Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-DP1000D
MAIN
Q12 8-729-620-05 TRANSISTOR 2SC2603-EF
Q81 8-729-620-05 TRANSISTOR 2SC2603TP-EF (AEP,UK)
Q111 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q112 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q113 8-729-026-68 TRANSISTOR 2SD2525(TP)
Q114 8-729-900-36 TRANSISTOR DTC124ES
Q121 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q141 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q171 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q301 8-729-801-93 TRANSISTOR 2SD1387-3
Q302 8-729-142-46 TRANSISTOR 2SC2001-LK
Q303 8-729-142-46 TRANSISTOR 2SC2001-LK
Q304 8-729-900-63 TRANSISTOR DTA124ES
Q305 8-729-900-80 TRANSISTOR DTC114ES
Q391 8-729-140-04 TRANSISTOR 2SB1116A-L
Q392 8-729-900-80 TRANSISTOR DTC114ES
Q393 8-729-140-04 TRANSISTOR 2SB1116A-L
Q394 8-729-900-80 TRANSISTOR DTC114ES
Q395 8-729-900-80 TRANSISTOR DTC114ES
Q396 8-729-116-57 TRANSISTOR 2SB1068-K
Q397 8-729-900-80 TRANSISTOR DTC114ES
Q501 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q502 8-729-900-63 TRANSISTOR DTA124ES
Q503 8-729-900-63 TRANSISTOR DTA124ES
Q504 8-729-900-63 TRANSISTOR DTA124ES
Q505 8-729-900-36 TRANSISTOR DTC124ES
Q506 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q507 8-729-422-57 TRANSISTOR UN4111
< RESISTOR >
R1 1-216-864-11 METAL CHIP 0 5% 1/16W
R3 1-216-805-11 METAL CHIP 47 5% 1/16W
R4 1-216-805-11 METAL CHIP 47 5% 1/16W
R5 1-216-819-11 METAL CHIP 680 5% 1/16W
R6 1-216-815-11 METAL CHIP 330 5% 1/16W
R7 1-216-819-11 METAL CHIP 680 5% 1/16W
R8 1-216-821-11 METAL CHIP 1K 5% 1/16W
R10 1-216-814-11 METAL CHIP 270 5% 1/16W
R12 1-216-833-11 METAL CHIP 10K 5% 1/16W
R13 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R14 1-216-814-11 METAL CHIP 270 5% 1/16W
R15 1-216-843-11 METAL CHIP 68K 5% 1/16W
R16 1-216-837-11 METAL CHIP 22K 5% 1/16W
R17 1-216-839-11 METAL CHIP 33K 5% 1/16W
R18 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R19 1-216-833-11 METAL CHIP 10K 5% 1/16W
R20 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R21 1-216-819-11 METAL CHIP 680 5% 1/16W
(AEP,UK)
R21 1-216-821-11 METAL CHIP 1K 5% 1/16W
(EXCEPT AEP,UK)
R22 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R23 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R24 1-216-819-11 METAL CHIP 680 5% 1/16W
(AEP,UK)
R24 1-216-821-11 METAL CHIP 1K 5% 1/16W
(EXCEPT AEP,UK)
R25 1-216-809-11 METAL CHIP 100 5% 1/16W
R26 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R27 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R28 1-216-849-11 METAL CHIP 220K 5% 1/16W
R29 1-216-849-11 METAL CHIP 220K 5% 1/16W
R30 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R31 1-216-864-11 METAL CHIP 0 5% 1/16W
R41 1-216-833-11 METAL CHIP 10K 5% 1/16W
R42 1-216-845-11 METAL CHIP 100K 5% 1/16W
R43 1-216-839-11 METAL CHIP 33K 5% 1/16W
R55 1-216-833-11 METAL CHIP 10K 5% 1/16W
R56 1-216-833-11 METAL CHIP 10K 5% 1/16W
R58 1-216-809-11 METAL CHIP 100 5% 1/16W
R59 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R60 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R61 1-216-809-11 METAL CHIP 100 5% 1/16W
R62 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R63 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R64 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R65 1-216-809-11 METAL CHIP 100 5% 1/16W
R66 1-216-833-11 METAL CHIP 10K 5% 1/16W
R67 1-216-833-11 METAL CHIP 10K 5% 1/16W
R68 1-216-821-11 METAL CHIP 1K 5% 1/16W
R69 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R81 1-216-851-11 METAL CHIP 330K 5% 1/16W
(AEP,UK)
R83 1-216-821-11 METAL CHIP 1K 5% 1/16W
(AEP,UK)
R84 1-216-817-11 METAL CHIP 470 5% 1/16W
(AEP,UK)
R85 1-216-864-11 METAL CHIP 0 5% 1/16W
(AEP,UK)
R86 1-216-805-11 METAL CHIP 47 5% 1/16W
(AEP,UK)
R87 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
(AEP,UK)
R88 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
(AEP,UK)
R111 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R112 1-216-841-11 METAL CHIP 47K 5% 1/16W
R113 1-216-837-11 METAL CHIP 22K 5% 1/16W
R114 1-216-849-11 METAL CHIP 220K 5% 1/16W
R115 1-216-837-11 METAL CHIP 22K 5% 1/16W
0R121 1-215-891-11 METAL OXIDE 680 5% 2W
R122 1-216-821-11 METAL CHIP 1K 5% 1/16W
R124 1-216-837-11 METAL CHIP 22K 5% 1/16W
R141 1-216-821-11 METAL CHIP 1K 5% 1/16W
R142 1-216-822-11 METAL CHIP 1.2K 5% 1/16W
R143 1-216-817-11 METAL CHIP 470 5% 1/16W
0R171 1-215-891-11 METAL OXIDE 680 5% 2W
R172 1-216-821-11 METAL CHIP 1K 5% 1/16W
R174 1-216-837-11 METAL CHIP 22K 5% 1/16W
R175 1-216-826-11 METAL CHIP 2.7K 5% 1/16W
R301 1-216-837-11 METAL CHIP 22K 5% 1/16W
R302 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R303 1-216-809-11 METAL CHIP 100 5% 1/16W
R304 1-216-809-11 METAL CHIP 100 5% 1/16W
R305 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
R306 1-216-833-11 METAL CHIP 10K 5% 1/16W
R307 1-216-832-11 METAL CHIP 8.2K 5% 1/16W
R308 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R309 1-216-837-11 METAL CHIP 22K 5% 1/16W
R311 1-216-857-11 METAL CHIP 1M 5% 1/16W
R312 1-218-745-11 RES-CHIP 160K 5% 1/16W
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part number
specified.
