108
HCD-C700/C900
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
MISCELLANEOUS
**************
05 1-775-789-91 CORD, POWER (MX)
05 1-783-532-11 CORD, POWER (US, CND)
05 1-690-608-11 CORD, POWER (AUS)
05 1-696-169-21 CORD, POWER (AEP, UK, E, MY, SP, HK)
52 1-823-082-11 CABLE, FLEXIBLE FLAT (13 CORE)
54 1-823-124-11 CABLE, FLEXIBLE FLAT (29 CORE)
55 1-823-355-11 CABLE, FLEXIBLE FLAT (13 CORE)
62 1-823-080-11 CABLE, FLEXIBLE FLAT (25 CORE)
63 1-823-083-11 CABLE, FLEXIBLE FLAT (9 CORE)
64 1-823-078-11 CABLE, FLEXIBLE FLAT (17 CORE)
65 1-823-125-11 CABLE, FLEXIBLE FLAT (12 CORE)
66 1-823-084-11 CABLE, FLEXIBLE FLAT (17 CORE)
108 1-786-210-11 SWITCH, POWER
114 1-823-081-11 CABLE, FLEXIBLE FLAT (17 CORE)
454 1-823-085-11 CABLE, FLEXIBLE FLAT (9 CORE)
455 1-823-072-11 CABLE, FLEXIBLE FLAT 26P
0458 8-820-144-06 OPTICAL PICK-UP KHM-240AAA
488 1-675-729-21 CLAMP MOTOR BOARD
M701 X-4950-341-1 MOTOR (CLAMP) ASSY
M702 X-4950-342-1 MOTOR (LOADING) ASSY
S707 1-418-045-01 ENCODER, ROTARY
(DISC TRAY ADDRESS DETECT)
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
**************
HARDWARE LIST
**************
#1 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
#2 7-685-548-14 SCREW +BTP 3X12 TYPE2 N-S
#3 7-682-547-09 SCREW +B 3X6
#4 3-229-336-01 SCREW, +BVWH TAPPING
#5 7-685-533-19 SCREW +BTP 2.6X6 TYPE2 N-S
