S632 1-554-303-21 SWITCH, TACTILE (DAILY 1)
S633 1-554-303-21 SWITCH, TACTILE (DAYLY 2)
S634 1-554-303-21 SWITCH, TACTILE (SLEEP)
S701 1-473-392-11 ENCODER, ROTARY (VOLUME)
< VIBRATOR >
X601 1-579-125-11 VIBRATOR, CERAMIC (8MHz)
************************************************************
* A-4392-410-A POWERAMP BOARD, COMPLETE (US,CND)
* A-4392-425-A POWERAMP BOARD, COMPLETE (AEP,UK)
* A-4392-436-A POWERAMP BOARD, COMPLETE
(E,AR,MX,AUS)
* A-4398-360-A POWERAMP BOARD, COMPLETE (EE,CIS)
*****************************
< CAPACITOR >
C801 1-128-582-11 ELECT 10uF 20% 100V
C802 1-162-286-21 CERAMIC 220PF 10% 50V
C803 1-162-282-31 CERAMIC 100PF 10% 50V
C804 1-126-967-11 ELECT 47uF 20% 50V
C806 1-126-967-11 ELECT 47uF 20% 50V
C807 1-128-560-11 ELECT 22uF 20% 100V
C809 1-128-560-11 ELECT 22uF 20% 100V
C810 1-164-159-21 CERAMIC 0.1uF 50V
C811 1-130-493-00 MYLAR 0.068uF 5% 50V
C812 1-130-493-00 MYLAR 0.068uF 5% 50V
C814 1-162-306-11 CERAMIC 0.01uF 20% 16V
C841 1-126-925-11 ELECT 470uF 20% 10V
C851 1-128-582-11 ELECT 10uF 20% 100V
C852 1-162-286-21 CERAMIC 220PF 10% 50V
C853 1-162-282-31 CERAMIC 100PF 10% 50V
C854 1-126-967-11 ELECT 47uF 20% 50V
C856 1-126-967-11 ELECT 47uF 20% 50V
C857 1-128-560-11 ELECT 22uF 20% 100V
C861 1-130-493-00 MYLAR 0.068uF 5% 50V
C862 1-130-493-00 MYLAR 0.068uF 5% 50V
C901 1-104-482-11 ELECT 4700uF 20% 63V
C902 1-130-777-00 FILM 0.1uF 10% 100V
C951 1-104-482-11 ELECT 4700uF 20% 63V
C952 1-130-777-00 FILM 0.1uF 10% 100V
< CONNECTOR >
CN801 1-778-981-11 CONNECTOR, BOARD TO BOARD 13P
< DIODE >
D801 8-719-815-85 DIODE 1S1585
D841 8-719-987-63 DIODE 1N4148M
D842 8-719-987-63 DIODE 1N4148M
D851 8-719-815-85 DIODE 1S1585
D901 8-719-510-68 DIODE D5SBA20F01
< IC >
IC801 8-749-921-68 IC STK-4231MK2
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
PANEL POWERAMP
R675 1-247-815-91 CARBON 220 5% 1/4W
R676 1-249-411-11 CARBON 330 5% 1/4W
R677 1-249-413-11 CARBON 470 5% 1/4W
R678 1-249-415-11 CARBON 680 5% 1/4W
R679 1-249-419-11 CARBON 1.5K 5% 1/4W
R681 1-249-429-11 CARBON 10K 5% 1/4W
R682 1-249-421-11 CARBON 2.2K 5% 1/4W
R683 1-247-887-00 CARBON 220K 5% 1/4W
R684 1-249-421-11 CARBON 2.2K 5% 1/4W
R685 1-247-815-91 CARBON 220 5% 1/4W
R686 1-247-807-31 CARBON 100 5% 1/4W
R687 1-247-807-31 CARBON 100 5% 1/4W
R688 1-247-807-31 CARBON 100 5% 1/4W
R689 1-247-807-31 CARBON 100 5% 1/4W
R690 1-247-807-31 CARBON 100 5% 1/4W
R691 1-247-807-31 CARBON 100 5% 1/4W
R692 1-247-807-31 CARBON 100 5% 1/4W
R693 1-247-807-31 CARBON 100 5% 1/4W
R694 1-247-807-31 CARBON 100 5% 1/4W
R695 1-247-807-31 CARBON 100 5% 1/4W
R696 1-247-807-31 CARBON 100 5% 1/4W
R697 1-247-807-31 CARBON 100 5% 1/4W
R698 1-247-807-31 CARBON 100 5% 1/4W
R699 1-247-807-31 CARBON 100 5% 1/4W
R700 1-247-807-31 CARBON 100 5% 1/4W
< SWITCH >
S601 1-554-303-21 SWITCH, TACTILE (ENTER/NEXT)
S602 1-554-303-21 SWITCH, TACTILE (TUNER MEMORY)
S603 1-554-303-21 SWITCH, TACTILE (TUNING MODE)
S604 1-554-303-21 SWITCH, TACTILE (TUNER/BAND)
S605 1-554-303-21 SWITCH, TACTILE (TUNING +)
S606 1-554-303-21 SWITCH, TACTILE (TUNING -)
S607 1-554-303-21 SWITCH, TACTILE (STEREO/MONO)
S609 1-554-303-21 SWITCH, TACTILE (FUNCTION)
S610 1-554-303-21 SWITCH, TACTILE (GROOVE)
S611 1-554-303-21 SWITCH, TACTILE (GEQ ¢)
S612 1-554-303-21 SWITCH, TACTILE (GEQ ª)
S613 1-554-303-21 SWITCH, TACTILE (GEQ ·)
S614 1-554-303-21 SWITCH, TACTILE (GEQ ›)
S615 1-554-303-21 SWITCH, TACTILE (SUPER WOOFER)
S616 1-554-303-21 SWITCH, TACTILE (S/W MODE)
S619 1-554-303-21 SWITCH, TACTILE (GEQ CONTROL)
S620 1-554-303-21 SWITCH, TACTILE (ENTER)
S621 1-554-303-21 SWITCH, TACTILE (EFFECT)
S622 1-554-303-21 SWITCH, TACTILE (WAVE)
S623 1-554-303-21 SWITCH, TACTILE (KARAOKE PON/MPX)
S624 1-554-303-21 SWITCH, TACTILE (SURROUND)
S625 1-554-303-21 SWITCH, TACTILE (P FILE MEMORY)
S627 1-554-303-21 SWITCH, TACTILE (SPECTRUM ANALYZER)
S628 1-554-303-21 SWITCH, TACTILE (DISPLAY/DEMO)
S629 1-554-303-21 SWITCH, TACTILE (POWER)
S630 1-554-303-21 SWITCH, TACTILE (CLOCK SET)
S631 1-554-303-21 SWITCH, TACTILE (REC)
