107
HCD-C700/C900
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
C036 1-165-176-11 CERAMIC CHIP 0.047uF 10.00% 16V
C038 1-165-176-11 CERAMIC CHIP 0.047uF 10.00% 16V
C039 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C040 1-164-217-11 CERAMIC CHIP 150PF 5.00% 50V
C043 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C044 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C046 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C047 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C048 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
< CONNECTOR >
CN001 1-766-835-11 CONNECTOR, FFC/FPC (ZIF) 26P
CN002 1-784-875-21 CONNECTOR,FFC(LIF(NON-ZIF))25P
CN003 1-784-861-11 CONNECTOR, FFC(LIF(NON-ZIF))9P
CN004 1-784-861-11 CONNECTOR, FFC(LIF(NON-ZIF))9P
< DIODE >
D001 8-719-988-61 DIODE 1SS355TE-17
D004 8-719-988-61 DIODE 1SS355TE-17
< IC >
IC001 8-759-828-02 IC SP3728AC
< COIL >
L001 1-412-031-11 INDUCTOR CHIP 47uH
L002 1-412-031-11 INDUCTOR CHIP 47uH
< TRANSISTOR >
Q001 8-729-903-46 TRANSISTOR 2SB1132-T100-QR
Q002 8-729-903-46 TRANSISTOR 2SB1132-T100-QR
< RESISTOR >
R002 1-216-809-11 METAL CHIP 100 5% 1/16W
R003 1-216-809-11 METAL CHIP 100 5% 1/16W
R005 1-216-845-11 METAL CHIP 100K 5% 1/16W
R006 1-216-838-11 METAL CHIP 27K 5% 1/16W
R007 1-216-803-11 METAL CHIP 33 5% 1/16W
R008 1-216-803-11 METAL CHIP 33 5% 1/16W
R009 1-216-821-11 METAL CHIP 1K 5% 1/16W
R010 1-216-841-11 METAL CHIP 47K 5% 1/16W
R011 1-216-809-11 METAL CHIP 100 5% 1/16W
R020 1-216-803-11 METAL CHIP 33 5% 1/16W
R023 1-216-803-11 METAL CHIP 33 5% 1/16W
R025 1-216-841-11 METAL CHIP 47K 5% 1/16W
R029 1-216-809-11 METAL CHIP 100 5% 1/16W
R037 1-216-834-11 METAL CHIP 12K 5% 1/16W
R038 1-216-861-11 METAL CHIP 2.2M 5% 1/16W
R045 1-216-809-11 METAL CHIP 100 5% 1/16W
************************************************************
1-675-726-21 SENSOR BOARD
*************
< CONNECTOR >
CN708 1-506-481-11 PIN, CONNECTOR 2P
< DIODE >
D704 8-719-055-84 DIODE GL528VS1 (DISC IN DETECT SENSOR)
< RESISTOR >
R711 1-249-415-11 CARBON 680 5% 1/4W F
************************************************************
1-675-727-21 SENSOR 2 BOARD
***************
4-964-461-02 HOLDER (SENSOR)
< TRANSISTOR >
Q703 8-729-921-53 PHOTO TRAN ISTOR PT483F1
************************************************************
1-682-000-11 SW-1089 BOARD
**************
< CONNECTOR >
CN810 1-506-481-11 PIN, CONNECTOR 2P
< RESISTOR >
R800 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R801 1-216-832-11 METAL CHIP 8.2K 5% 1/16W
R802 1-216-835-11 METAL CHIP 15K 5% 1/16W
R803 1-216-841-11 METAL CHIP 47K 5% 1/16W
< SWITCH >
S801 1-762-875-21 SWITCH, KEYBOARD (x)
S802 1-762-875-21 SWITCH, KEYBOARD (X)
S803 1-762-875-21 SWITCH, KEYBOARD (G)
S804 1-762-875-21 SWITCH, KEYBOARD (PRESET +/NEXT >)
S805 1-762-875-21 SWITCH, KEYBOARD (PRESET -/. PREV)
************************************************************
RF-240 SENSOR SENSOR 2 SW-1089
