Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-DZ370/DZ560/DZ570/DZ660/DZ777
8585
C529 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(DZ660)
C530 1-104-662-11 ELECT 22uF 20% 25V
C533 1-126-960-11 ELECT 1uF 20% 50V
C535 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C536 1-104-662-11 ELECT 22uF 20% 25V
C537 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C538 1-104-662-11 ELECT 22uF 20% 25V
C541 1-126-933-11 ELECT 100uF 20% 16V
C542 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C548 1-127-573-11 CERAMIC CHIP 1uF 10% 16V
C549 1-126-947-11 ELECT 47uF 20% 35V
C552 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C556 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C557 1-126-933-11 ELECT 100uF 20% 16V
C558 1-104-662-11 ELECT 22uF 20% 25V
C559 1-104-662-11 ELECT 22uF 20% 25V
C561 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C562 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C569 1-126-964-11 ELECT 10uF 20% 50V
C620 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C621 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C622 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
< CONNECTOR >
CN400 1-816-044-11 CONNECTOR, SQUARE TYPE 21P
(EURO AV T OUTPUT (TO TV))
CN401 1-779-287-11 CONNECTOR, FFC (LIF(NON-ZIF)) 19P
CN406 1-779-287-11 CONNECTOR, FFC (LIF(NON-ZIF)) 19P
CN410 1-779-273-11 CONNECTOR, FFC (LIF(NON-ZIF)) 5P
CN412 1-564-706-11 PIN, CONNECTOR (SMALL TYPE) 4P
CN414 1-568-830-11 CONNECTOR, FFC 11P
< DIODE >
D401 6-501-817-01 DIODE MA2J1110GLS0
D402 6-501-817-01 DIODE MA2J1110GLS0
D407 8-719-058-24 DIODE RB501V-40TE-17
D411 6-501-579-01 DIODE MC2837
D412 6-501-728-01 DIODE MAZ8051G0LS0
< IC >
IC400 6-710-470-01 IC MM1758AFBE
IC407
8-759-385-76 IC MC14052BDR2
IC409 8-759-385-76 IC MC14052BDR2 (DZ660)
IC411 8-759-385-76 IC MC14052BDR2
IC413 6-700-830-01 IC KIA7809API
IC620 6-705-338-01 IC TK11250CMCL-G
< JACK >
J403
1-778-940-11 JACK, PIN 2P (LINE (AUDIO IN R/L)) (DZ660)
< JUMPER RESISTOR >
JR401 1-216-864-11 SHORT CHIP 0
JR403 1-216-864-11 SHORT CHIP 0
JR404 1-216-864-11 SHORT CHIP 0
JR405 1-216-864-11 SHORT CHIP 0
JR406 1-216-864-11 SHORT CHIP 0
JR407 1-216-864-11 SHORT CHIP 0
JW427 1-216-864-11 SHORT CHIP 0
JW433 1-216-864-11 SHORT CHIP 0
< COIL >
L401 1-469-525-91 INDUCTOR 10uH
L407 1-469-525-91 INDUCTOR 10uH
< TRANSISTOR >
Q400 8-729-038-28 TRANSISTOR RT1N441C-TP-1
Q401 8-729-038-28 TRANSISTOR RT1N441C-TP-1
Q402 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q403 8-729-027-52 TRANSISTOR DTC124EKA-T146
Q404 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q405 8-729-038-28 TRANSISTOR RT1N441C-TP-1
Q406 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q408 8-729-027-52 TRANSISTOR DTC124EKA-T146
Q409 8-729-027-52 TRANSISTOR DTC124EKA-T146
Q410 8-729-027-52 TRANSISTOR DTC124EKA-T146 (DZ660)
Q411 8-729-027-52 TRANSISTOR DTC124EKA-T146 (DZ660)
Q412 8-729-027-52 TRANSISTOR DTC124EKA-T146
Q413 8-729-027-52 TRANSISTOR DTC124EKA-T146
< RESISTOR >
R400 1-216-815-11 METAL CHIP 330 5% 1/10W
R401 1-216-815-11 METAL CHIP 330 5% 1/10W
R402 1-216-815-11 METAL CHIP 330 5% 1/10W
R403 1-216-849-11 METAL CHIP 220K 5% 1/10W
R404 1-216-815-11 METAL CHIP 330 5% 1/10W
R405 1-216-837-11 METAL CHIP 22K 5% 1/10W
R406 1-216-811-11 METAL CHIP 150 5% 1/10W
R407 1-216-811-11 METAL CHIP 150 5% 1/10W
R408 1-216-821-11 METAL CHIP 1K 5% 1/10W
R409 1-216-833-11 METAL CHIP 10K 5% 1/10W
R410 1-216-811-11 METAL CHIP 150 5% 1/10W
R411 1-216-841-11 METAL CHIP 47K 5% 1/10W
R412 1-216-811-11 METAL CHIP 150 5% 1/10W
R413 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R414 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R415 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R416 1-216-811-11 METAL CHIP 150 5% 1/10W
R417 1-216-811-11 METAL CHIP 150 5% 1/10W
R418 1-216-811-11 METAL CHIP 150 5% 1/10W
R419 1-216-811-11 METAL CHIP 150 5% 1/10W
R421 1-216-864-11 SHORT CHIP 0
R422 1-218-285-11 METAL CHIP 75 5% 1/10W
R424 1-216-821-11 METAL CHIP 1K 5% 1/10W
R425 1-216-809-11 METAL CHIP 100 5% 1/10W
R426 1-216-809-11 METAL CHIP 100 5% 1/10W
R431 1-218-827-11 METAL CHIP 150 0.5% 1/10W
R432 1-218-827-11 METAL CHIP 150 0.5% 1/10W
R433 1-218-827-11 METAL CHIP 150 0.5% 1/10W
R434 1-218-827-11 METAL CHIP 150 0.5% 1/10W
R435 1-218-827-11 METAL CHIP 150 0.5% 1/10W
R479 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R480 1-216-841-11 METAL CHIP 47K 5% 1/10W
R481 1-216-841-11 METAL CHIP 47K 5% 1/10W
R485 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R486 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R489 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R490 1-216-841-11 METAL CHIP 47K 5% 1/10W
R491 1-216-841-11 METAL CHIP 47K 5% 1/10W
IO-SCART
