– 108 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
Q232 8-729-900-63 TRANSISTOR DTA124ES
Q252 8-729-119-78 TRANSISTOR 2SC403SP-51
Q253 8-729-119-78 TRANSISTOR 2SC403SP-51
Q254 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q281 8-729-900-36 TRANSISTOR DTC124ES
Q282 8-729-900-63 TRANSISTOR DTA124ES
Q283 8-729-900-36 TRANSISTOR DTC124ES
Q301 8-729-119-78 TRANSISTOR 2SC403SP-51
Q901 8-729-040-20 TRANSISTOR RT1P137L-TP
Q902 8-729-900-36 TRANSISTOR DTC124ES
Q903 8-729-030-18 TRANSISTOR 2SD2525
Q904 8-729-030-19 TRANSISTOR 2SB1640
Q905 8-729-040-20 TRANSISTOR RT1P137L-TP
Q906 8-729-900-63 TRANSISTOR DTA124ES
Q907 8-729-119-78 TRANSISTOR 2SC403SP-51
Q1531 8-729-801-93 TRANSISTOR 2SD1387
Q1532 8-729-900-80 TRANSISTOR DTC114ES
Q1533 8-729-900-80 TRANSISTOR DTC114ES
Q1534 8-729-119-77 TRANSISTOR 2SA1175-FEK
Q1535 8-729-900-80 TRANSISTOR DTC114ES
< RESISTOR >
R101 1-249-417-11 CARBON 1K 5% 1/4W
(AEP, UK, EE)
R102 1-249-417-11 CARBON 1K 5% 1/4W
R103 1-249-437-11 CARBON 47K 5% 1/4W
R104 1-249-417-11 CARBON 1K 5% 1/4W
R105 1-247-897-11 CARBON 560K 5% 1/4W
R106 1-249-437-11 CARBON 47K 5% 1/4W
R107 1-249-417-11 CARBON 1K 5% 1/4W
R108 1-249-441-11 CARBON 100K 5% 1/4W
R109 1-247-815-91 CARBON 220 5% 1/4W
(AEP, UK, EE)
R121 1-249-424-11 CARBON 3.9K 5% 1/4W
R122 1-247-887-00 CARBON 220K 5% 1/4W
R131 1-260-076-11 CARBON 10 5% 1/2W
(AEP, UK, EE)
R132 1-260-076-11 CARBON 10 5% 1/2W
(AEP, UK, EE)
R133 1-260-091-11 CARBON 220 5% 1/2W
R134 1-260-091-11 CARBON 220 5% 1/2W
R140 1-249-429-11 CARBON 10K 5% 1/4W
R141 1-249-437-11 CARBON 47K 5% 1/4W
R142 1-249-429-11 CARBON 10K 5% 1/4W
! R147 1-215-893-11 METAL OXIDE 1.5K 5% 2W F
(US, CND)
! R147 1-215-892-11 METAL OXIDE 1K 5% 2W F
(AEP, UK, EE)
! R147 1-216-456-00 METAL OXIDE 820 5% 2W F
(E, AR, MX, AUS, PX)
D906 8-719-200-82 DIODE 11ES2
D907 8-719-200-82 DIODE 11ES2
D908 8-719-200-82 DIODE 11ES2
D909 8-719-200-82 DIODE 11ES2
D910 8-719-002-60 DIODE UZL-33L-TA
D911 8-719-011-47 DIODE UZ-3.3BSB-TA
D912 8-719-987-63 DIODE 1N4148M
D913 8-719-200-82 DIODE 11ES2
D914 8-719-200-82 DIODE 11ES2
D915 8-719-001-43 DIODE UZL-11M1-TA
D951 8-719-987-63 DIODE 1N4148M
D952 8-719-987-63 DIODE 1N4148M
< FERRITE BEAD >
FB302 1-412-473-21 INDUCTOR (SMALL)
< IC >
IC101 8-759-634-50 IC M5218AL
IC102 8-759-000-48 IC MC14052BCP
IC201 8-759-331-39 IC M62427FP
IC231 8-759-634-50 IC M5218AL
IC281 8-759-111-68 IC uPC1237HA
IC301 8-759-459-31 IC uPD780018YGF-013-3BA
IC302 8-759-635-63 IC M51943BSL
IC901 8-759-288-53 IC LA5617
IC902 8-759-604-86 IC M5F7807L
IC903 8-759-231-53 IC TA7805S
IC904 8-759-231-58 IC TA7812S
IC1501 8-759-363-21 IC HA12203NT
IC1502 8-759-822-09 IC LB1641
< JACK >
J101 1-695-188-31 JACK, PIN 4P (PHONO,VIDEO IN)
< COIL >
L131 1-420-872-00 COIL, AIR-CORE (AEP, UK, EE)
L181 1-420-872-00 COIL, AIR-CORE (AEP, UK, EE)
L301 1-410-509-11 INDUCTOR 10uH
L393 1-410-515-11 INDUCTOR 33uH
< TRANSISTOR >
Q141 8-729-140-82 TRANSISTOR 2SA988-PAFAEA (US, CND)
Q141 8-729-119-76 TRANSISTOR 2SA1175-HFE (EXCEPT US, CND)
Q142 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA (US, CND)
Q142 8-729-119-78 TRANSISTOR 2SC403SP-51 (EXCEPT US, CND)
Q202 8-729-119-78 TRANSISTOR 2SC403SP-51
Q203 8-729-119-78 TRANSISTOR 2SC403SP-51
Q204 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q231 8-729-900-63 TRANSISTOR DTA124ES
The components identified by
mark ! or dotted line with
mark ! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le neméro spécifié.
MAIN
