Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-DZ370/DZ560/DZ570/DZ660/DZ777
84
R500 1-216-821-11 METAL CHIP 1K 5% 1/10W
R503 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(DZ777)
R504 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(DZ777)
R505 1-216-833-11 METAL CHIP 10K 5% 1/10W
R506 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(DZ777)
R507 1-216-841-11 METAL CHIP 47K 5% 1/10W
(DZ777)
R508 1-216-841-11 METAL CHIP 47K 5% 1/10W
(DZ777)
R509 1-216-821-11 METAL CHIP 1K 5% 1/10W
R513 1-216-864-11 SHORT CHIP 0
R514 1-216-864-11 SHORT CHIP 0
R515 1-216-864-11 SHORT CHIP 0
R516 1-216-864-11 SHORT CHIP 0
R523 1-216-864-11 SHORT CHIP 0
R527 1-216-841-11 METAL CHIP 47K 5% 1/10W
R528 1-216-841-11 METAL CHIP 47K 5% 1/10W
R533 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R536 1-216-833-11 METAL CHIP 10K 5% 1/10W
(DZ777)
R538 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R539 1-216-841-11 METAL CHIP 47K 5% 1/10W
R540 1-216-841-11 METAL CHIP 47K 5% 1/10W
R541 1-216-864-11 SHORT CHIP 0
R543 1-216-821-11 METAL CHIP 1K 5% 1/10W
(DZ777)
R546 1-216-864-11 SHORT CHIP 0
R548 1-216-864-11 SHORT CHIP 0
R550 1-216-833-11 METAL CHIP 10K 5% 1/10W
(DZ777)
R551 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R552 1-216-841-11 METAL CHIP 47K 5% 1/10W
R553 1-216-841-11 METAL CHIP 47K 5% 1/10W
R556 1-216-821-11 METAL CHIP 1K 5% 1/10W
(DZ777)
R557 1-216-809-11 METAL CHIP 100 5% 1/10W
R558 1-216-809-11 METAL CHIP 100 5% 1/10W
R559 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R561 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R562 1-216-864-11 SHORT CHIP 0 (DZ370/DZ570)
R563 1-216-864-11 SHORT CHIP 0 (DZ777)
R564 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R566 1-216-841-11 METAL CHIP 47K 5% 1/10W
R567 1-216-841-11 METAL CHIP 47K 5% 1/10W
R575 1-216-833-11 METAL CHIP 10K 5% 1/10W
R576 1-216-864-11 SHORT CHIP 0 (DZ370/DZ570)
R577 1-216-864-11 SHORT CHIP 0 (DZ777)
R579 1-216-821-11 METAL CHIP 1K 5% 1/10W
R582 1-216-833-11 METAL CHIP 10K 5% 1/10W
R584 1-216-821-11 METAL CHIP 1K 5% 1/10W
R591 1-216-864-11 SHORT CHIP 0
R592 1-216-809-11 METAL CHIP 100 5% 1/10W
R593 1-216-864-11 SHORT CHIP 0
R595 1-216-864-11 SHORT CHIP 0
R598 1-216-833-11 METAL CHIP 10K 5% 1/10W
R599 1-216-833-11 METAL CHIP 10K 5% 1/10W
R600 1-216-845-11 METAL CHIP 100K 5% 1/10W
R601 1-216-845-11 METAL CHIP 100K 5% 1/10W
R602 1-216-845-11 METAL CHIP 100K 5% 1/10W
R603 1-216-845-11 METAL CHIP 100K 5% 1/10W
R609 1-216-864-11 SHORT CHIP 0
R610 1-216-864-11 SHORT CHIP 0
R620 1-216-821-11 METAL CHIP 1K 5% 1/10W
R621 1-215-865-11 METAL OXIDE 220 5% 1W
R622 1-216-864-11 SHORT CHIP 0
R623 1-216-864-11 SHORT CHIP 0
*************************************************************
A-1438-877-A IO-SCART BOARD, COMPLETE (DZ560)
A-1438-933-A IO-SCART BOARD, COMPLETE (DZ660)
************************
< CAPACITOR >
C400 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C401 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C402 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C403 1-126-933-11 ELECT 100uF 20% 16V
C404 1-126-933-11 ELECT 100uF 20% 16V
C405 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C406 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C407 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C408 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C409 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C410 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C411 1-126-933-11 ELECT 100uF 20% 16V
C412 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C413 1-126-933-11 ELECT 100uF 20% 16V
C414 1-126-933-11 ELECT 100uF 20% 16V
C415 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C416 1-126-964-11 ELECT 10uF 20% 50V
C417 1-126-916-11 ELECT 1000uF 20% 6.3V
C419 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C420 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C421 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C422 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C423 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C424 1-126-933-11 ELECT 100uF 20% 16V
C425 1-126-964-11 ELECT 10uF 20% 50V
C443 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(DZ660)
C481 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C482 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C491 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C495 1-104-662-11 ELECT 22uF 20% 25V
C496 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C499 1-104-662-11 ELECT 22uF 20% 25V
C504 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C505 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
(DZ660)
C509 1-104-662-11 ELECT 22uF 20% 25V
(DZ660)
C511 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
(DZ660)
C512 1-104-662-11 ELECT 22uF 20% 25V
(DZ660)
C518 1-126-960-11 ELECT 1uF 20% 50V
C521 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C524 1-104-662-11 ELECT 22uF 20% 25V
C525 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C528 1-126-933-11 ELECT 100uF 20% 16V
(DZ660)
IO-COMPONENT IO-SCART
