HCD-DZ119/DZ410
3-2. CASE, FRONT PANEL ASSY
Note: Follow the disassembly procedure in the numerical order given.
1
The lever is moved in the direction
of the arrow with the thin rod.
2
3
loading panel
4
screw (CASE3 TP2)
5
screw
(CASE3 TP2
7
case
qk
front panel assy
qg
three screws (+BV 3
×
6)
9
connector (CN302)
qf
connector (CN3001)
qd
wire (flat type)
23core (CN501)
qj
claw
qh
claw
6
five screws
(+BVTP 3
×
8)
q;
two screws
(+BVTP 3
×
8)
When re-assembling, leave 30 mm between
harnesses A and B for safety.
qa
cover (top)
8
sheet
qs
sheet
harnesses A
harnesses B
clamp
30mm
