HCD-DX375
SECTION 3
DISASSEMBLY
3-1. DISASSEMBLY FLOW
•This set can be disassembled in the order shown below.
•The dotted square with arrow ( ) prompts you to move to the next job when all of the works within the dotted square ( ) are
completed.
3-3.FL BOARD, SW BOARD
(Page 16)
3-5.DMB12 BOARD
(Page 17)
3-4.JACK BOARD, LED BOARD
(Page 16)
3-10.DVD MECHANISM DECK
(CDM81C-DVBU101)
(Page 21)
3-11.TRAY
(Page 22)
3-12.MOTOR BOARD
M761 (LD/ST MOTOR),
M762 (BU U/D MOTOR)
(Page 22)
3-13.BASE UNIT (DVBU101)
(Page 23)
3-14.OPTICAL PICK-UP
(KHM-310CAB)
(Page 23)
3-6.I/O BOARD, TUNER
(Page 18)
3-8.MAIN BOARD
(Page 19)
3-9.POWER BOARD
(Page 20)
3-7.SPEAKER BOARD,
D.C. FAN
(Page 18)
3-2.CASE, FRONT PANEL ASSY
(Page 15)
SET
3-15.GEAR (SUB TRAY 1),
GEAR (SUB TRAY 2)
(Page 24)
3-16.LEVER ASSY
(Page 24)
3-17.STOCKER SECTION
(Page 25)
3-20.ROTARY ENCODER (MD)
(Page 26)
3-18.CAM (STOCKER)
(Page 25)
3-21.GEAR (BU1)
(Page 27)
3-19.GEAR (STOCKER 3)
(Page 26)
