– 114 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
! R858 1-208-601-11 WIREWOUND 0.1 10% 2W F
R859 1-260-076-11 CARBON 10 5% 1/2W
R861 1-249-417-11 CARBON 1K 5% 1/4W
R862 1-247-863-91 CARBON 22K 5% 1/4W
R863 1-249-441-11 CARBON 100K 5% 1/4W
************************************************************
* 1-659-058-13 TABLE SENSOR BOARD
******************
* 4-980-385-01 HOLDER (SW)
< IC >
IC202 8-749-924-18 IC PHOTO INTERRUPTER RPI-1391
< RESISTOR >
R207 1-249-416-11 CARBON 820 5% 1/4W
************************************************************
* 1-664-012-11 TC-A SW BOARD
*************
< CONNECTOR >
* CN612 1-568-943-11 PIN, CONNECTOR 5P
< DIODE >
D631 8-719-057-10 DIODE LNJ301MPUJA (·)
D632 8-719-057-10 DIODE LNJ301MPUJA (ª)
< RESISTOR >
R705 1-249-413-11 CARBON 470 5% 1/4W
R706 1-249-415-11 CARBON 680 5% 1/4W
R707 1-249-416-11 CARBON 820 5% 1/4W
R708 1-249-418-11 CARBON 1.2K 5% 1/4W
R709 1-249-419-11 CARBON 1.5K 5% 1/4W
R710 1-249-421-11 CARBON 2.2K 5% 1/4W
R711 1-247-807-31 CARBON 100 5% 1/4W
R714 1-247-807-31 CARBON 100 5% 1/4W
< SWITCH >
S641 1-554-303-21 SWITCH, TACTILE (·)
S642 1-554-303-21 SWITCH, TACTILE (ª)
S643 1-554-303-21 SWITCH, TACTILE (p)
S644 1-554-303-21 SWITCH, TACTILE (0)
S645 1-554-303-21 SWITCH, TACTILE ())
S646 1-554-303-21 SWITCH, TACTILE (DOLBY NR)
S647 1-554-303-21 SWITCH, TACTILE (DIRECTION)
************************************************************
The components identified by
mark ! or dotted line with
mark ! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le neméro spécifié.
POWER AMP
R803 1-249-415-11 CARBON 680 5% 1/4W
(EXCEPT, US, CND)
R804 1-249-437-11 CARBON 47K 5% 1/4W
R805 1-260-107-11 CARBON 4.7K 5% 1/2W
(US, CND)
R805 1-260-105-11 CARBON 3.3K 5% 1/2W
(EXCEPT US, CND)
R806 1-260-107-11 CARBON 4.7K 5% 1/2W
(US, CND)
R806 1-260-105-11 CARBON 3.3K 5% 1/2W
(EXCEPT US, CND)
! R807 1-212-881-11 FUSIBLE 100 5% 1/4W F
! R808 1-208-601-11 WIREWOUND 0.1 10% 2W F
R809 1-260-076-11 CARBON 10 5% 1/2W
R811 1-249-417-11 CARBON 1K 5% 1/4W
R812 1-247-863-91 CARBON 22K 5% 1/4W
R813 1-249-441-11 CARBON 100K 5% 1/4W
R814 1-260-105-11 CARBON 3.3K 5% 1/2W
(US, CND)
R814 1-260-099-11 CARBON 1K 5% 1/2W
(EXCEPT US, CND)
R816 1-260-105-11 CARBON 3.3K 5% 1/2W
(US, CND)
R816 1-260-099-11 CARBON 1K 5% 1/2W
(EXCEPT US, CND)
! R820 1-202-972-61 FUSIBLE 1 5% 1/4W F
R841 1-249-429-11 CARBON 10K 5% 1/4W
R842 1-247-885-00 CARBON 180K 5% 1/4W
(US, CND)
R842 1-247-881-00 CARBON 120K 5% 1/4W
(EXCEPT US, CND)
R843 1-247-843-11 CARBON 3.3K 5% 1/4W
(US, CND)
R843 1-249-421-11 CARBON 2.2K 5% 1/4W
(EXCEPT US, CND)
R844 1-249-429-11 CARBON 10K 5% 1/4W
R851 1-249-417-11 CARBON 1K 5% 1/4W
R852 1-249-437-11 CARBON 47K 5% 1/4W
R853 1-249-413-11 CARBON 470 5% 1/4W
(US, CND)
R853 1-249-415-11 CARBON 680 5% 1/4W
(EXCEPT US, CND)
R854 1-249-437-11 CARBON 47K 5% 1/4W
R855 1-260-107-11 CARBON 4.7K 5% 1/2W
(US, CND)
R855 1-260-105-11 CARBON 3.3K 5% 1/2W
(EXCEPT US, CND)
R856 1-260-107-11 CARBON 4.7K 5% 1/2W
(US, CND)
R856 1-260-105-11 CARBON 3.3K 5% 1/2W
(EXCEPT US, CND)
! R857 1-212-881-11 FUSIBLE 100 5% 1/4W F
TABLE SENSOR TC-A SW
