HCD-C700/C900
2-18. GEAR (CHUCKING)
PRECAUTION DURING
GEAR (CHUCKING) (2)
PRECAUTION DURING
GEAR (CHUCKING) (1)
OK
NG
3
Gear (chucking)
Rotary encoder (S707)
1
2
Gear
(chucking)
Rotary encoder (S707)
Rotary encoder
(S707)
Align with the slot of
rotary encoder.
Align marking
