91
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-DP1000D
Q1001 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q1016 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q1017 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q1041 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q1051 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q1081 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q1083 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q1084 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
< RESISTOR >
R931 1-249-422-11 CARBON 2.7K 5% 1/4W F
R932 1-249-422-11 CARBON 2.7K 5% 1/4W F
R933 1-249-422-11 CARBON 2.7K 5% 1/4W F
R934 1-249-429-11 CARBON 10K 5% 1/4W
R1001 1-249-417-11 CARBON 1K 5% 1/4W F
R1002 1-249-438-11 CARBON 56K 5% 1/4W
R1003 1-249-418-11 CARBON 1.2K 5% 1/4W F
(AEP,UK)
R1003 1-249-417-11 CARBON 1K 5% 1/4W F
(US,CND)
R1003 1-249-416-11 CARBON 820 5% 1/4W F
(AUS,E,E91,EA,MX,SP,MY,TH)
R1004 1-249-438-11 CARBON 56K 5% 1/4W
0R1005 1-220-755-11 METAL 0.22 10% 2W
0R1006 1-220-755-11 METAL 0.22 10% 2W
R1007 1-249-417-11 CARBON 1K 5% 1/4W F
R1008 1-249-431-11 CARBON 15K 5% 1/4W
R1009 1-249-441-11 CARBON 100K 5% 1/4W
R1010 1-260-076-11 CARBON 10 5% 1/2W
0R1011 1-212-881-11 FUSIBLE 100 5% 1/4W
R1015 1-249-433-11 CARBON 22K 5% 1/4W
R1016 1-249-441-11 CARBON 100K 5% 1/4W
R1017 1-249-441-11 CARBON 100K 5% 1/4W
R1018 1-249-437-11 CARBON 47K 5% 1/4W
R1019 1-249-429-11 CARBON 10K 5% 1/4W
0R1020 1-202-972-61 FUSIBLE 1 5% 1/4W
R1031 1-249-437-11 CARBON 47K 5% 1/4W
R1032 1-249-438-11 CARBON 56K 5% 1/4W
R1033 1-249-439-11 CARBON 68K 5% 1/4W
R1041 1-249-417-11 CARBON 1K 5% 1/4W F
R1042 1-249-438-11 CARBON 56K 5% 1/4W
R1043 1-249-419-11 CARBON 1.5K 5% 1/4W F
(AEP,U)
R1043 1-249-418-11 CARBON 1.2K 5% 1/4W F
(US,CND)
R1043 1-249-417-11 CARBON 1K 5% 1/4W F
(AUS,E,E91,EA,MX,SP,MY,TH)
R1044 1-249-438-11 CARBON 56K 5% 1/4W
0R1045 1-220-755-11 METAL 0.22 10% 2W
0R1046 1-220-755-11 METAL 0.22 10% 2W
R1047 1-249-417-11 CARBON 1K 5% 1/4W F
R1048 1-249-431-11 CARBON 15K 5% 1/4W
R1049 1-249-441-11 CARBON 100K 5% 1/4W
R1050 1-260-076-11 CARBON 10 5% 1/2W
R1051 1-249-417-11 CARBON 1K 5% 1/4W F
R1052 1-249-438-11 CARBON 56K 5% 1/4W
R1053 1-249-418-11 CARBON 1.2K 5% 1/4W F
(AEP,UK)
R1053 1-249-417-11 CARBON 1K 5% 1/4W F
(US,CND)
R1053 1-249-416-11 CARBON 820 5% 1/4W F
(AUS,E,E91,EA,MX,SP,MY,TH)
R1054 1-249-438-11 CARBON 56K 5% 1/4W
0R1055 1-220-755-11 METAL 0.22 10% 2W
0R1056 1-220-755-11 METAL 0.22 10% 2W
R1057 1-249-417-11 CARBON 1K 5% 1/4W F
R1058 1-249-431-11 CARBON 15K 5% 1/4W
R1059 1-249-441-11 CARBON 100K 5% 1/4W
R1060 1-260-076-11 CARBON 10 5% 1/2W
0R1061 1-212-881-11 FUSIBLE 100 5% 1/4W
R1071 1-249-441-11 CARBON 100K 5% 1/4W
R1072 1-249-441-11 CARBON 100K 5% 1/4W
R1081 1-260-076-11 CARBON 10 5% 1/2W
R1082 1-260-076-11 CARBON 10 5% 1/2W
R1083 1-260-076-11 CARBON 10 5% 1/2W
R1084 1-260-076-11 CARBON 10 5% 1/2W
R1085 1-260-076-11 CARBON 10 5% 1/2W
R1086 1-260-076-11 CARBON 10 5% 1/2W
R1087 1-249-437-11 CARBON 47K 5% 1/4W
R1088 1-249-437-11 CARBON 47K 5% 1/4W
R1089 1-249-437-11 CARBON 47K 5% 1/4W
R1090 1-249-429-11 CARBON 10K 5% 1/4W
0R1094 1-215-888-00 METAL OXIDE 220 5% 2W
(US,CND,AEP,UK)
0R1094 1-215-889-00 METAL OXIDE 330 5% 2W
(AUS,E,E91,EA,MX,SP,MY,TH)
R1095 1-249-429-11 CARBON 10K 5% 1/4W
R1096 1-249-433-11 CARBON 22K 5% 1/4W
R1097 1-249-429-11 CARBON 10K 5% 1/4W
R1098 1-249-441-11 CARBON 100K 5% 1/4W
0R1099 1-215-888-00 METAL OXIDE 220 5% 2W
(US,CND,AEP,UK)
0R1099 1-215-889-00 METAL OXIDE 330 5% 2W
(AUS,E,E91,EA,MX,SP,MY,TH)
< RELAY >
RY1081 1-515-920-11 RELAY
RY1082 1-515-920-11 RELAY
< THERMISTOR >
TH1001 1-807-796-11 THERMISTOR
< TERMINAL >
TM1001 1-694-674-22 TERMINAL BOARD (6P)
(REAR/CENTER SPEAKER)
******************************************************
1-680-189-11 TRANS BOARD
***********
1-533-217-31 HOLDER, FUSE
< CAPACITOR >
C911 1-128-576-11 ELECT 100uF 20% 63V
C912 1-126-960-11 ELECT 1uF 20% 50V
C913 1-126-968-11 ELECT 100uF 20% 50V
C915 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
* CN913 1-564-518-11 PLUG, CONNECTOR 3P
* CN914 1-564-525-11 PLUG, CONNECTOR 10P
* CN915 1-564-519-11 PLUG, CONNECTOR 4P
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part number
specified.
SURROUND AMP TRANS
