90
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-DP1000D
D902 8-719-024-99 DIODE 11ES2-NTA2B
D903 8-719-024-99 DIODE 11ES2-NTA2B
D904 8-719-024-99 DIODE 11ES2-NTA2B
D905 8-719-024-99 DIODE 11ES2-NTA2B
< FUSE >
0F911 1-533-470-11 FUSE, GLASS TUBE (DIA. 5) (T3.15AL 250V)
(E,EA,SP,MY)
0F912 1-533-470-11 FUSE, GLASS TUBE (DIA. 5) (T3.15AL 250V)
(E,EA,SP,MY)
0F913 1-533-454-11 FUSE, GLASS TUBE (DIA. 5) (6.3A 125V)
(US,CND)
0F913 1-533-468-11 FUSE, GLASS TUBE (DIA. 5) (T2AL 250V)
(AEP,UK)
0F913 1-533-470-11 FUSE, GLASS TUBE (DIA. 5) (T3.15AL 250V)
(AUS,E91,TH)
0F913 1-533-473-11 FUSE, GLASS TUBE (DIA. 5) (T6.3AL 250V)
(E,EA,MX,SP,MY)
< IC >
IC901 8-759-158-62 IC TA78057S
< TRANSISTOR >
Q901 8-729-119-78 TRANSISTOR 2SC2785-HFE
< RESISTOR >
R902 1-249-429-11 CARBON 10K 5% 1/4W
R903 1-249-429-11 CARBON 10K 5% 1/4W
< RELAY >
0RY901 1-755-276-11 RELAY, POWER
< SWITCH >
0S901 1-786-055-21 SELECTOR, VOLTAGE (VOLTAGE SELECTOR)
(E,EA,SP,MY)
< TRANSFORMER >
0T901 1-435-824-11 TRANSFORMER, POWER (AEP,UK)
0T901 1-435-823-11 TRANSFORMER, POWER (US,CND)
0T901 1-435-825-11 TRANSFORMER, POWER
(AUS,E,E91,EA,MX,SP,MY,TH)
******************************************************
A-4727-113-A SURROUND AMP BOARD, COMPLETE(US,CND)
A-4727-137-A SURROUND AMP BOARD, COMPLETE (AEP,UK)
A-4727-157-A SURROUND AMP BOARD, COMPLETE
(AUS,E91,EA,SP,MY)
A-4727-197-A SURROUND AMP BOARD, COMPLETE (E,MX)
A-4727-223-A SURROUND AMP BOARD, COMPLETE (TH)
**********************************
< CAPACITOR >
C931 1-126-964-11 ELECT 10uF 20% 50V
C932 1-126-917-11 ELECT 3300uF 20% 6.3V
C933 1-126-964-11 ELECT 10uF 20% 50V
C934 1-126-935-11 ELECT 470uF 20% 10V
C935 1-126-964-11 ELECT 10uF 20% 50V
C936 1-126-917-11 ELECT 3300uF 20% 6.3V
C937 1-126-964-11 ELECT 10uF 20% 50V
C938 1-126-935-11 ELECT 470uF 20% 10V
C1001 1-126-964-11 ELECT 10uF 20% 50V
C1002 1-162-286-31 CERAMIC 220PF 10% 50V
C1003 1-162-286-31 CERAMIC 220PF 10% 50V
C1004 1-126-947-11 ELECT 47uF 20% 10V
C1006 1-136-165-00 FILM 0.1uF 5% 50V
C1007 1-136-165-00 FILM 0.1uF 5% 50V
C1008 1-126-968-11 ELECT 100uF 20% 50V
C1041 1-126-964-11 ELECT 10uF 20% 50V
C1042 1-162-286-31 CERAMIC 220PF 10% 50V
C1043 1-162-286-31 CERAMIC 220PF 10% 50V
C1044 1-126-947-11 ELECT 47uF 20% 10V
C1046 1-136-165-00 FILM 0.1uF 5% 50V
C1047 1-136-165-00 FILM 0.1uF 5% 50V
C1051 1-126-964-11 ELECT 10uF 20% 50V
C1052 1-162-286-31 CERAMIC 220PF 10% 50V
C1053 1-162-286-31 CERAMIC 220PF 10% 50V
C1054 1-126-947-11 ELECT 47uF 20% 10V
C1056 1-136-165-00 FILM 0.1uF 5% 50V
C1057 1-136-165-00 FILM 0.1uF 5% 50V
C1058 1-126-968-11 ELECT 100uF 20% 50V
C1071 1-136-153-00 FILM 0.01uF 5% 50V
C1072 1-136-153-00 FILM 0.01uF 5% 50V
C1073 1-137-844-11 ELECT 2200uF 20% 42V
C1074 1-137-844-11 ELECT 2200uF 20% 42V
C1081 1-136-165-00 FILM 0.1uF 5% 50V
C1082 1-136-165-00 FILM 0.1uF 5% 50V
C1083 1-136-165-00 FILM 0.1uF 5% 50V
C1084 1-136-165-00 FILM 0.1uF 5% 50V
C1085 1-136-165-00 FILM 0.1uF 5% 50V
C1086 1-136-165-00 FILM 0.1uF 5% 50V
< CONNECTOR >
CN1001 1-573-829-11 CONNECTOR, BOARD TO BOARD 15P
< DIODE >
D933 8-719-050-84 DIODE RB441Q-40T-77
D934 8-719-050-84 DIODE RB441Q-40T-77
D1001 8-719-911-19 DIODE 1SS119-25
D1041 8-719-911-19 DIODE 1SS119-25
D1051 8-719-911-19 DIODE 1SS119-25
D1071 8-719-510-68 DIODE D5SBA204101
D1081 8-719-911-19 DIODE 1SS119-25
D1082 8-719-911-19 DIODE 1SS119-25
D1091 8-719-911-19 DIODE 1SS119-25
< IC >
IC931 8-759-039-69 IC UPC7805AHF
IC932 8-759-158-62 IC TA78057S
IC933 8-759-445-59 IC BA033T
IC934 8-759-445-59 IC BA033T
IC1001 8-749-017-19 IC STK443-050
< COIL >
L1081 1-420-872-00 COIL, AIR-CORE
L1082 1-420-872-00 COIL, AIR-CORE
L1083 1-420-872-00 COIL, AIR-CORE
< TRANSISTOR >
Q931 8-729-030-19 TRANSISTOR 2SB1640
Q932 8-729-900-80 TRANSISTOR DTC114ES
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part number
specified.
SUB TRANS SURROUND AMP
