Sony HCD-D290 - Page 38

– 38 –
SECTION 6
DIAGRAMS
• Circuit Board Location
TRANS board
PANEL board
TCB board
POWER AMP
board
TC-B SW board
CD-B1 SW board
CD-B2 SW board
CD-A SW board
LED board
TC-A SW
board
HEADPHONE-MIC
board
CD MOTOR board
BD LED board
AUDIO board
BD board
LEAF SWITCH
board
MOTOR board
DOOR SW board
MAIN board
