106
HCD-C700/C900
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
0R910 1-215-884-31 METAL OXIDE 47 5% 2W (US)
0R910 1-215-884-11 METAL OXIDE 47 5% 2W
(EXCEPT US)
0R911 1-249-425-11 CARBON 4.7K 5% 1/4W F
0R912 1-249-426-11 CARBON 5.6K 5% 1/4W
0R913 1-249-399-11 CARBON 33 5% 1/4W F
(US, CND, MX)
0R913 1-249-385-11 CARBON 2.2 5% 1/6W F
(EXCEPT US, CND, MX)
R914 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R915 1-216-826-11 METAL CHIP 2.7K 5% 1/16W
R916 1-249-421-11 CARBON 2.2K 5% 1/4W F
(US, CND, MX)
R916 1-249-420-11 CARBON 1.8K 5% 1/4W F
(EXCEPT US, CND, MX)
R917 1-249-420-11 CARBON 1.8K 5% 1/4W F
(US, CND, MX)
R917 1-249-422-11 CARBON 2.7K 5% 1/4W F
(EXCEPT US, CND, MX)
0R918 1-215-884-31 METAL OXIDE 47 5% 2W (US)
R919 1-249-429-11 CARBON 10K 5% 1/4W
(C700:US, CND, MX)
R919 1-249-433-11 CARBON 22K 5% 1/4W
(C900)
R919 1-249-431-11 CARBON 15K 5% 1/4W
(AEP, UK, E, MY, SP, HK, AUS)
R920 1-249-433-11 CARBON 22K 5% 1/4W
(US, CND, MX)
R920 1-249-421-11 CARBON 2.2K 5% 1/4W F
(EXCEPT US, CND, MX)
R921 1-216-853-11 METAL CHIP 470K 5% 1/16W
(C700:US, CND, MX)
R921 1-216-857-11 METAL CHIP 1M 5% 1/16W
(C900)
R921 1-216-850-11 METAL CHIP 270K 5% 1/16W
(AEP, UK, E, MY, SP, HK, AUS)
R922 1-216-843-11 METAL CHIP 68K 5% 1/16W
(C700:US, CND, MX)
R922 1-216-841-11 METAL CHIP 47K 5% 1/16W
(C900)
R922 1-216-845-11 METAL CHIP 100K 5% 1/16W
(AEP, UK, E, MY, SP, HK, AUS)
R923 1-216-833-11 METAL CHIP 10K 5% 1/16W
R924 1-216-818-11 METAL CHIP 560 5% 1/16W
(US, CND, MX)
R925 1-216-811-11 METAL CHIP 150 5% 1/16W
(US, CND, MX)
R925 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
(EXCEPT US, CND, MX)
R926 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R927 1-215-865-11 METAL OXIDE 220 5% 1W (US)
R927 1-249-417-11 CARBON 1K 5% 1/4W F
(EXCEPT US)
R928 1-216-841-11 METAL CHIP 47K 5% 1/16W
(US)
R928 1-216-837-11 METAL CHIP 22K 5% 1/16W
(EXCEPT US)
R929 1-216-809-11 METAL CHIP 100 5% 1/16W
R932 1-216-848-11 METAL CHIP 180K 5% 1/16W
(US)
R932 1-216-847-11 METAL CHIP 150K 5% 1/16W
(EXCEPT US)
R933 1-216-841-11 METAL CHIP 47K 5% 1/16W
(US)
R934 1-216-837-11 METAL CHIP 22K 5% 1/16W
(US, CND, MX)
R934 1-216-836-11 METAL CHIP 18K 5% 1/16W
(EXCEPT US, CND, MX)
< TRANSFORMER >
0T901 1-437-414-11 TRANSFORMER, POWER
< THERMISTOR >
0TH901 1-803-916-11 THERMISTOR, NTC
************************************************************
1-682-002-11 PW-1089 BOARD
**************
< DIODE >
D812 8-719-071-44 DIODE SELS5223C-TP15 (POWER)
< RESISTOR >
R804 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
************************************************************
A-4726-883-A RF-240 BOARD, COMPLETE
**********************
< CAPACITOR >
C001 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C002 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C005 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C006 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C007 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C008 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C009 1-124-779-00 ELECT CHIP 10uF 20% 16V
C015 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C016 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C017 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C018 1-115-416-11 CERAMIC CHIP 0.001uF 5.00% 25V
C019 1-164-739-11 CERAMIC CHIP 560PF 5.00% 50V
C021 1-124-779-00 ELECT CHIP 10uF 20% 16V
C022 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C023 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C024 1-115-416-11 CERAMIC CHIP 0.001uF 5.00% 25V
C025 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C026 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C027 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C028 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C031 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C032 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C033 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C034 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C035 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
POWER PW-1089 RF-240
