79
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-DP1000D
MAIN
CN102 1-573-847-11 CONNECTOR, BOARD TO BOARD 15P
CN103 1-573-847-11 CONNECTOR, BOARD TO BOARD 15P
* CN104 1-564-518-11 PLUG, CONNECTOR 3P
CN203 1-779-549-21 CONNECTOR,FFC(LIF(NON-ZIF))12P
CN204 1-785-320-11 PIN, CONNECTOR (STRAIGHT) 8P
CN304 1-784-778-11 CONNECTOR, FFC 17P
CN401 1-793-766-11 CONNECTOR, BOARD TO BOARD 30P
CN402 1-506-469-11 PIN, CONNECTOR 4P
CN501 1-779-289-11 CONNECTOR,FFC(LIF(NON-ZIF))21P
CN502 1-779-291-11 CONNECTOR,FFC(LIF(NON-ZIF))23P
< DIODE >
D51 8-719-988-61 DIODE 1SS355TE-17
D81 8-719-988-61 DIODE 1SS355TE-17 (AEP,UK)
D111 8-719-988-61 DIODE 1SS355TE-17
D112 8-719-056-82 DIODE UDZ-TE-17-6.2B
D113 8-719-056-83 DIODE UDZ-TE-17-6.8B
D501 8-719-988-61 DIODE 1SS355TE-17
D502 8-719-988-61 DIODE 1SS355TE-17
D503 8-719-988-61 DIODE 1SS355TE-17
D504 8-719-988-61 DIODE 1SS355TE-17
D505 8-719-988-61 DIODE 1SS355TE-17
D506 8-719-988-61 DIODE 1SS355TE-17
D507 8-719-988-61 DIODE 1SS355TE-17
D508 8-719-988-61 DIODE 1SS355TE-17
D509 8-719-988-61 DIODE 1SS355TE-17
D510 8-719-988-61 DIODE 1SS355TE-17
D511 8-719-988-61 DIODE 1SS355TE-17
D950 8-719-028-23 DIODE D3SBA20-4101
D959 8-719-028-23 DIODE D3SBA20-4101
D961 8-719-988-61 DIODE 1SS355TE-17
D962 8-719-988-61 DIODE 1SS355TE-17
D971 8-719-200-82 DIODE 11ES2
D972 8-719-200-82 DIODE 11ES2
D973 8-719-200-82 DIODE 11ES2
D974 8-719-200-82 DIODE 11ES2
D975 8-719-200-82 DIODE 11ES2
D981 8-719-200-82 DIODE 11ES2
D982 8-719-200-82 DIODE 11ES2
D983 8-719-200-82 DIODE 11ES2
D984 8-719-200-82 DIODE 11ES2
< FRONT END >
FE2 1-693-478-11 FRONT END (FM3 GANGS) (EXCEPT AEP,UK)
FE3 1-693-496-11 FRONT END (4 GANG) (AEP,UK)
< IC >
IC11 8-759-828-33 IC LA1845
IC51 8-759-590-13 IC LC72131D
IC81 8-759-541-48 IC BU1924 (AEP,UK)
IC301 8-759-652-02 IC HA12226F
IC302 8-759-143-54 IC uPC1330HA
IC303 8-759-656-83 IC NJM4580MD-(TE2)
IC304 8-759-656-83 IC NJM4580MD-(TE2)
IC401 6-800-712-01 IC M30622MGA-A72FP
IC501 8-759-635-63 IC M51943BSL-TP
< IFT >
IFT11 1-435-848-12 TRANSFORMER,IF(CERAMIC FILTER)
< JUMPER RESISTOR >
JR1 1-216-864-11 METAL CHIP 0 5% 1/16W
JR2 1-216-864-11 METAL CHIP 0 5% 1/16W
JR3 1-216-864-11 METAL CHIP 0 5% 1/16W
JR4 1-216-864-11 METAL CHIP 0 5% 1/16W
JR5 1-216-864-11 METAL CHIP 0 5% 1/16W
JR6 1-216-864-11 METAL CHIP 0 5% 1/16W
(EXCEPT AEP,UK)
JR7 1-216-864-11 METAL CHIP 0 5% 1/16W
JR8 1-216-864-11 METAL CHIP 0 5% 1/16W
JR10 1-216-864-11 METAL CHIP 0 5% 1/16W
(EXCEPT AEP,UK)
JR11 1-216-864-11 METAL CHIP 0 5% 1/16W
(AEP,UK)
JR12 1-216-864-11 METAL CHIP 0 5% 1/16W
(EXCEPT AEP,UK)
JR13 1-216-864-11 METAL CHIP 0 5% 1/16W
(AEP,UK)
JR14 1-216-864-11 METAL CHIP 0 5% 1/16W
(AEP,UK)
JR15 1-216-864-11 METAL CHIP 0 5% 1/16W
JR19 1-216-864-11 METAL CHIP 0 5% 1/16W
(EXCEPT AEP,UK)
JR22 1-216-864-11 METAL CHIP 0 5% 1/16W
JR24 1-216-864-11 METAL CHIP 0 5% 1/16W
JR25 1-216-864-11 METAL CHIP 0 5% 1/16W
JR26 1-216-864-11 METAL CHIP 0 5% 1/16W
JR27 1-216-864-11 METAL CHIP 0 5% 1/16W
JR29 1-216-864-11 METAL CHIP 0 5% 1/16W
JR30 1-216-864-11 METAL CHIP 0 5% 1/16W
JR31 1-216-864-11 METAL CHIP 0 5% 1/16W
JR32 1-216-864-11 METAL CHIP 0 5% 1/16W
JR33 1-216-864-11 METAL CHIP 0 5% 1/16W
JR34 1-216-864-11 METAL CHIP 0 5% 1/16W
JR271 1-216-864-11 METAL CHIP 0 5% 1/16W
JR272 1-216-864-11 METAL CHIP 0 5% 1/16W
JR273 1-216-864-11 METAL CHIP 0 5% 1/16W
JR400 1-216-864-11 METAL CHIP 0 5% 1/16W
JR416 1-216-864-11 METAL CHIP 0 5% 1/16W
JR418 1-216-864-11 METAL CHIP 0 5% 1/16W
(EXCEPT AEP,UK)
JR420 1-216-864-11 METAL CHIP 0 5% 1/16W
(EXCEPT AEP,UK)
JR462 1-216-864-11 METAL CHIP 0 5% 1/16W
< COIL >
L41 1-412-957-11 INDUCTOR 33uH (AEP,UK)
L81 1-412-963-11 INDUCTOR 100uH (AEP,UK)
L301 1-410-780-11 INDUCTOR 27MH
L302 1-414-193-41 INDUCTOR 220uH
L303 1-414-193-41 INDUCTOR 220uH
L351 1-410-780-11 INDUCTOR 27MH
L971 1-410-478-11 INDUCTOR 47uH
< FILTER >
LPF11 1-234-612-11 FILTER, LOW PASS
LPF12 1-234-612-11 FILTER, LOW PASS
< TRANSISTOR >
Q1 8-729-055-80 TRANSISTOR 2SC1674LK-TP
Q2 8-729-422-57 TRANSISTOR UN4111
Q11 8-729-620-05 TRANSISTOR 2SC2603-EF
