Sony HCD-EC59 - Page 43

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-EC59
4343
< RESISTOR >
R900 1-216-864-11 SHORT CHIP 0
R901 1-216-809-11 METAL CHIP 100 5% 1/10W
R902 1-216-809-11 METAL CHIP 100 5% 1/10W
R903 1-216-857-11 METAL CHIP 1M 5% 1/10W
R904 1-216-864-11 SHORT CHIP 0
R905 1-216-809-11 METAL CHIP 100 5% 1/10W
R906 1-216-809-11 METAL CHIP 100 5% 1/10W
R907 1-216-809-11 METAL CHIP 100 5% 1/10W
R908 1-216-809-11 METAL CHIP 100 5% 1/10W
R909 1-216-809-11 METAL CHIP 100 5% 1/10W
R910 1-216-845-11 METAL CHIP 100K 5% 1/10W
R911 1-216-809-11 METAL CHIP 100 5% 1/10W
R912 1-216-845-11 METAL CHIP 100K 5% 1/10W
R913 1-216-809-11 METAL CHIP 100 5% 1/10W
R914 1-216-845-11 METAL CHIP 100K 5% 1/10W
R915 1-216-809-11 METAL CHIP 100 5% 1/10W
R916 1-216-809-11 METAL CHIP 100 5% 1/10W
R917 1-216-809-11 METAL CHIP 100 5% 1/10W
R918 1-216-805-11 METAL CHIP 47 5% 1/10W
R919 1-216-805-11 METAL CHIP 47 5% 1/10W
R920 1-216-805-11 METAL CHIP 47 5% 1/10W
R921 1-216-809-11 METAL CHIP 100 5% 1/10W
R922 1-216-809-11 METAL CHIP 100 5% 1/10W
R923 1-216-809-11 METAL CHIP 100 5% 1/10W
R924 1-216-809-11 METAL CHIP 100 5% 1/10W
R951 1-216-835-11 METAL CHIP 15K 5% 1/10W
R952 1-216-835-11 METAL CHIP 15K 5% 1/10W
R953 1-216-803-11 METAL CHIP 33 5% 1/10W
R954 1-216-803-11 METAL CHIP 33 5% 1/10W
R955 1-216-864-11 SHORT CHIP 0
< VIBRATOR >
X901 1-814-365-11 QUARTZ CRYSTAL UNITS (12MHz)
*************************************************************
USB-JACK BOARD
***************
< CAPACITOR >
C561 1-126-923-91 ELECT 220uF 20% 10V
C565 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
< CONNECTOR >
CN560 1-794-548-21 CONNECTOR, USB (A) (
)
< JUMPER RESISTOR >
FB561 1-216-295-00 SHORT CHIP 0
FB562 1-216-295-00 SHORT CHIP 0
< RESISTOR >
R561 1-216-789-11 METAL CHIP 2.2 5% 1/10W
R562 1-216-789-11 METAL CHIP 2.2 5% 1/10W
*************************************************************
MISCELLANEOUS
**************
58 1-832-814-21 CABLE, FLEXIBLE FLAT (9 CORE)
61 1-832-635-21 CABLE, FLEXIBLE FLAT (25 CORE)
62 1-838-369-21 CABLE, FLEXIBLE FLAT (25 CORE)
63 1-838-370-21 CABLE, FLEXIBLE FLAT (25 CORE)
103 1-832-796-21 CABLE, FLEXIBLE FLAT (5 CORE)
0 107 1-834-966-41 POWER-SUPPLY CORD (E2, E4, E51)
0 107 1-837-312-11 CORD, POWER-SUPPLY (AR)
0 107 1-837-344-11 CORD, POWER-SUPPLY (MX)
152 1-834-268-21 WIRE (FLAT TYPE) (16 CORE)
0 157 A-1780-028-A OPTICAL PICK-UP BLOCK (DA11MMVGP)
(Including sled motor (M402), spindle motor (M401))
164 1-452-899-31 MAGNET
0 M601 1-787-344-11 FAN, DC
0 PT054 1-445-881-11 TRANSFORMER, POWER (MX)
0 PT054 1-445-882-11 TRANSFORMER, POWER (E2, E4, E51, AR)
S001 1-771-853-11 SWITCH, DETECTION (LIMIT)
SW305 1-692-960-11 SWITCH, PUSH (1 KEY)
(CD LID OPEN/CLOSE DETECT)
*************************************************************
ACCESSORY
***********
0 1-569-008-33 ADAPTOR, CONVERSION (E2, E4, E51)
USB USB-JACK
