105
HCD-C700/C900
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
D909 8-719-079-46 DIODE FMB-G16L
D910 8-719-200-91 DIODE 11EQS10-TA1 (US, CND, MX)
D910 8-719-200-93 DIODE 11EQS10-TA2 (EXCEPT US, CND, MX)
D911 8-719-313-14 DIODE FML-22S (US, CND, MX)
D912 8-719-110-42 DIODE MTZJ-T-77-15C
D913 8-719-404-50 DIODE MA111-TX
D914 8-719-210-21 DIODE 11EQS04-TA1B
D915 8-719-404-50 DIODE MA111-TX
D916 8-719-210-21 DIODE 11EQS04-TA1B
D917 8-719-200-82 DIODE 11ES2-NTA1B (US, CND, MX)
D917 8-719-024-99 DIODE 11ES2-NTA2B (EXCEPT US, CND, MX)
D918 8-719-404-50 DIODE MA111-TX
D920 1-216-296-11 SHORT 0 (US, CND, MX)
D921 1-216-296-11 SHORT 0 (US, CND, MX)
< EARTH >
EB901 1-537-770-11 TERMINAL BOARD, GROUND
EB902 1-537-770-11 TERMINAL BOARD, GROUND
< FUSE >
0F901 1-533-453-11 FUSE, GLASS TUBE (DIA. 5) 5A/125V
(US, CND, MX)
0F901 1-533-471-11 FUSE, GLASS TUBE (DIA. 5) T3.15A/250V
(EXSEPT US, CND, MX)
< FERRITE BEAD >
FB901 1-412-473-41 INDUCTOR 0uH
< FUSE HOLDER >
FH901 1-533-313-11 HOLDER, FUSE
FH902 1-533-313-11 HOLDER, FUSE
< IC >
0IC901 6-700-162-01 IC STR-F6426S (US, CND, MX)
0IC901 8-749-017-79 IC STR-F6676 (EXCEPT US, CND, MX)
IC902 6-700-388-01 IC SE-B2
IC903 6-700-812-01 IC SI-8050JF (US, CND, MX)
IC903 8-759-474-09 IC SI-8050S-LF1101 (EXCEPT US, CND, MX)
IC904 8-759-332-29 IC M51945BL
IC905 8-759-450-47 IC BA05T
IC906 6-700-813-01 IC SI-8033JF (US, CND, MX)
IC906 8-759-659-28 IC SI-8033S (EXCEPT US, CND, MX)
IC907 8-759-390-72 IC TC4S584F(TE85R) (US, CND, MX)
IC907 8-759-257-96 IC TC7S14FU(TE85R) (EXCEPT US, CND, MX)
< COIL >
L901 1-424-860-11 INDUCTOR 10uH (US, CND, MX)
L901 1-419-505-11 INDUCTOR 10uH (EXCEPT US, CND, MX)
L902 1-419-253-11 INDUCTOR 100uH (EXCEPT CND)
L902 1-419-506-11 INDUCTOR 150uH (CND)
L903 1-419-253-11 INDUCTOR 100uH (EXCEPT CND)
L903 1-419-506-11 INDUCTOR 150uH (CND)
L904 1-414-398-11 INDUCTOR 10uH
L905 1-414-398-11 INDUCTOR 10uH
L906 1-414-398-11 INDUCTOR 10uH
L907 1-414-398-11 INDUCTOR 10uH
L908 1-414-398-11 INDUCTOR 10uH
< LINE FILTER >
0LF901 1-424-930-11 COIL, LINE FILTER
< PHOTO COUPLER >
0PC901 8-749-019-04 PHOTO COUPLER TLP421
0PC902 8-749-019-04 PHOTO COUPLER TLP421
< TRANSISTOR >
0Q901 8-729-119-76 TRANSISTOR 2SA1175TP-HFE
0Q902 8-729-140-04 TRANSISTOR 2SB1116A-TP-LK
0Q903 8-729-111-29 TRANSISTOR 2SD1616A-TP-LK (C700)
0Q903 8-719-922-03 DIODE MTZJ-T-77-18C (C900)
Q905 8-729-900-53 TRANSISTOR DTC114EKA-T146
Q906 8-729-900-53 TRANSISTOR DTC114EKA-T146
Q907 8-729-030-19 TRANSISTOR 2SB1640(TP) (US, CND, MX)
Q907 8-729-209-60 TRANSISTOR 2SB1375
(EXCEPT US, CND, MX)
Q908 8-729-900-53 TRANSISTOR DTC114EKA-T146
Q909 8-729-027-49 TRANSISTOR DTC123EKA-T146
Q910 8-729-900-53 TRANSISTOR DTC114EKA-T146
Q911 8-729-900-53 TRANSISTOR DTC114EKA-T146 (US)
Q915 8-729-900-53 TRANSISTOR DTC114EKA-T146
(US, CND, MX)
Q915 8-729-027-23 TRANSISTOR DTA114EKA-T146
(EXCEPT US, CND, MX)
< RESISTOR >
0R900 1-219-237-11 SOLID 3.3M 20% 1/2W
(CND)
0R900 1-202-725-00 SOLID 3.3M 10% 1/2W
(US)
0R900 1-219-237-91 SOLID 3.3M 20% 1/2W
(AEP, UK, E, MY, SP, HK, MX, AUS)
0R901 1-249-415-11 CARBON 680 5% 1/4W F
0R902 1-243-979-31 METAL OXIDE 0.1 5% 2W (US)
0R902 1-243-979-11 METAL OXIDE 0.1 5% 2W
(EXCEPT US)
0R903 1-243-979-31 METAL OXIDE 0.1 5% 2W (US)
0R904 1-247-881-00 CARBON 120K 5% 1/4W
0R905 1-249-439-11 CARBON 68K 5% 1/4W
0R906 1-249-424-11 CARBON 3.9K 5% 1/4W F
0R907 1-249-425-11 CARBON 4.7K 5% 1/4W F
0R908 1-215-878-00 METAL OXIDE 33K 5% 1W
(US, CND, MX)
0R908 1-215-901-00 METAL OXIDE 33K 5% 2W
(EXCEPT US, CND, MX)
0R909 1-260-127-11 CARBON 220K 5% 1/2W
(US, CND, MX)
0R909 1-247-887-00 CARBON 220K 5% 1/4W
(EXCEPT US, CND, MX)
POWER
Ver 1.1 2002.03
To Next Page
