68
HCD-DZ119/DZ410
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
Q460 6-550-889-01 TRANSISTOR 2SC5938-T112-1B
Q461 6-550-889-01 TRANSISTOR 2SC5938-T112-1B
Q802 8-729-120-28 TRANSISTOR 2SC1623-L5L6
< RESISTOR >
R436 1-216-834-11 METAL CHIP 12K 5% 1/10W
R437 1-216-835-11 METAL CHIP 15K 5% 1/10W
R450 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R451 1-216-801-11 METAL CHIP 22 5% 1/10W
R452 1-216-805-11 METAL CHIP 47 5% 1/10W
R453 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R454 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R460 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R461 1-216-801-11 METAL CHIP 22 5% 1/10W
R462 1-216-805-11 METAL CHIP 47 5% 1/10W
R463 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R464 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R800 1-216-821-11 METAL CHIP 1K 5% 1/10W
R811 1-216-844-11 METAL CHIP 82K 5% 1/10W
R812 1-216-845-11 METAL CHIP 100K 5% 1/10W
R813 1-216-845-11 METAL CHIP 100K 5% 1/10W
R814 1-216-809-11 METAL CHIP 100 5% 1/10W
R815 1-216-809-11 METAL CHIP 100 5% 1/10W
R816 1-216-809-11 METAL CHIP 100 5% 1/10W
R817 1-216-821-11 METAL CHIP 1K 5% 1/10W
R819 1-216-805-11 METAL CHIP 47 5% 1/10W
R820 1-216-845-11 METAL CHIP 100K 5% 1/10W
R823 1-216-864-11 SHORT CHIP 0
*************************************************************
A-1146-119-A I/O SCART BOARD, COMPLETE (DZ410)
A-1167-326-A I/O SCART BOARD, COMPLETE (DZ119)
*************************
< CAPACITOR >
C201 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C202 1-126-925-91 ELECT 470uF 20% 10V
C203 1-126-933-11 ELECT 100uF 20% 16V
C204 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C206 1-126-964-11 ELECT 10uF 20% 50V
C208 1-115-156-11 CERAMIC CHIP 1uF 10V
C209 1-115-156-11 CERAMIC CHIP 1uF 10V
C210 1-115-156-11 CERAMIC CHIP 1uF 10V
C214 1-126-916-11 ELECT 1000uF 20% 6.3V
C215 1-126-933-11 ELECT 100uF 20% 16V
C216 1-126-933-11 ELECT 100uF 20% 16V
C225 1-126-916-11 ELECT 1000uF 20% 6.3V
C231 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C232 1-126-933-11 ELECT 100uF 20% 16V
C233 1-126-933-11 ELECT 100uF 20% 16V
C234 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C238 1-115-156-11 CERAMIC CHIP 1uF 10V
C239 1-115-156-11 CERAMIC CHIP 1uF 10V
C240 1-115-156-11 CERAMIC CHIP 1uF 10V
C244 1-126-916-11 ELECT 1000uF 20% 6.3V
C245 1-126-916-11 ELECT 1000uF 20% 6.3V
C246 1-126-916-11 ELECT 1000uF 20% 6.3V
C271 1-126-933-11 ELECT 100uF 20% 16V
C295 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C296 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C302 1-127-573-11 CERAMIC CHIP 1uF 10% 16V
C303 1-126-947-11 ELECT 47uF 20% 16V
C304 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C305 1-126-933-11 ELECT 100uF 20% 16V
C306 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C310 1-104-662-91 ELECT 22uF 20% 25V
C311 1-104-662-91 ELECT 22uF 20% 25V
C320 1-104-662-91 ELECT 22uF 20% 25V
C321 1-104-662-91 ELECT 22uF 20% 25V
C331 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C332 1-104-662-91 ELECT 22uF 20% 25V
C333 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C334 1-104-662-91 ELECT 22uF 20% 25V
C341 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C342 1-104-662-91 ELECT 22uF 20% 25V
C343 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C344 1-104-662-91 ELECT 22uF 20% 25V
C351 1-104-662-91 ELECT 22uF 20% 25V
C352 1-104-662-91 ELECT 22uF 20% 25V
C354 1-126-960-11 ELECT 1uF 20% 50V
C355 1-126-933-11 ELECT 100uF 20% 16V
C356 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C358 1-126-933-11 ELECT 100uF 20% 16V
C359 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C361 1-104-662-91 ELECT 22uF 20% 25V
C362 1-104-662-91 ELECT 22uF 20% 25V
C364 1-126-960-11 ELECT 1uF 20% 50V
C365 1-104-662-91 ELECT 22uF 20% 25V
C366 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C389 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C390 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
CN201 1-779-550-21 CONNECTOR, FFC (LIF (NON-ZIF)) 13P
CN302 1-785-331-11 PIN, CONNECTOR (LIGHT ANGLE) 5P
CN303 1-568-830-11 CONNECTOR, FFC 11P
CN304 1-779-544-21 CONNECTOR, FFC (LIF (NON-ZIF)) 7P
< DIODE >
D271 8-719-988-61 DIODE 1SS355TE-17
D272 8-719-988-61 DIODE 1SS355TE-17
D280 8-719-988-61 DIODE 1SS355TE-17
D300 8-719-058-24 DIODE RB501V-40TE-17
< IC >
IC201 6-707-489-01 IC BH7868FS-E2
IC230 6-707-489-01 IC BH7868FS-E2
IC300 6-703-550-01 IC TA7809LS
IC350 8-759-385-76 IC MC14052 BDR2
IC360 8-759-100-96 IC NJM4558M-TE2
< JACK >
J203 1-819-925-11 JACK, PIN 5P
((Y, PB/CB, PR/CR)COMPONENNT VIDEO OUT)
((R, AUDIO IN, L)LINE)
J230 1-815-911-11 CONNECTOR, SQUARE TYPE 21P
(EURO AV T OUT PUT (TO TV))
