Sony HCD-EC98P - CD Mechanism Section (US and Canadian Models) (CDM77 B-K6 BD90-WOD)

52
HCD-EC98P
251 A-1242-967-A LOADING (BK) ASSY
252 3-080-478-01 BELT
253 4-985-672-01 SCREW (+PTPWHM2.6), FLOATING
254 4-227-045-41 SPRING (INSULATOR)
255 4-229-005-41 INSULATOR
0 256 A-4735-357-A BASE ASSY, OP (KSM-213D)
257 1-832-404-21 CABLE, FLEXIBLE FLAT (16 CORE)
258 A-1217-914-A CD BOARD, COMPLETE
S201 1-771-853-11 SWITCH, DETECTION (LIMIT)
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
7-6. 1 CD MECHANISM SECTION (US and Canadian models)
(CDM77B-K6BD90-WOD)
not supplied
not supplied
not supplied
(MOTOR board)
251
252
255
254
253
253
255
254
255
255
S201
sled motor (M402)
257
256
(including sled motor (M402),
spindle motor (M401))
spindle motor (M401)
258
