– 87 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
The components identified by
mark ! or dotted line with
mark ! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le neméro spécifié.
* 101 A-4392-330-A POWER AMP BOARD, COMPLETE
(D60/RX70: US, CND)
* 101 A-4392-331-A POWER AMP BOARD, COMPLETE
(RX70: AEP, AED, CIS, EE, G, UK)
* 101 A-4392-332-A POWER AMP BOARD, COMPLETE
(GR7: E2, E3, EA3, HK, MX, MY, SP, TW, AUS/GR7J)
* 101 A-4392-843-A POWER AMP BOARD, COMPLETE
(GR7: EA4, SAF, TH)
* 102 1-664-004-11 TRANS BOARD
103 3-701-946-27 LABEL, FUSE RATING (US, CND)
104 1-777-870-11 WIRE (FLAT TYPE) (19 CORE)
* 105 4-986-844-01 PANEL, BACK (RX70: US)
* 105 4-986-844-11 PANEL, BACK (RX70: CND)
* 105 4-986-844-21 PANEL, BACK (RX70: AEP, AED, G, UK)
* 105 4-986-844-31 PANEL, BACK (RX70: CIS, EE)
* 105 4-986-844-71 PANEL, BACK (D60)
* 105 4-988-019-01 PANEL, BACK (GR7: E3)
* 105 4-988-019-11 PANEL, BACK (GR7: E2)
* 105 4-988-019-21 PANEL, BACK (GR7: MY, SP)
* 105 4-988-019-31 PANEL, BACK (GR7: EA3, TW/GR7J)
* 105 4-988-019-41 PANEL, BACK (GR7: HK)
* 105 4-988-019-51 PANEL, BACK (GR7: AUS)
* 105 4-988-019-61 PANEL, BACK (GR7: MX)
* 105 4-988-019-71 PANEL, BACK (GR7: EA4, SAF, TH)
* 106 A-4303-574-A TCB BOARD, COMPLETE
(RX70: AEP, AED, G, UK)
106 1-233-514-11 ENCAPSULATED COMPONENT (RX70: CIS, EE)
106 1-233-544-11 ENCAPSULATED COMPONENT
(D60/RX70: US, CND)
106 1-233-545-11 ENCAPSULATED COMPONENT
(GR7: E2, EA4, MX, TH, AUS)
106 1-233-546-11 ENCAPSULATED COMPONENT
(GR7: E3, EA3, HK, MY, SAF, SP, TW/GR7J)
* 107 3-703-244-00 BUSHING (2104), CORD
(EXCEPT GR7: E2, E3, MX, TH)
107 3-703-571-11 BUSHING (S) (4516), CORD
(GR7: E2, E3, MX, TH)
108 1-751-086-11 WIRE (FLAT TYPE) (13 CORE)
(D60/GR7: E2, EA4, MX, TH, AUS/RX70: US, CND)
108 1-751-688-11 WIRE (FLAT TYPE) (13 CORE) (GR7: E2)
108 1-773-012-11 WIRE (FLAT TYPE) (15 CORE) (GR7: E3, EA3, HK
SAF, SP, TW/GR7J/RX70: AEP, AED, CIS, EE, G, UK)
* 109 4-988-533-01 HOLDER, PCB (EXCEPT GR7: EA4, SAF, TH)
110 4-965-822-01 FOOT
* 111 A-4392-315-A MAIN BOARD, COMPLETE (RX70: US)
* 111 A-4392-316-A MAIN BOARD, COMPLETE
(RX70: AEP, AED, G, UK)
* 111 A-4392-317-A MAIN BOARD, COMPLETE
(GR7: E3, EA3, HK, MY, SP, TW/GR7J)
* 111 A-4392-711-A MAIN BOARD, COMPLETE (RX70: CND)
* 111 A-4392-712-A MAIN BOARD, COMPLETE (RX70: CIS, EE)
* 111 A-4392-713-A MAIN BOARD, COMPLETE (GR7: E2, MX)
* 111 A-4392-714-A MAIN BOARD, COMPLETE (GR7: AUS)
* 111 A-4392-806-A MAIN BOARD, COMPLETE (D60)
* 111 A-4392-837-A MAIN BOARD, COMPLETE (GR7: EA4, TH)
* 111 A-4392-854-A MAIN BOARD, COMPLETE (GR7: SAF)
112 4-956-370-12 BAND, PLUG FIXED (GR7: HK, AUS/RX70: UK)
! 113 1-751-326-31 CORD, POWER (TH)
! 114 1-690-609-21 CORD, POWER (US, CND)
! 115 1-575-653-11 CORD, POWER (E2, E3, MX)
! 116 1-569-007-11 ADAPTOR, CONVERSION 2P (E3)
! 117 1-569-008-11 ADAPTOR, CONVERSION 2P (EA3, MY, SP, TW)
! 118 1-575-651-11 CORD, POWER (EA3, EA4, HK, MY, SAF, SP, TW)
! 118 1-575-651-21 CORD, POWER (AEP, AED, CIS, EE, G)
! 119 1-690-608-11 CORD, POWER (AUS)
! 120 1-751-529-11 CORD, POWER (UK)
! 121 1-770-019-11 ADAPTOR, CONVERSION PLUG 3P (HK)
M901 1-698-792-11 FAN, DC (D60/GR7/GR7J/RX70: US, CND)
! T901 1-429-997-11 TRANSFORMER, POWER (D60/RX70: US)
! T901 1-429-998-11 TRANSFORMER, POWER
(RX70: AEP, AED, CIS, EE, G, UK)
! T901 1-429-999-11 TRANSFORMER, POWER (GR7/GR7J)
! T901 1-431-148-11 TRANSFORMER, POWER (RX70: CND)
To Next Page
