Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-EC59
42
R475 1-216-826-11 METAL CHIP 2.7K 5% 1/10W
R476 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
R480 1-216-833-11 METAL CHIP 10K 5% 1/10W
R481 1-216-821-11 METAL CHIP 1K 5% 1/10W
R482 1-216-822-11 METAL CHIP 1.2K 5% 1/10W
R483 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R484 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R485 1-216-826-11 METAL CHIP 2.7K 5% 1/10W
R486 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
R487 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R490 1-216-833-11 METAL CHIP 10K 5% 1/10W
R491 1-216-821-11 METAL CHIP 1K 5% 1/10W
R492 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R493 1-216-843-11 METAL CHIP 68K 5% 1/10W
R494 1-216-839-11 METAL CHIP 33K 5% 1/10W
R495 1-216-833-11 METAL CHIP 10K 5% 1/10W
R496 1-216-833-11 METAL CHIP 10K 5% 1/10W
R497 1-216-817-11 METAL CHIP 470 5% 1/10W
R498 1-216-821-11 METAL CHIP 1K 5% 1/10W
R499 1-216-809-11 METAL CHIP 100 5% 1/10W
< ROTARY ENCODER >
S491 1-786-417-11 ENCODER, ROTARY (VOLUME)
< SWITCH >
SW471 1-771-410-21 SWITCH, TACTILE (FUNCTION)
SW472 1-771-410-21 SWITCH, TACTILE (REC TO USB)
SW473 1-771-410-21 SWITCH, TACTILE (
–)
SW474 1-771-410-21 SWITCH, TACTILE (u)
SW475 1-771-410-21 SWITCH, TACTILE (– TUNING l m)
SW476 1-771-410-21 SWITCH, TACTILE (DSGX)
SW481 1-771-410-21 SWITCH, TACTILE (CD)
SW482 1-771-410-21 SWITCH, TACTILE (USB)
SW483 1-771-410-21 SWITCH, TACTILE (ENTER)
SW484 1-771-410-21 SWITCH, TACTILE ( +)
SW485 1-771-410-21 SWITCH, TACTILE (
x
)
SW486 1-771-410-21 SWITCH, TACTILE (TUNING +
M
L
)
SW487 1-771-410-21 SWITCH, TACTILE (OPTIONS)
SW491 1-771-410-21 SWITCH, TACTILE (I/1)
< VIBRATOR >
X301 1-814-067-11 OSCILLATOR, CRYSTAL (32.768kHz)
X302 1-813-548-31 VIBRATOR, CERAMIC (6MHz)
*************************************************************
PT-SWITCH BOARD
***************
< CAPACITOR >
C051 1-165-621-11 CERAMIC CHIP 0.1uF 50V
< CONNECTOR >
0 CN051 1-793-660-11 PIN, CONNECTOR (PC BOARD) 3P
< DIODE >
D051 6-500-334-01 DIODE MC2836-T112-1
D052 6-500-335-01 DIODE MC2838-T112-1
D053 6-500-335-01 DIODE MC2838-T112-1
< TRANSFORMER >
0 PT051 1-445-105-11 TRANSFORMER, POWER
< RELAY >
0 RY051 1-755-276-22 RELAY, POWER (MX)
0 RY052 1-755-496-11 RELAY (EXCEPT MX)
< VOLTAGE SELECTOR >
0 S051 1-786-408-11 SELECTOR, VOLTAGE (SWS-2301)
(VOLTAGE SELECTOR) (E2, E4, E51)
*************************************************************
REG BOARD
**********
< CAPACITOR >
C697 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C698 1-164-156-11 CERAMIC CHIP 0.1uF 25V
< IC >
IC690 6-713-032-01 IC KIA7809API-U/PF
*************************************************************
USB BOARD
**********
< CAPACITOR >
C900 1-117-681-11 ELECT CHIP 100uF 20% 16V
C901 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C902 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C903 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C904 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C905 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C906 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C907 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C908 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C909 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C915 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C916 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C917 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C918 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C919 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C920 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C921 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C950 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C951 1-162-910-11 CERAMIC CHIP 5PF 0.25PF 50V
C952 1-162-910-11 CERAMIC CHIP 5PF 0.25PF 50V
C953 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C954 1-126-601-11 ELECT CHIP 2.2uF 20% 50V
C955 1-165-884-11 CERAMIC CHIP 2.2uF 10% 6.3V
< CONNECTOR >
CN901 1-784-382-51 CONNECTOR, FFC/FPC 25P
CN902 1-784-382-51 CONNECTOR, FFC/FPC 25P
CN903 1-764-250-11 PIN, CONNECTOR (PC BOARD) 4P
CN910 1-784-366-51 CONNECTOR, FFC/FPC 7P
< IC >
IC901 A-1768-193-A IC LC87F1JJ2AU-SQFP-H (for SERVICE)
PANEL
PT-SWITCH
REG USB
