– 123 –
< TRANSISTOR >
Q801 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q851 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
< RESISTOR >
R801 1-249-417-11 CARBON 1K 5% 1/4W
R802 1-249-437-11 CARBON 47K 5% 1/4W
R803 1-249-413-11 CARBON 470 5% 1/4W
(EXCEPT EE,CIS)
R804 1-249-437-11 CARBON 47K 5% 1/4W
R805 1-260-107-11 CARBON 4.7K 5% 1/2W
R806 1-260-107-11 CARBON 4.7K 5% 1/2W
! R807 1-212-881-11 FUSIBLE 100 5% 1/4W F
! R808 1-217-156-00 WIREWOUND 0.22 10% 5W F
R809 1-260-076-11 CARBON 10 5% 1/2W
R811 1-249-417-11 CARBON 1K 5% 1/4W
R812 1-249-431-11 CARBON 15K 5% 1/4W
R813 1-249-441-11 CARBON 100K 5% 1/4W
R814 1-260-103-11 CARBON 2.2K 5% 1/2W
(E,AR,MX,AUS)
R814 1-260-105-11 CARBON 3.3K 5% 1/2W
(EXCEPT E,AR,MX,AUS)
R816 1-260-103-11 CARBON 2.2K 5% 1/2W
(E,AR,MX,AUS)
R816 1-260-105-11 CARBON 3.3K 5% 1/2W
(EXCEPT E,AR,MX,AUS)
! R820 1-202-972-61 FUSIBLE 1 5% 1/4W F
R841 1-249-425-11 CARBON 4.7K 5% 1/4W
(E,AR,MX,AUS)
R841 1-249-426-11 CARBON 5.6K 5% 1/4W
(EXCEPT E,AR,MX,AUS)
R842 1-247-885-00 CARBON 180K 5% 1/4W
(E,AR,MX,AUS)
R842 1-247-889-00 CARBON 270K 5% 1/4W
(EXCEPT E,AR,MX,AUS)
R843 1-249-421-11 CARBON 2.2K 5% 1/4W
R844 1-249-429-11 CARBON 10K 5% 1/4W
R851 1-249-417-11 CARBON 1K 5% 1/4W
R852 1-249-437-11 CARBON 47K 5% 1/4W
R853 1-249-413-11 CARBON 470 5% 1/4W
(EXCEPT EE,CIS)
R854 1-249-437-11 CARBON 47K 5% 1/4W
R855 1-260-107-11 CARBON 4.7K 5% 1/2W
R856 1-260-107-11 CARBON 4.7K 5% 1/2W
! R857 1-212-881-11 FUSIBLE 100 5% 1/4W F
! R858 1-217-156-00 WIREWOUND 0.22 10% 5W F
R859 1-260-076-11 CARBON 10 5% 1/2W
R861 1-249-417-11 CARBON 1K 5% 1/4W
R862 1-249-431-11 CARBON 15K 5% 1/4W
R863 1-249-441-11 CARBON 100K 5% 1/4W
************************************************************
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
* 1-659-058-13 TABLE SENSOR BOARD
******************
< IC >
IC202 8-749-924-18 IC PHOTO INTERRUPTER RPI-1391
< RESISTOR >
R207 1-249-416-11 CARBON 820 5% 1/4W
************************************************************
* 1-664-012-11 TC-A SW BOARD
*************
< CONNECTOR >
CN612 1-506-486-11 PIN, CONNECTOR 7P
< DIODE >
D631 8-719-057-29 DIODE SML78423C-TP15 (·)
D632 8-719-057-29 DIODE SML78423C-TP15 (ª)
< RESISTOR >
R705 1-249-401-11 CARBON 47 5% 1/4W
R706 1-249-403-11 CARBON 68 5% 1/4W
R707 1-247-807-31 CARBON 100 5% 1/4W
R708 1-249-407-11 CARBON 150 5% 1/4W
R709 1-249-407-11 CARBON 150 5% 1/4W
R710 1-247-815-91 CARBON 220 5% 1/4W
R711 1-247-807-31 CARBON 100 5% 1/4W
R712 1-247-807-31 CARBON 100 5% 1/4W
R713 1-247-807-31 CARBON 100 5% 1/4W
R714 1-247-807-31 CARBON 100 5% 1/4W
< SWITCH >
S641 1-554-303-21 SWITCH, TACTILE (·)
S642 1-554-303-21 SWITCH, TACTILE (ª)
S643 1-554-303-21 SWITCH, TACTILE (p)
S644 1-554-303-21 SWITCH, TACTILE (0)
S645 1-554-303-21 SWITCH, TACTILE ())
S646 1-554-303-21 SWITCH, TACTILE (DOLBY NR)
S647 1-554-303-21 SWITCH, TACTILE (DIRECTION)
************************************************************
* 1-664-013-11 TC-B SW BOARD
*************
< DIODE >
D635 8-719-057-29 DIODE SML78423C-TP15 (ª)
D636 8-719-057-29 DIODE SML78423C-TP15 (·)
D637 8-719-058-17 DIODE LNG401NPYJA (P)
D638 8-719-057-09 DIODE LNJ801LPDJA (r REC)
< RESISTOR >
R715 1-247-815-91 CARBON 220 5% 1/4W
R716 1-249-411-11 CARBON 330 5% 1/4W
The components identified by
mark ! or dotted line with
mark ! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le neméro spécifié.
TC-B SWTABLE SENSOR TC-A SWPOWERAMP
