Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-DP1000D
< DIODE >
D911 8-719-024-99 DIODE 11ES2-NTA2B
D912 8-719-983-88 DIODE MTZJ-T-72-33C
D913 8-719-118-56 DIODE RD4.7F-T7B1
< FUSE >
0F916 1-533-473-11 FUSE, GLASS TUBE (DIA. 5) (T6.3AL 250V)
(EXCEPT US,CND)
0F916 1-576-537-11 FUSE, GLASS TUBE (DIA. 5) (8A 125V)
(US,CND)
0F917 1-533-473-11 FUSE, GLASS TUBE (DIA. 5) (T6.3AL 250V)
(EXCEPT US,CND)
0F917 1-576-537-11 FUSE, GLASS TUBE (DIA. 5) (8A 125V)
(US,CND)
0F918 1-533-472-11 FUSE, GLASS TUBE (DIA. 5) (T5AL 250V)
(EXCEPT US,CND)
0F918 1-576-537-11 FUSE, GLASS TUBE (DIA. 5) (8A 125V)
(US,CND)
0F919 1-533-472-11 FUSE, GLASS TUBE (DIA. 5) (T5AL 250V)
(EXCEPT US,CND)
0F919 1-576-537-11 FUSE, GLASS TUBE (DIA. 5) (8A 125V)
(US,CND)
< TRANSISTOR >
Q971 8-729-048-52 TRANSISTOR 2SA1932(TP)
< RESISTOR >
0R911 1-217-637-00 FUSIBLE 1 5% 1/4W
(AEP,UK)
0R911 1-219-124-11 FUSIBLE 0.68 5% 1/4W
(EXCEPT AEP,UK)
R913 1-249-429-11 CARBON 10K 5% 1/4W
R914 1-249-429-11 CARBON 10K 5% 1/4W
R915 1-247-807-31 CARBON 100 5% 1/4W
R916 1-247-807-31 CARBON 100 5% 1/4W
0R918 1-219-237-91 SOLID 3.3M 20% 1/2W
(US,CND)
< TRANSFORMER >
0T911 1-437-510-11 TRANSFORMER, POWER (US,CND)
0T911 1-437-511-11 TRANSFORMER, POWER (AEP,UK)
0T911 1-437-512-11 TRANSFORMER, POWER
(AUS,E,E91,EA,MX,SP,MY,TH)
******************************************************
1-682-902-11 VIDEO BOARD
**********
< CONNECTOR >
CN601 1-779-274-11 CONNECTOR, FFC(LIF(NON-ZIF))6P
< DIODE >
D601 8-719-056-83 DIODE UDZ-TE-17-6.8B
D602 8-719-056-83 DIODE UDZ-TE-17-6.8B
D603 8-719-056-83 DIODE UDZ-TE-17-6.8B
D604 8-719-056-83 DIODE UDZ-TE-17-6.8B
D605 8-719-056-83 DIODE UDZ-TE-17-6.8B
D606 8-719-056-83 DIODE UDZ-TE-17-6.8B
< JACK >
J601 1-774-227-11 JACK, PIN 1P (VIDEO OUT)
J602 1-537-943-11 TERMINAL, S (S VIDEO OUT)
**************************************************************
MISCELLANEOUS
*************
14 1-823-367-11 WIRE (FLAT TYPE) (9 CORE)
15 1-823-370-11 WIRE (FLAT TYPE) (6 CORE)
16 1-823-368-11 WIRE (FLAT TYPE) (25 CORE)
68 1-796-001-11 TOUCH PAD
102 1-773-042-11 WIRE (FLAT TYPE) (17 CORE)
103 1-757-419-11 WIRE (FLAT TYPE) (21 CORE)
104 1-757-420-11 WIRE (FLAT TYPE) (23 CORE)
105 1-823-369-11 WIRE (FLAT TYPE) (12 CORE)
0110 1-777-071-81 CORD, POWER (AEP,E91,EA,SP,MY,UK)
0110 1-783-203-11 CORD, POWER (AUS)
0110 1-783-531-31 CORD, POWER (US,CND)
0110 1-791-901-11 CORD, POWER (E,MX,TH)
0111 1-569-008-21 ADAPTOR, CONVERSION (EA,SP,MY)
0112 1-770-019-11 ADAPTOR, CONVERSION PLUG 3P (UK)
155 1-454-887-32 SOLENOID, PLUNGER
161 X-3378-241-1 MOTOR ASSY
209 X-3378-241-1 MOTOR ASSY
259 1-791-983-12 WIRE (FLAT TYPE) (8 CORE)
0277 8-820-144-06 OPTICAL PICK-UP KHM-240AAA (TYPE A)
0277 A-6062-709-A SERVICE ASSY, KHM-270AAA (TYPE B)
283 1-823-621-11 CABLE, FLEXIBLE FLAT (26 CORE)
284 1-823-622-11 WIRE (FLAT TYPE) (9 CORE)
FL1101 1-518-722-11 INDICATOR TUBE, FLUORESCENT
M721 A-4672-826-A MOTOR ASSY
M961 1-763-072-11 FAN, DC
0T911 1-437-510-11 TRANSFORMER, POWER (US,CND)
0T911 1-437-511-11 TRANSFORMER, POWER (AEP,UK)
0T911 1-437-512-11 TRANSFORMER, POWER
(AUS,E,E91,EA,MX,SP,MY,TH)
******************************************************
*************
HARDWARE LIST
*************
#1 7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
#2 7-685-647-79 SCREW +BVTP 3X10 TYPE2 IT-3
#3 7-685-105-19 TPG +P 2X8, TYPE 2, NON-SLIT
#4 7-685-881-09 SCREW +BVTT 4X8 (S)
#5 7-685-650-79 SCREW +BVTP 3X16 TYPE2 IT-3
#6 7-685-872-09 SCREW +BVTT 3X8 (S)
#7 7-623-921-01 RING, RETAINING, CAPSTAN
#8 7-628-254-05 SCREW +PS 2.6X5
#9 7-685-781-09 SCREW +PTT 2X4 (S)
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part number
specified.
