– 106 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
* 1-664-017-11 LED BOARD
*********
< CONNECTOR >
CN671 1-506-481-11 PIN, CONNECTOR 2P
< DIODE >
D671 8-719-058-03 DIODE SEL5423E-TP15
D672 8-719-058-03 DIODE SEL5423E-TP15
D673 8-719-058-03 DIODE SEL5423E-TP15
D674 8-719-058-03 DIODE SEL5423E-TP15
< RESISTOR >
R791 1-249-412-11 CARBON 390 5% 1/4W
************************************************************
* A-4392-438-A MAIN BOARD, COMPLETE (US, CND)
* A-4392-457-A MAIN BOARD, COMPLETE (E, AR, MX)
* A-4392-706-A MAIN BOARD, COMPLETE (AUS, PX)
* A-4392-461-A MAIN BOARD, COMPLETE (AEP, UK)
* A-4392-703-A MAIN BOARD, COMPLETE (EE)
*********************
* 4-870-539-11 PLATE, GROUND
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
< CAPACITOR >
C101 1-162-288-31 CERAMIC 330PF 10% 50V
(AEP, UK, EE)
C102 1-162-282-31 CERAMIC 100PF 10% 50V
C103 1-162-282-31 CERAMIC 100PF 10% 50V
C104 1-126-962-11 ELECT 3.3uF 20% 50V
C105 1-162-600-11 CERAMIC 0.0047uF30% 16V
C106 1-162-301-11 CERAMIC 0.0015uF30% 16V
C107 1-126-956-91 ELECT 0.1uF 20% 50V
C108 1-126-967-11 ELECT 47uF 20% 10V
(AEP, UK, EE)
C109 1-164-159-21 CERAMIC 0.1uF 50V
(AEP, UK, EE)
C121 1-162-286-21 CERAMIC 220PF 10% 50V
C123 1-162-306-11 CERAMIC 0.01uF 20% 16V
C131 1-136-495-11 FILM 0.068uF 5% 50V
(AEP, UK, EE)
C132 1-136-495-11 FILM 0.068uF 5% 50V
(AEP, UK, EE)
C133 1-162-294-31 CERAMIC 0.001uF 10% 50V
(AEP, UK, EE)
C134 1-164-159-21 CERAMIC 0.1uF 50V
(AEP, UK, EE)
C151 1-162-288-31 CERAMIC 330PF 10% 50V
(AEP, UK, EE)
C152 1-162-282-31 CERAMIC 100PF 10% 50V
C153 1-162-282-31 CERAMIC 100PF 10% 50V
C154 1-126-962-11 ELECT 3.3uF 20% 50V
C155 1-162-600-11 CERAMIC 0.0047uF30% 16V
C156 1-162-301-11 CERAMIC 0.0015uF30% 16V
C157 1-126-956-91 ELECT 0.1uF 20% 50V
C158 1-126-967-11 ELECT 47uF 20% 10V
(AEP, UK, EE)
C171 1-162-286-21 CERAMIC 220PF 10% 50V
C173 1-162-306-11 CERAMIC 0.01uF 20% 16V
C181 1-136-495-11 FILM 0.068uF 5% 50V
(AEP, UK, EE)
C182 1-136-495-11 FILM 0.068uF 5% 50V
(AEP, UK, EE)
C183 1-162-294-31 CERAMIC 0.001uF 10% 50V
(AEP, UK, EE)
C184 1-164-159-21 CERAMIC 0.1uF 50V
(AEP, UK, EE)
C201 1-136-169-00 FILM 0.22uF 5% 50V
C202 1-136-169-00 FILM 0.22uF 5% 50V
C203 1-130-493-00 MYLAR 0.068uF 5% 50V
C204 1-130-493-00 MYLAR 0.068uF 5% 50V
C205 1-130-486-00 MYLAR 0.018uF 10% 50V
C206 1-130-486-00 MYLAR 0.018uF 10% 50V
C207 1-130-480-00 MYLAR 0.0056uF5% 50V
C208 1-130-479-00 MYLAR 0.0047uF5% 50V
C209 1-130-474-00 MYLAR 0.0018uF5% 50V
C210 1-126-964-11 ELECT 10uF 20% 50V
C211 1-126-964-11 ELECT 10uF 20% 50V
C212 1-130-481-00 MYLAR 0.0068uF5% 50V
C213 1-136-169-00 FILM 0.22uF 5% 50V
C214 1-136-169-00 FILM 0.22uF 5% 50V
C215 1-162-294-31 CERAMIC 0.001uF 10% 50V
C216 1-136-167-00 FILM 0.15uF 5% 50V
C221 1-126-967-11 ELECT 47uF 20% 10V
C222 1-126-967-11 ELECT 47uF 20% 10V
C223 1-126-964-11 ELECT 10uF 20% 50V
C224 1-162-290-31 CERAMIC 470PF 10% 50V
C226 1-126-964-11 ELECT 10uF 20% 50V
C227 1-164-159-21 CERAMIC 0.1uF 50V
C231 1-126-960-11 ELECT 1uF 20% 50V
C251 1-136-169-00 FILM 0.22uF 5% 50V
C252 1-136-169-00 FILM 0.22uF 5% 50V
C253 1-130-493-00 MYLAR 0.068uF 5% 50V
C254 1-130-493-00 MYLAR 0.068uF 5% 50V
C255 1-130-486-00 MYLAR 0.018uF 10% 50V
C256 1-130-486-00 MYLAR 0.018uF 10% 50V
LED
MAIN
