Sony HCD-D60 - Page 74

– 99 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
MAIN
< CAPACITOR >
C109 1-164-159-11 CERAMIC 0.1uF 50V
(RX70: AEP, AED, CIS, EE, G, UK)
C121 1-162-286-21 CERAMIC 220PF 10% 50V
(GR7: EA4, SAF, TH)
C121 1-162-286-31 CERAMIC 220PF 10% 50V
(EXCEPT GR7: EA4, SAF, TH)
C122 1-162-286-21 CERAMIC 220PF 10% 50V
(GR7: EA4, SAF, TH)
C122 1-162-286-31 CERAMIC 220PF 10% 50V
(EXCEPT GR7: EA4, SAF, TH)
C123 1-162-306-11 CERAMIC 0.01uF 20% 16V
C131 1-136-495-11 FILM 0.068uF 5% 50V
(RX70: AEP, AED, CIS, EE, G, UK)
C132 1-136-495-11 FILM 0.068uF 5% 50V
(RX70: AEP, AED, CIS, EE, G, UK)
C171 1-162-286-21 CERAMIC 220PF 10% 50V
(GR7: EA4, SAF, TH)
C171 1-162-286-31 CERAMIC 220PF 10% 50V
(EXCEPT GR7: EA4, SAF, TH)
C172 1-162-286-21 CERAMIC 220PF 10% 50V
(GR7: EA4, SAF, TH)
C172 1-162-286-31 CERAMIC 220PF 10% 50V
(EXCEPT GR7: EA4, SAF, TH)
C173 1-162-306-11 CERAMIC 0.01uF 20% 16V
C181 1-136-495-11 FILM 0.068uF 5% 50V
(RX70: AEP, AED, CIS, EE, G, UK)
C182 1-136-495-11 FILM 0.068uF 5% 50V
(RX70: AEP, AED, CIS, EE, G, UK)
C191 1-126-963-11 ELECT 4.7uF 20% 50V
(D60/GR7/GR7J/RX70: US, CND)
C192 1-164-159-11 CERAMIC 0.1uF 50V
(EXCEPT GR7: EA4, SAF, TH/RX70: AEP, AED, CIS, EE, G, UK)
C192 1-164-159-21 CERAMIC 0.1uF 50V
(GR7: EA4, SAF, TH)
C201 1-136-169-00 FILM 0.22uF 5% 50V
C202 1-136-169-00 FILM 0.22uF 5% 50V
C203 1-130-493-00 MYLAR 0.068uF 5% 50V
C204 1-130-493-00 MYLAR 0.068uF 5% 50V
C205 1-130-486-00 MYLAR 0.018uF 10% 50V
C206 1-130-486-00 MYLAR 0.018uF 10% 50V
C207 1-130-480-00 MYLAR 0.0056uF5% 50V
C208 1-130-479-00 MYLAR 0.0047uF5% 50V
C209 1-130-474-00 MYLAR 0.0018uF5% 50V
C210 1-126-964-11 ELECT 10uF 20% 50V
C211 1-126-964-11 ELECT 10uF 20% 50V
C212 1-130-483-00 MYLAR 0.01uF 5% 50V
C213 1-136-165-00 FILM 0.1uF 5% 50V
C214 1-136-165-00 FILM 0.1uF 5% 50V
C215 1-162-294-31 CERAMIC 0.001uF 10% 50V
C216 1-136-167-00 FILM 0.15uF 5% 50V
C221 1-126-967-11 ELECT 47uF 20% 10V
C222 1-126-967-11 ELECT 47uF 20% 10V
C223 1-126-964-11 ELECT 10uF 20% 50V
C224 1-162-290-31 CERAMIC 470PF 10% 50V
C226 1-126-964-11 ELECT 10uF 20% 50V
C231 1-126-960-11 ELECT 1uF 20% 50V
C241 1-126-964-11 ELECT 10uF 20% 50V
(GR7/GR7J/RX70: US, CND)
C242 1-162-292-31 CERAMIC 680PF 10% 50V
(GR7/GR7J/RX70: US, CND)
C243 1-126-964-11 ELECT 10uF 20% 50V
(GR7/GR7J/RX70: US, CND)
C244 1-162-286-21 CERAMIC 220PF 10% 50V
(GR7: EA4, SAF, TH)
C244 1-162-286-31 CERAMIC 220PF 10% 50V
(EXCEPT D60/GR7: EA4, SAF, TH/RX70: AEP, AED, CIS, EE, G, UK)
C245 1-162-306-11 CERAMIC 0.01uF 20% 16V
(GR7/GR7J/RX70: US, CND)
C246 1-162-306-11 CERAMIC 0.01uF 20% 16V
(GR7/GR7J/RX70: US, CND)
C247 1-162-306-11 CERAMIC 0.01uF 20% 16V
(GR7/GR7J)
C251 1-136-169-00 FILM 0.22uF 5% 50V
C252 1-136-169-00 FILM 0.22uF 5% 50V
C253 1-130-493-00 MYLAR 0.068uF 5% 50V
C254 1-130-493-00 MYLAR 0.068uF 5% 50V
C255 1-130-486-00 MYLAR 0.018uF 10% 50V
C256 1-130-486-00 MYLAR 0.018uF 10% 50V
C257 1-130-480-00 MYLAR 0.0056uF5% 50V
C258 1-130-479-00 MYLAR 0.0047uF5% 50V
C259 1-130-474-00 MYLAR 0.0018uF5% 50V
C260 1-126-964-11 ELECT 10uF 20% 50V
C261 1-126-964-11 ELECT 10uF 20% 50V
C262 1-130-483-00 MYLAR 0.01uF 5% 50V
C263 1-136-165-00 FILM 0.1uF 5% 50V
C264 1-136-165-00 FILM 0.1uF 5% 50V
C276 1-126-964-11 ELECT 10uF 20% 50V
C281 1-126-933-11 ELECT 100uF 20% 10V
C282 1-126-961-11 ELECT 2.2uF 20% 50V
C283 1-126-933-11 ELECT 100uF 20% 10V
C284 1-126-923-11 ELECT 220uF 20% 10V
C291 1-126-959-11 ELECT 0.47uF 20% 50V
C301 1-126-965-11 ELECT 22uF 20% 50V
C302 1-164-159-11 CERAMIC 0.1uF 50V
(EXCEPT GR7: EA4, SAF, TH)
C302 1-164-159-21 CERAMIC 0.1uF 50V
(GR7: EA4, SAF, TH)
C303 1-136-165-00 FILM 0.1uF 5% 50V
C304 1-126-926-11 ELECT 1000uF 20% 10V
C305 1-162-306-11 CERAMIC 0.01uF 20% 16V
