Sony HCD-C900 - Page 27

9
HCD-C700/C900
2-4. POWER BOARD
2.5. DVD MECHANISM DECK (CDM53K-DVBU7)
6 Wire
5 Screw,
+BVTP
(3 × 8)
7 Four screws,
+BVTP
(3 × 8)
4 Connector
(CN904)
1 Connector
(CN905)
2 Connector
(CN901)
3 Connector
(CN902)
8 POWER boar
d
7 Flexible flat cable
(25core) (CN002)
6 Flexible flat cable
(17core) (CN701)
8 Flexible flat cable
(9core) (CN004)
5 Four screws,
+BVTP
(3 × 8)
9 Mechanism deck
(CDM53K-DVBU7)
2 Two screws,
+BTP
(3 × 6)
4 MD cover
MD cover
MD cover
1 Two screws,
+BTP
(3 × 12)
3 Connector
(CN202)
Connector
(CN202)
HARNESS PROCESSING
HARNESS PROCESSING
