Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-DZ370/DZ560/DZ570/DZ660/DZ777
8383
C499 1-104-662-11 ELECT 22uF 20% 25V
C504 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C505 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
(DZ777)
C509 1-104-662-11 ELECT 22uF 20% 25V
(DZ777)
C511 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
(DZ777)
C512 1-104-662-11 ELECT 22uF 20% 25V
(DZ777)
C514 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C518 1-126-960-11 ELECT 1uF 20% 50V
C521 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C524 1-104-662-11 ELECT 22uF 20% 25V
C525 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C528 1-126-933-11 ELECT 100uF 20% 16V
(DZ777)
C529 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(DZ777)
C530 1-104-662-11 ELECT 22uF 20% 25V
C533 1-126-960-11 ELECT 1uF 20% 50V
C535 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C536 1-104-662-11 ELECT 22uF 20% 25V
C537 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C538 1-104-662-11 ELECT 22uF 20% 25V
C541 1-126-933-11 ELECT 100uF 20% 16V
C542 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C548 1-127-573-11 CERAMIC CHIP 1uF 10% 16V
C549 1-126-947-11 ELECT 47uF 20% 35V
C552 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C556 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C557 1-126-933-11 ELECT 100uF 20% 16V
C558 1-104-662-11 ELECT 22uF 20% 25V
C559 1-104-662-11 ELECT 22uF 20% 25V
C561 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V (KR)
C562 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V (KR)
C569 1-126-964-11 ELECT 10uF 20% 50V
C620 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C621 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C622 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
< CONNECTOR >
CN402 1-779-285-11 CONNECTOR, FFC (LIF(NON-ZIF)) 17P
CN407 1-779-285-11 CONNECTOR, FFC (LIF(NON-ZIF)) 17P
CN412 1-564-706-11 PIN, CONNECTOR (SMALL TYPE) 4P
CN418 1-779-273-11 CONNECTOR, FFC (LIF(NON-ZIF)) 5P
CN419 1-784-770-11 CONNECTOR, FFC 9P
< DIODE >
D405 6-501-579-01 DIODE MC2837 (DZ777)
D406 6-501-579-01 DIODE MC2837
D407 8-719-058-24 DIODE RB501V-40TE-17
D411 6-501-579-01 DIODE MC2837
D412 6-501-728-01 DIODE MAZ8051G0LS0
< IC >
IC404 6-710-470-01 IC MM1758AFBE
IC407
8-759-385-76 IC MC14052BDR2
IC409 8-759-385-76 IC MC14052BDR2 (DZ777)
IC411 8-759-385-76 IC MC14052BDR2
IC413 6-700-830-01 IC KIA7809API
IC620 6-705-338-01 IC TK11250CMCL-G
< JACK >
J401
1-817-601-11 JACK, PIN 3P (COMPONENT VIDEO OUT)
J403 1-778-940-11 JACK, PIN 2P (SAT/CABLE (AUDIO IN R/L))
(DZ777)
J404 1-820-862-11 JACK, PIN 3P (VIDEO OUT,
TV/VIDEO (AUDIO IN (R/L)))
(DZ370/DZ570)
J404 1-820-862-11 JACK, PIN 3P (VIDEO OUT,
TV (AUDIO IN (R/L))) (DZ777)
< JUMPER RESISTOR >
JR502 1-216-864-11 SHORT CHIP 0
JR503 1-216-864-11 SHORT CHIP 0
JR504 1-216-864-11 SHORT CHIP 0
JR505 1-216-864-11 SHORT CHIP 0
JR506 1-216-864-11 SHORT CHIP 0
JR507 1-216-864-11 SHORT CHIP 0
JR508 1-216-864-11 SHORT CHIP 0
JR515 1-216-864-11 SHORT CHIP 0
JR516 1-216-864-11 SHORT CHIP 0
< COIL >
L404 1-469-525-91 INDUCTOR 10uH
L407 1-469-525-91 INDUCTOR 10uH
< TRANSISTOR >
Q408 8-729-027-52 TRANSISTOR DTC124EKA-T146
Q409 8-729-027-52 TRANSISTOR DTC124EKA-T146
Q410 8-729-027-52 TRANSISTOR DTC124EKA-T146 (DZ777)
Q411 8-729-027-52 TRANSISTOR DTC124EKA-T146 (DZ777)
Q412 8-729-027-52 TRANSISTOR DTC124EKA-T146
Q413 8-729-027-52 TRANSISTOR DTC124EKA-T146
< RESISTOR >
R439 1-218-285-11 METAL CHIP 75 5% 1/10W
R444 1-218-827-11 METAL CHIP 150 0.5% 1/10W
R445 1-218-827-11 METAL CHIP 150 0.5% 1/10W
R446 1-218-827-11 METAL CHIP 150 0.5% 1/10W
R447 1-218-827-11 METAL CHIP 150 0.5% 1/10W
R448 1-218-827-11 METAL CHIP 150 0.5% 1/10W
R449 1-218-285-11 METAL CHIP 75 5% 1/10W
R452 1-218-285-11 METAL CHIP 75 5% 1/10W
R458 1-216-864-11 SHORT CHIP 0
R459 1-216-864-11 SHORT CHIP 0
R468 1-218-285-11 METAL CHIP 75 5% 1/10W
R473 1-218-285-11 METAL CHIP 75 5% 1/10W
R479 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R480 1-216-841-11 METAL CHIP 47K 5% 1/10W
R481 1-216-841-11 METAL CHIP 47K 5% 1/10W
R485 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R486 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R489 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R490 1-216-841-11 METAL CHIP 47K 5% 1/10W
R491 1-216-841-11 METAL CHIP 47K 5% 1/10W
R494 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(DZ777)
R495 1-216-833-11 METAL CHIP 10K 5% 1/10W
R496 1-216-841-11 METAL CHIP 47K 5% 1/10W
(DZ777)
R497 1-216-841-11 METAL CHIP 47K 5% 1/10W
(DZ777)
