Sony HCD-DX375 - Page 65

65
HCD-DX375
•Waveforms
– DMB12 Board –
– MAIN Board –
100.0 ns
3.8 Vp-p
3 IC708 qg (X1)
1 V/DIV, 40 ns/DIV
1 IC101 6 (DVDRFIP)
200 mV/DIV, 100 ns/DIV
2 IC101 <xx. (XTALI)
1 V/DIV, 10 ns/DIV
37 ns
4.0 Vp-p
800 mVp-p
200 ns
2.7 Vp-p
5.5 Vp-p
20.3 ns
5 IC3010 rk (XFSOIN)
1 V/DIV, 10 ns/DIV
4 IC501 qg (Xin)
1 V/DIV, 100 ns/DIV
– I/O Board –
6 IC201 wd (CVBS)
7 IC201 wh (COUT)
1.8 Vp-p
H
H
8 IC201 wa (YOUT)
2.1 Vp-p
H
2.5 Vp-p
0 IC201 qk (CbOUT)
qa IC201 qh (CrOUT)
9 IC201 w; (CYOUT)
1.3 Vp-p
H
500 mV/DIV, 20
µ s/DIV
500 mV/DIV, 20 µ s/DIV
H
1.5 Vp-p
1 V/DIV, 20 µ s/DIV
2.0 Vp-p
H
1 V/DIV, 20 µ s/DIV
1 V/DIV, 20
µ s/DIV
1 V/DIV, 20
µ s/DIV
