8
HCD-DP1000D
2-2. LOADING PANEL
2-3. FRONT PANEL SECTION, DVD MECHANISM DECK (CDM58D)
2
pull-out the disc tray.
4
pull-out the disc tray.
loading panel
1
turn the pulley to the direction of arrow.
pulley
front panel side
DVD mechanism deck (CDM58D)
3
qf
two screws (+BVTP 3
×
8
)
qd
five screws
(+BVTP 3
×
8
)
qg
three screws (+BVTP 3
×
8
)
qa
connector (CN204)
3
screw (+BVTP 3
×
10)
2
screw
(+BVTP 3
×
10)
1
connector (CN601)
8
connector (CN2)
7
connector (CN1)
6
flat type wire (CN1001)
chassis section
4
three screws (+BVTT 3
×
8)
5
front panel section
qh
DVD mechanism deck (CDM58D)
9
flat type wire
(CN203)
0
flat type wire
(CN502)
qs
flat type wire
(CN501)
