– 104 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
< RESISTOR >
R201 1-247-863-91 CARBON 22K 5% 1/4W
R202 1-249-411-11 CARBON 330 5% 1/4W
R203 1-249-437-11 CARBON 47K 5% 1/4W
************************************************************
* A-4673-765-A CD MOTOR BOARD, COMPLETE
*************************
< CAPACITOR >
C201 1-124-907-11 ELECT 10uF 20% 50V
C202 1-164-159-21 CERAMIC 0.1uF 50V
C203 1-124-907-11 ELECT 10uF 20% 50V
< CONNECTOR >
* CN201 1-568-947-11 PIN, CONNECTOR 9P
< IC >
IC201 8-759-365-94 IC TA8409S
< COIL >
L201 1-408-117-00 INDUCTOR 10uH
< RESISTOR >
R205 1-249-427-11 CARBON 6.8K 5% 1/4W
R206 1-249-425-11 CARBON 4.7K 5% 1/4W
< SWITCH >
S201 1-762-587-11 SWITCH, PUSH (1 KEY)
************************************************************
* 1-664-009-11 CD-A SW BOARD
*************
< DIODE >
D641 8-719-058-04 DIODE SEL5223S-TP15 (NON-STOP)
< RESISTOR >
R731 1-247-843-11 CARBON 3.3K 5% 1/4W
R732 1-249-425-11 CARBON 4.7K 5% 1/4W
R733 1-249-427-11 CARBON 6.8K 5% 1/4W
R734 1-249-429-11 CARBON 10K 5% 1/4W
R735 1-249-432-11 CARBON 18K 5% 1/4W
R736 1-249-436-11 CARBON 39K 5% 1/4W
R737 1-247-881-00 CARBON 120K 5% 1/4W
R741 1-247-807-31 CARBON 100 5% 1/4W
< SWITCH >
S661 1-554-303-21 SWITCH, TACTILE (DISC 1)
S662 1-554-303-21 SWITCH, TACTILE (DISC 2)
S663 1-554-303-21 SWITCH, TACTILE (DISC 3)
S664 1-554-303-21 SWITCH, TACTILE (DISC 4)
S665 1-554-303-21 SWITCH, TACTILE (DISC 5)
S666 1-554-303-21 SWITCH, TACTILE (FLASH)
S667 1-554-303-21 SWITCH, TACTILE (NON-STOP)
S668 1-554-303-21 SWITCH, TACTILE (LOOP)
************************************************************
* 1-664-010-11 CD-B1 SW BOARD
***************
< CONNECTOR >
* CN642 1-568-943-11 PIN, CONNECTOR 5P
< DIODE >
D645 8-719-058-03 DIODE SEL5423E-TP15 (· CD PLAY)
D646 8-719-057-97 DIODE SEL5923A-TP15 (P PAUSE)
D647 8-719-058-03 DIODE SEL5423E-TP15 (· CD PLAY)
< RESISTOR >
R745 1-249-419-11 CARBON 1.5K 5% 1/4W
R746 1-249-421-11 CARBON 2.2K 5% 1/4W
R747 1-247-843-11 CARBON 3.3K 5% 1/4W
R748 1-249-425-11 CARBON 4.7K 5% 1/4W
R749 1-247-807-31 CARBON 100 5% 1/4W
R750 1-247-807-31 CARBON 100 5% 1/4W
R751 1-247-807-31 CARBON 100 5% 1/4W
< SWITCH >
S676 1-554-303-21 SWITCH, TACTILE (·)
S677 1-554-303-21 SWITCH, TACTILE (p)
S678 1-554-303-21 SWITCH, TACTILE (P)
S679 1-554-303-21 SWITCH, TACTILE (DISC SKIP)
************************************************************
* 1-664-011-11 CD-B2 SW BOARD
**************
< RESISTOR >
R752 1-249-427-11 CARBON 6.8K 5% 1/4W
R753 1-249-429-11 CARBON 10K 5% 1/4W
R754 1-249-432-11 CARBON 18K 5% 1/4W
R755 1-249-436-11 CARBON 39K 5% 1/4W
R756 1-247-881-00 CARBON 120K 5% 1/4W
BD LED CD MOTOR CD-A SW CD-B1 SW CD-B2 SW
