75
HCD-DZ119/DZ410
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
IC511 6-708-922-01 IC PST3635NR
IC516 6-703-547-01 IC TA7805LS
IC1101 6-707-535-01 IC CXD9849R
IC1102 6-806-818-01 IC MX29LV320CBTC70-OBA2-0604CE (DZ410)
IC1102 6-806-745-01 IC MX29LV320CBTC70-OBA1-0603CE (DZ119)
✩ IC1103 not supplied IC BR24L64F-WE2
IC1104 6-709-370-01 IC A2V64S40CTP-G75
IC1105 6-702-302-01 IC TK11133CSCL-G
IC1107 6-702-302-01 IC TK11133CSCL-G
IC1109 6-707-485-01 IC NJM2885DL1-18 (TE2)
IC1201 6-704-524-01 IC FAN8036L
IC2200 6-707-608-01 IC PCM1803DBR
IC3001 8-759-710-97 IC NJM4565M (TE2)
IC3003 8-759-680-48 IC TC7WH157FK (TE85R)
IC3010 6-705-979-01 IC CXD9788AR (DZ410)
IC3010 6-707-939-01 IC CXD9843AR (DZ119)
IC3020 6-705-979-01 IC CXD9788AR (DZ410)
IC3020 6-707-939-01 IC CXD9843AR (DZ119)
IC3030 6-705-979-01 IC CXD9788AR (DZ410)
IC3030 6-707-939-01 IC CXD9843AR (DZ119)
IC3050 6-702-300-01 IC TK11118CSCL-G
IC3051 8-759-649-50 IC SN74AHC1GU04DCKR
IC3100 6-708-921-01 IC CXD9883M
IC3150 6-708-921-01 IC CXD9883M
IC3200 6-708-921-01 IC CXD9883M
IC3250 6-708-921-01 IC CXD9883M
IC3300 6-708-921-01 IC CXD9883M
IC3400 6-708-921-01 IC CXD9883M
< SHORT >
JC500 1-216-864-11 SHORT CHIP 0 (DZ410)
JC501 1-216-864-11 SHORT CHIP 0 (DZ119)
JC521 1-216-864-11 SHORT CHIP 0
< COIL >
L2200 1-414-754-11 INDUCTOR 10uH
L2201 1-216-295-91 SHORT CHIP 0
L3000 1-469-527-91 INDUCTOR 47uH
L3051 1-414-754-11 INDUCTOR 10uH
L3052 1-414-754-11 INDUCTOR 10uH
L3053 1-414-754-11 INDUCTOR 10uH
L3054 1-412-939-11 INDUCTOR 1uH
L3111 1-456-680-11 INDUCTOR 10uH
L3112 1-456-680-11 INDUCTOR 10uH
L3151 1-456-680-11 INDUCTOR 10uH
L3152 1-456-680-11 INDUCTOR 10uH
L3201 1-456-680-11 INDUCTOR 10uH
L3202 1-456-680-11 INDUCTOR 10uH
L3251 1-456-680-11 INDUCTOR 10uH
L3252 1-456-680-11 INDUCTOR 10uH
L3301 1-456-680-11 INDUCTOR 10uH
L3302 1-456-680-11 INDUCTOR 10uH
L3401 1-456-680-11 INDUCTOR 10uH
L3402 1-456-680-11 INDUCTOR 10uH
< TRANSISTOR >
Q502 6-550-718-01 TRANSISTOR RSR025N03TL
Q506 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1101 6-550-008-01 TRANSISTOR UM6K1N-TN
Q1102 6-550-653-01 TRANSISTOR QST8TR
Q1103 8-729-901-00 TRANSISTOR DTC124EK
Q3000 8-729-142-48 TRANSISTOR 2SD1616-TP-LK
Q3001 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q3002 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q3081 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q3101 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R (DZ119)
Q3101 8-729-600-22 TRANSISTOR 2SA1235-F (DZ410)
Q3102 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R (DZ119)
Q3102 8-729-600-22 TRANSISTOR 2SA1235-F (DZ410)
Q3151 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R (DZ119)
Q3151 8-729-600-22 TRANSISTOR 2SA1235-F (DZ410)
Q3152 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R (DZ119)
Q3152 8-729-600-22 TRANSISTOR 2SA1235-F (DZ410)
Q3201 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R (DZ119)
Q3201 8-729-600-22 TRANSISTOR 2SA1235-F (DZ410)
Q3202 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R (DZ119)
Q3202 8-729-600-22 TRANSISTOR 2SA1235-F (DZ410)
Q3251 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R (DZ119)
Q3251 8-729-600-22 TRANSISTOR 2SA1235-F (DZ410)
Q3252 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R (DZ119)
Q3252 8-729-600-22 TRANSISTOR 2SA1235-F (DZ410)
Q3301 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R (DZ119)
Q3301 8-729-600-22 TRANSISTOR 2SA1235-F (DZ410)
Q3302 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R (DZ119)
Q3302 8-729-600-22 TRANSISTOR 2SA1235-F (DZ410)
Q3401 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R (DZ119)
Q3401 8-729-600-22 TRANSISTOR 2SA1235-F (DZ410)
Q3402 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R (DZ119)
Q3402 8-729-600-22 TRANSISTOR 2SA1235-F (DZ410)
Q3551 8-729-120-28 TRANSISTOR 2SC1623-L5L6
< RESISTOR >
R506 1-216-821-11 METAL CHIP 1K 5% 1/10W
R507 1-216-841-11 METAL CHIP 47K 5% 1/10W
R513 1-216-821-11 METAL CHIP 1K 5% 1/10W
R515 1-216-821-11 METAL CHIP 1K 5% 1/10W
R519 1-216-809-11 METAL CHIP 100 5% 1/10W
R524 1-216-833-11 METAL CHIP 10K 5% 1/10W
R535 1-216-821-11 METAL CHIP 1K 5% 1/10W
R536 1-216-821-11 METAL CHIP 1K 5% 1/10W
R577 1-216-821-11 METAL CHIP 1K 5% 1/10W
(DZ119)
R577 1-216-841-11 METAL CHIP 47K 5% 1/10W
(DZ410)
R585 1-216-809-11 METAL CHIP 100 5% 1/10W
R586 1-216-809-11 METAL CHIP 100 5% 1/10W
R587 1-216-809-11 METAL CHIP 100 5% 1/10W
R588 1-216-809-11 METAL CHIP 100 5% 1/10W
R589 1-216-809-11 METAL CHIP 100 5% 1/10W
R590 1-216-809-11 METAL CHIP 100 5% 1/10W
R591 1-216-809-11 METAL CHIP 100 5% 1/10W
R592 1-216-833-11 METAL CHIP 10K 5% 1/10W
R593 1-216-833-11 METAL CHIP 10K 5% 1/10W
R594 1-216-809-11 METAL CHIP 100 5% 1/10W
R595 1-216-809-11 METAL CHIP 100 5% 1/10W
MAIN
✩ New part of EEP ROM (IC1103) on the MAIN board cannot be used.
Therefore, if the mounted MAIN board (A-1144-739-A, etc.) is replaced,
exchange new EEP ROM (IC1103) with that used before the replacement.
Ver. 1.1
