 1-110-602-51 ELECT 1800uF 20.00% 25V
(CND)
C924 1-126-953-11 ELECT 2200uF 20.00% 35V
(US, CND)
C924 1-126-972-11 ELECT 1000uF 20.00% 50V
(EXCEPT US, CND)
C925 1-126-960-11 ELECT 1uF 20.00% 50V
C926 1-115-339-11 CERAMIC CHIP 0.1uF 10.00% 50V
C927 1-115-339-11 CERAMIC CHIP 0.1uF 10.00% 50V
C928 1-126-916-11 ELECT 1000uF 20.00% 6.3V
C929 1-104-665-11 ELECT 100uF 20.00% 10V
C930 1-115-339-11 CERAMIC CHIP 0.1uF 10.00% 50V
C931 1-126-916-11 ELECT 1000uF 20.00% 6.3V
C932 1-115-339-11 CERAMIC CHIP 0.1uF 10.00% 50V
C933 1-126-768-11 ELECT 2200uF 20.00% 16V (US)
C933 1-126-942-61 ELECT 1000uF 20.00% 16V
(CND, MX)
C936 1-163-809-11 CERAMIC CHIP 0.047uF 10% 25V
< CONNECTOR >
CN901 1-564-321-00 PIN, CONNECTOR 2P
* CN902 1-564-321-21 PIN, CONNECTOR 2P (US, CND, MX)
CN902 1-564-321-00 PIN, CONNECTOR 2P (EXCEPT US, CND, MX)
* CN904 1-564-778-11 PLUG, CONNECTOR (2.5MM) 4P
* CN905 1-568-939-11 PIN, CONNECTOR 12P
< DIODE >
0D901 8-719-991-33 DIODE 1SS133T-77 (US, CND, MX)
0D901 8-719-911-19 DIODE 1SS133T-72 (EXCEPT US, CND, MX)
0D902 8-719-022-92 DIODE RBV-604
0D903 8-719-010-98 DIODE MTZJ-T-77-22A (US)
0D903 8-719-110-48 DIODE MTZJ-T-72-18A
(AEP, UK, E, MY, SP, HK, AUS)
0D903 8-719-922-03 DIODE MTZJ-T-77-18C (CND, MX)
0D904 8-719-110-61 DIODE MTZJ-T-77-24A (US, CND, MX)
0D904 8-719-947-81 DIODE MTZJ-T-72-24A (US, CND, MX)
0D905 8-719-200-91 DIODE 11EQS10-TA1 (US, CND, MX)
0D905 8-719-200-93 DIODE 11EQS10-TA2 (EXCEPT US, CND, MX)
0D906 8-719-200-91 DIODE 11EQS10-TA1 (US, CND, MX)
0D906 8-719-200-93 DIODE 11EQS10-TA2 (EXCEPT US, CND, MX)
0D907 8-719-200-91 DIODE 11EQS10-TA1 (US, CND, MX)
0D907 8-719-200-93 DIODE 11EQS10-TA2 (EXCEPT US, CND, MX)
0D908 8-719-080-26 DIODE SARS01V0 (US, CND, MX)
POWER
