86
HCD-DX375
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C218 1-124-779-00 ELECT CHIP 10uF 20% 16V
C219 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C220 1-124-779-00 ELECT CHIP 10uF 20% 16V
C221 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C222 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C224 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C233 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C602 1-128-994-21 ELECT CHIP 47uF 20% 10V
C603 1-128-994-21 ELECT CHIP 47uF 20% 10V
C701 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C702 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C703 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C704 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C707 1-128-993-21 ELECT CHIP 22uF 20% 10V
C709 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C710 1-124-779-00 ELECT CHIP 10uF 20% 16V
C711 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C712 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C713 1-164-172-11 CERAMIC CHIP 0.0056uF 10% 25V
C714 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C715 1-128-994-21 ELECT CHIP 47uF 20% 10V
C716 1-127-715-91 CERAMIC CHIP 0.22uF 10% 16V
C717 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C718 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C719 1-127-715-91 CERAMIC CHIP 0.22uF 10% 16V
C720 1-127-715-91 CERAMIC CHIP 0.22uF 10% 16V
C723 1-127-715-91 CERAMIC CHIP 0.22uF 10% 16V
C725 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C726 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C727 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C729 1-127-715-91 CERAMIC CHIP 0.22uF 10% 16V
C730 1-127-715-91 CERAMIC CHIP 0.22uF 10% 16V
C731 1-128-993-21 ELECT CHIP 22uF 20% 10V
C732 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C733 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C734 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C736 1-126-208-21 ELECT CHIP 47uF 20% 4V
C1103 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C1104 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C1105 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C1106 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C1107 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C1501 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C4501 1-117-370-11 CERAMIC CHIP 10uF 10V
C4502 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C4504 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C4601 1-117-370-11 CERAMIC CHIP 10uF 10V
C4602 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C4603 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C4605 1-128-994-21 ELECT CHIP 47uF 20% 10V
C4606 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C4607 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C4608 1-124-779-00 ELECT CHIP 10uF 20% 16V
C4609 1-124-779-00 ELECT CHIP 10uF 20% 16V
C4610 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C4611 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C4621 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
< CONNECTOR >
CN101 1-815-763-32 CONNECTOR, FFC/FPC 24P
* CN105 1-770-470-21 PIN, CONNECTOR (PC BOARD) 6P
CN109 1-784-370-21 CONNECTOR, FFC/FPC 11P
* CN201 1-770-470-21 PIN, CONNECTOR (PC BOARD) 6P
CN601 1-779-993-11 PIN, CONNECTOR (PWB) 5P
CN701 1-818-086-21 HDMI CONNECTOR (HDMI OUT (DVD ONLY))
CN1701 1-573-806-21 PIN, CONNECTOR (1.5MM) (SMD) 6P
CN4301 1-784-370-21 CONNECTOR, FFC/FPC 11P
CN4302 1-784-365-21 CONNECTOR, FFC/FPC 5P
CN4501 1-784-368-11 CONNECTOR, FFC/FPC 9P
< FERRITE BEAD >
FB106 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB107 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB108 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB111 1-469-670-21 FERRITE, EMI (SMD) (2012)
FB112 1-469-670-21 FERRITE, EMI (SMD) (2012)
FB115 1-469-670-21 FERRITE, EMI (SMD) (2012)
FB123 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB601 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB602 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB603 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB604 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB605 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB606 1-469-324-21 FERRITE, EMI (SMD) (2012)
< FLUORESCENT INDICATOR >
FL601 1-234-177-21 FILTER, CHIP EMI
FL602 1-233-893-21 FILTER, CHIP EMI
FL603 1-234-177-21 FILTER, CHIP EMI
FL701 1-234-177-21 FILTER, CHIP EMI
FL703 1-234-177-21 FILTER, CHIP EMI
FL704 1-234-177-21 FILTER, CHIP EMI
FL705 1-234-177-21 FILTER, CHIP EMI
FL4501 1-234-177-21 FILTER, CHIP EMI
< IC >
IC101 6-706-727-01 IC CXD9804R
IC102 6-806-675-01 IC S29AL032D70TF-CHI1-0611UC
✩ IC103 not supplied IC BR24L64F-WE2
IC104 6-707-897-01 IC EDS6416AHTA-75-E
IC105 6-702-302-01 IC TK11133CSCL-G
IC107 6-702-302-01 IC TK11133CSCL-G
IC110 6-707-739-01 IC MM1661JTRE
IC111 6-704-100-01 IC TC7PAU04FU (TE85R)
IC150 6-703-046-01 IC SN74LVC1G08DCKR
IC201 6-704-524-01 IC FAN8036L
IC701 6-708-682-01 IC CXD9873Q
IC702 6-702-300-01 IC TK11118CSCL-G
IC703 6-702-302-01 IC TK11133CSCL-G
IC705 6-703-046-01 IC SN74LVC1G08DCKR
✩ IC706 not supplied IC BR24L16F-WE2
IC707 6-705-337-01 IC TK11150CSCL-G
IC708 6-806-298-01 IC MB95F108ASPFV-GE1-H0601
IC4502 6-703-589-01 IC SN74LVC1G125DCKR
IC4601 6-707-608-01 IC PCM1803DBR
✩ New part of EEP ROM (IC103, IC706) on the DMB12 board cannot be used.
Therefore, if the mounted DMB12 board (A-1148-813-A) is replaced,
exchange new EEP ROM (IC103, IC706) with that used before the
replacement.
DMB12
Ver. 1.1
