Sony HCD-DX2 - Decode Section Parts List

44
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
< RESISTOR >
0 R001 1-219-238-11 SOLID 4.7M 20% 1/2W F
(US, Canadian)
R400 1-249-418-11 CARBON 1.2K 5% 1/4W
R401 1-247-879-11 CARBON 100K 5% 1/4W
R402 1-247-879-11 CARBON 100K 5% 1/4W
R403 1-247-839-11 CARBON 2.2K 5% 1/4W
R404 1-247-839-11 CARBON 2.2K 5% 1/4W
R405 1-249-438-11 CARBON 56K 5% 1/4W
R406 1-249-438-11 CARBON 56K 5% 1/4W
R407 1-247-839-11 CARBON 2.2K 5% 1/4W
R408 1-247-839-11 CARBON 2.2K 5% 1/4W
R409 1-249-438-11 CARBON 56K 5% 1/4W
R410 1-249-438-11 CARBON 56K 5% 1/4W
R411 1-249-459-11 CARBON 12K 5% 1/4W
R412 1-249-417-11 CARBON 1K 5% 1/4W
R413 1-249-417-11 CARBON 1K 5% 1/4W
R414 1-249-459-11 CARBON 12K 5% 1/4W
R415 1-249-431-11 CARBON 15K 5% 1/4W
R416 1-249-431-11 CARBON 15K 5% 1/4W
R417 1-247-879-11 CARBON 100K 5% 1/4W
R418 1-247-879-11 CARBON 100K 5% 1/4W
0 R419 1-220-890-11 METAL 0.22 10% 3W F
0 R420 1-220-890-11 METAL 0.22 10% 3W F
R421 1-249-438-11 CARBON 56K 5% 1/4W
R422 1-247-871-11 CARBON 47K 5% 1/4W
R427 1-249-455-11 CARBON 4.7 5% 1/4W
R428 1-249-455-11 CARBON 4.7 5% 1/4W
R430 1-247-863-11 CARBON 22K 5% 1/4W
R431 1-247-847-11 CARBON 4.7K 5% 1/4W
R432 1-247-867-11 CARBON 33K 5% 1/4W
R434 1-247-871-11 CARBON 47K 5% 1/4W
R435 1-247-855-11 CARBON 10K 5% 1/4W
R436 1-247-863-11 CARBON 22K 5% 1/4W
R437 1-247-879-11 CARBON 100K 5% 1/4W
0 R439 1-215-867-00 METAL OXIDE 470 5% 1W F
0 R440 1-215-867-00 METAL OXIDE 470 5% 1W F
R441 1-247-843-11 CARBON 3.3K 5% 1/4W
R442 1-247-843-11 CARBON 3.3K 5% 1/4W
R445 1-247-688-11 CARBON 10 5% 1/4W
R446 1-247-847-11 CARBON 4.7K 5% 1/4W
0 R447 1-212-857-00 FUSIBLE 10 5% 1/4W F
R448 1-247-713-11 CARBON 1K 5% 1/4W
R449 1-247-847-11 CARBON 4.7K 5% 1/4W
R450 1-247-855-11 CARBON 10K 5% 1/4W
0 R419A 1-220-890-11 METAL 0.22 10% 3W F
0 R420A 1-220-890-11 METAL 0.22 10% 3W F
< RELAY >
RL401 1-755-170-11 RELAY (12V)
0 RL402 1-515-999-11 RELAY, POWER
< TRANSFORMER >
0 T401 1-435-612-11 TRANSFORMER, POWER
**************************************************************
A-4473-611-A DECODE BOARD, COMPLETE
************************
< CAPACITOR >
C701 1-104-664-11 ELECT 47uF 20% 16V
C702 1-137-352-11 MYLAR 0.033uF 5% 100V
C703 1-137-150-11 MYLAR 0.01uF 5% 100V
C704 1-137-352-11 MYLAR 0.033uF 5% 100V
C705 1-137-150-11 MYLAR 0.01uF 5% 100V
C706 1-128-551-11 ELECT 22uF 20% 25V
C707 1-162-209-31 CERAMIC 27PF 5% 50V
C708 1-164-159-11 CERAMIC 0.1uF 50V
C711 1-162-600-11 CERAMIC 0.0047uF 10% 16V
C712 1-162-306-11 CERAMIC 0.01uF 20% 16V
C713 1-136-291-11 MYLAR 0.0068uF 5% 100V
C714 1-137-397-11 MYLAR 0.047uF 5% 100V
C715 1-161-494-00 CERAMIC 0.022uF 25V
C716 1-137-399-11 MYLAR 0.1uF 5% 100V
C717 1-104-665-11 ELECT 100uF 20% 10V
C718 1-104-665-11 ELECT 100uF 20% 10V
C719 1-137-399-11 MYLAR 0.1uF 5% 100V
C720 1-137-389-11 MYLAR 0.0022uF 5% 100V
C721 1-137-399-11 MYLAR 0.1uF 5% 100V
C722 1-137-399-11 MYLAR 0.1uF 5% 100V
C723 1-137-399-11 MYLAR 0.1uF 5% 100V
C724 1-107-713-11 ELECT 4.7uF 20% 50V
C725 1-137-352-11 MYLAR 0.033uF 5% 100V
C726 1-130-486-00 MYLAR 0.018uF 10% 50V
C727 1-162-199-31 CERAMIC 10PF 5% 50V
C728 1-137-398-11 MYLAR 0.068uF 5% 100V
C729 1-126-962-11 ELECT 3.3uF 20% 50V
C730 1-162-215-31 CERAMIC 47PF 5% 50V
C731 1-164-159-11 CERAMIC 0.1uF 50V
C732 1-161-494-00 CERAMIC 0.022uF 25V
C733 1-104-665-11 ELECT 100uF 20% 10V
C734 1-164-159-11 CERAMIC 0.1uF 50V
C736 1-162-294-31 CERAMIC 0.001uF 10% 50V
C737 1-162-306-11 CERAMIC 0.01uF 20% 16V
C740 1-126-925-11 ELECT 470uF 20% 10V
C742 1-161-494-00 CERAMIC 0.022uF 25V
C743 1-126-927-11 ELECT 2200uF 20% 10V
C745 1-162-306-11 CERAMIC 0.01uF 20% 16V
C746 1-107-713-11 ELECT 4.7uF 20% 35V
C751 1-162-306-11 CERAMIC 0.01uF 20% 16V
C753 1-161-494-00 CERAMIC 0.022uF 25V
C754 1-104-665-11 ELECT 100uF 20% 10V
C755 1-104-665-11 ELECT 100uF 20% 10V
C756 1-107-357-11 MYLAR 0.47uF 5% 100V
C757 1-162-306-11 CERAMIC 0.01uF 20% 16V
C759 1-162-290-31 CERAMIC 470PF 10% 50V
C760 1-162-286-31 CERAMIC 220PF 10% 50V
C761 1-130-781-00 MYLAR 0.22uF 5% 100V
C762 1-137-150-11 MYLAR 0.01uF 5% 100V
C763 1-161-494-00 CERAMIC 0.022uF 25V
C765 1-162-294-31 CERAMIC 0.001uF 10% 50V
C766 1-162-294-31 CERAMIC 0.001uF 10% 50V
C767 1-162-294-31 CERAMIC 0.001uF 10% 50V
C768 1-162-294-31 CERAMIC 0.001uF 10% 50V
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
AMP DECODE
