– 106 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R707 1-249-401-11 CARBON 47 5% 1/4W
************************************************************
* A-4392-339-A PANEL BOARD, COMPLETE
**********************
(D60/RX70: US, CND)
* A-4392-340-A PANEL BOARD, COMPLETE
**********************
(RX70:AEP, AED, CIS, EE, G, UK)
* A-4392-341-A PANEL BOARD, COMPLETE
**********************
(EXCEPT D60/GR7: EA4, SAF, TH/RX70)
* A-4392-846-A PANEL BOARD, COMPLETE (GR7: EA4, SAF, TH)
**********************
* 4-932-810-11 CUSHION (FL)
* 4-986-870-01 HOLDER, FL TUBE
< CAPACITOR >
C601 1-162-294-31 CERAMIC 0.001uF 10% 50V
C602 1-162-306-11 CERAMIC 0.01uF 20% 16V
C603 1-124-589-11 ELECT 47uF 20% 16V
C604 1-126-163-11 ELECT 4.7uF 20% 50V
C605 1-162-294-31 CERAMIC 0.001uF 10% 50V
C606 1-126-160-11 ELECT 1uF 20% 50V
C607 1-126-160-11 ELECT 1uF 20% 50V
C608 1-162-294-31 CERAMIC 0.001uF 10% 50V
C609 1-162-282-31 CERAMIC 100PF 10% 50V
C610 1-162-282-31 CERAMIC 100PF 10% 50V
C611 1-162-282-31 CERAMIC 100PF 10% 50V
C612 1-162-282-31 CERAMIC 100PF 10% 50V
C613 1-162-282-31 CERAMIC 100PF 10% 50V
C614 1-162-282-31 CERAMIC 100PF 10% 50V
C615 1-162-282-31 CERAMIC 100PF 10% 50V
C616 1-162-282-31 CERAMIC 100PF 10% 50V
C617 1-162-282-31 CERAMIC 100PF 10% 50V
C618 1-162-282-31 CERAMIC 100PF 10% 50V
C619 1-162-282-31 CERAMIC 100PF 10% 50V
C620 1-162-282-31 CERAMIC 100PF 10% 50V
C621 1-162-282-31 CERAMIC 100PF 10% 50V
C622 1-162-282-31 CERAMIC 100PF 10% 50V
C623 1-162-282-31 CERAMIC 100PF 10% 50V
C624 1-162-290-31 CERAMIC 470PF 10% 50V
C625 1-162-294-31 CERAMIC 0.001uF 10% 50V
C626 1-124-589-11 ELECT 47uF 20% 16V
C627 1-162-306-11 CERAMIC 0.01uF 20% 16V
C628 1-162-306-11 CERAMIC 0.01uF 20% 16V
C629 1-162-306-11 CERAMIC 0.01uF 20% 16V
C630 1-162-306-11 CERAMIC 0.01uF 20% 16V
C636 1-126-160-11 ELECT 1uF 20% 50V
C637 1-130-491-00 MYLAR 0.047uF 5% 50V
C638 1-124-464-11 ELECT 0.22uF 20% 50V
C639 1-124-464-11 ELECT 0.22uF 20% 50V
C640 1-162-306-11 CERAMIC 0.01uF 20% 16V
C641 1-124-464-11 ELECT 0.22uF 20% 50V
C642 1-130-489-00 MYLAR 0.033uF 5% 50V
C643 1-162-302-11 CERAMIC 0.0022uF30% 16V
C644 1-124-464-11 ELECT 0.22uF 20% 50V
C646 1-130-470-00 MYLAR 820PF 5% 50V
C647 1-124-464-11 ELECT 0.22uF 20% 50V
C648 1-162-306-11 CERAMIC 0.01uF 20% 16V
C649 1-124-589-11 ELECT 47uF 20% 16V
C650 1-124-464-11 ELECT 0.22uF 20% 50V
C653 1-164-159-11 CERAMIC 0.1uF 50V
C654 1-162-294-31 CERAMIC 0.001MF 10% 50V
< CONNECTOR >
CN601 1-568-860-11 SOCKET, CONNECTOR 17P
* CN603 1-568-851-11 SOCKET, CONNECTOR 8P (D60/RX70: US, CND)
CN603 1-568-853-11 SOCKET, CONNECTOR 10P
(EXCEPT D60/RX70: US, CND)
CN609 1-691-645-11 SOCKET, CONNECTOR 9P
< DIODE >
D601 8-719-058-03 DIODE SEL5423E-TP15 (TUNER/BAND)
D604 8-719-058-04 DIODE SEL5223S-TP15 (EFFECT ON/OFF)
D605 8-719-058-04 DIODE SEL5223S-TP15 (JOG)
D606 8-719-057-44 DIODE HLMF-K305 (±)
D607 8-719-057-44 DIODE HLMF-K305 (≠)
D608 8-719-057-44 DIODE HLMF-K305 (+)
D609 8-719-057-44 DIODE HLMF-K305 (-)
D611 8-719-058-04 DIODE SEL5223S-TP15 (ENTER/NEXT)
D614 8-719-057-44 DIODE HLMF-K305 (GROOVE)
D615 8-719-058-04 DIODE SEL5223S-TP15 (NON STOP)
D650 8-719-987-63 DIODE 1N4148M
D651 8-719-987-63 DIODE 1N4148M
D652 8-719-987-63 DIODE 1N4148M
D653 8-719-987-63 DIODE 1N4148M
D654 8-719-987-63 DIODE 1N4148M
D655 8-719-987-63 DIODE 1N4148M
D656 8-719-987-63 DIODE 1N4148M
< INDUCTOR >
FB601 1-412-473-21 INDUCTOR (SMALL TYPE)
< FLUORESCENT INDICATOR >
FL601 1-517-618-11 INDICATOR TUBE, FLUORESCENT
PANEL
MOTOR (TURN)
